- Page 1 ADPRO iFT Gateway Hardware Installation Manual February 2019 Doc. 33104_01 Firmware version XO 4.03...
- Page 3 ADPRO iFT Gateway Hardware Installation Manual Disclaimer The contents of this document are provided on an "as is" basis. No representation or warranty (either express or implied) is made as to the completeness, accuracy or reliability of the contents of this document. The manufacturer reserves the right to change designs or specifications without obligation and without further notice. Except as otherwise provided, all warranties, express or implied, including without limitation any implied warranties of merchantability and fitness for a particular purpose are expressly excluded. Intellectual Property and Copyright This document includes registered and unregistered trademarks. All trademarks displayed are the trademarks of their respective owners. Your use of this document does not constitute or create a license or any other right to use the name and/or trademark and/or label. This document is subject to copyright owned by Honeywell. You agree not to copy, communicate to the public, adapt, distribute, transfer, sell, modify, or publish any contents of this document without the express prior written consent of Honeywell. Trade Name Statement ADPRO, FastTrace, iFT, iFT-E, iFT Gateway, IntrusionTrace, LoiterTrace, XO, iTrace, iCommand, iCommission, iPIR, and FMST are trademarks and/or registered trademarks of Honeywell and/or its subsidiaries in the United States and/or other countries. Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s). Your use of this document does not constitute or create a licence or any other right to use the name and/or trademark and/or label. General Warning This product must only be installed, configured and used strictly in accordance with the General Terms and Conditions, User Manual and product documents available from Honeywell. All proper health and safety precautions must be taken during the installation, commissioning, and maintenance of the product. The system should not be connected to a power source until all the components have been installed. Proper safety precautions must be taken during tests and maintenance of the products when these are still connected to the power source. Failure to do so or tampering with the electronics inside the products can result in an electric shock causing injury or death and may cause equipment damage. Honeywell is not responsible and cannot be held accountable for any liability that may arise due to improper use of the equipment and/or failure to take proper precautions. Only persons trained through an Honeywell accredited training course can install, test and maintain the system. Liability You agree to install, configure, and use the products strictly in accordance with the User Manual and product documents available from Honeywell. Honeywell is not liable to you or any other person for incidental, indirect, or consequential loss, expense or damages of any kind including without limitation, loss of business, loss of profits, or loss of data arising out of your use of the products. Without limiting this general disclaimer the following specific warnings and disclaimers also apply: Fitness for Purpose You agree that you have been provided with a reasonable opportunity to appraise the products and have made your own independent assessment of the fitness ...
- Page 4 Gateway Hardware Installation Manual ADPRO Contact Us UK and Europe +44 1442 242 330 D-A-CH +49 431 23284 1 The Americas +1 781 740 2223 Middle East +962 6 588 5622 Asia +86 21 5240 0077 Australia and New Zealand +61 3 9936 7000 www.security.honeywell.com Environmental Information The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end of life. This applies to the device but also to any accessories marked with this symbol. Do not dispose of these products as unsorted municipal waste. If you need more information on the collection, reuse, and recycling systems please contact your local waste administration. You can also contact us for more information on the environmental specifications of our products. 33104_01...
-
Page 5: Table Of Contents
ADPRO iFT Gateway Hardware Installation Manual Contents Technical Specifications About the iFT Gateway Overview Packing List Power Requirements Safety Instructions Technical Documents Licenses 2.6.1 Overview 2.6.2 System License Software Memory Card Capacity Placing a Memory Card Preparing a Used Memory Card for Recording LED Status Indications Connectors Network Connection XO I/O Interface USB Modules Overview of Inputs and Outputs... - Page 6 Gateway Hardware Installation Manual ADPRO 33104_01...
-
Page 7: Technical Specifications
ADPRO iFT Gateway Hardware Installation Manual Technical Specifications ® Operating system ADPRO XO™ Security Operating System, Linux based Video input 4 IP cameras Video output Not applicable; live video viewing via client PC (XO client) Video compression H.264/H.265 (H.265 is camera dependent) Video resolution and 4 analytic streams: max. 4SIF @5 fps, max. 1 Mbps, with analytic on each frames/second channel 4 high-resolution streams: max. 1920 x 1080 @25 fps, max. 2 Mbps Bandwidth capacity (video) 4 x 2 Mbps Bandwidth management Configurable variable or constant bitrate / Configurable bandwidth limiter Audio input Via approved cameras Audio output Standard 1 line level output (AV/OUT). Audio level 2 Vrms; output impedance 600 Ω Audio out on IP cameras with ONVIF or brand-specific driver. Alarm inputs Via XO I/O Interface USB module: 20 inputs (monitored). Via Network I/O unit with PoE: up to 128 (monitored or unmonitored). Relay outputs Via XO I/O Interface USB module: 8 outputs (SPDT). -
Page 8: About The Ift Gateway
Gateway Hardware Installation Manual ADPRO About the iFT Gateway Note You can find the latest versions of this document and any referenced document on the Security Solutions Support site www.xtralissecurity.com (logon may be required). If a document number is indicated (between parentheses), you can enter it in the Keywords box on the site, and search for the document. Overview The ADPRO iFT Gateway is the entry-level member of the XO-enabled NVR+ portfolio, offering 4 IP channels of video transmission with the option to easily add 4 IP channels of ADPRO analytics, and event recording on memory card. Note This document usually refers to the iFT Gateway device as XO device. Multi-site configuration is possible: Integration of up to 10 000 XO devices Remote video and audio, live video, and consultation of recordings Compatible with VCP, EMS, and iTrace SDK for third-party integration. Packing List After unpacking, check for any signs of damage. Report any damage to your supplier immediately. Also check whether all items are present: ADPRO iFT Gateway device: pre-installed with XO firmware ... -
Page 9: Technical Documents
ADPRO iFT Gateway Hardware Installation Manual Technical Documents Download the XO Client Software User Manual for iFT Gateway (33103) from the Security Solutions Support website www.xtralissecurity.com. You can also download technical data sheets and technical manuals on specific devices that connect to the XO device. You can find the latest versions of this document and any referenced document on the Security Solutions Support site www.xtralissecurity.com (logon may be required). If a document number is indicated (between parentheses), you can enter it in the Keywords box on the site, and search for the document. Licenses 2.6.1 Overview All XO devices require licenses: System license IP video channel licenses (Optional) Analytic application licenses: IntrusionTrace and LoiterTrace. 2.6.2 System License The system license defines the maximum number of video channels allowed, and the maximum number of analytic channels allowed on your system. The iFT Gateway system license allows for max. 4 video channels and max. 4 analytic channels. The iFT Gateway system license is a TRANSMITTER (TX) license, which allows for event recording, but no continuous recording. Event recording is fixed to 10 seconds (no pre- or post-event recording), and recording stops when the daily limit of 16 000 events has been reached (the counter is reset at night). -
Page 10: Memory Card
Gateway Hardware Installation Manual ADPRO Memory Card Capacity For event recording, you can insert a microSD memory card (not supplied) in the XO device's Micro SD card slot. The recording features in the XO client are only available if there is a memory card present. The minimum required capacity of the memory card is 32 GB. The system supports SDHC and SDXC cards that are high-speed compatible. Caution! If possible, always use a fresh, unused memory card. Do not use memory cards that have been used for flashing firmware; they contain bootable partitions and may render the XO device unusable if you try to use them for recording. For instructions on cleaning partitions and removing bootable flags from a memory card, see Preparing a Used Memory Card for Recording on page 11. Note You can specify a minimum number of days to keep recordings on the memory card. The system will calculate if there is sufficient space on the memory card, and it will activate system input 0050 – [SYST] – STORAGE INSUFFICIENT if this is not the case. The system calculates the required memory card space based on the past recordings. For details, see the XO Client Software User Manual for iFT Gateway (33103). Placing a Memory Card When you insert a memory card in the device's card slot, the system will automatically prepare the card for ... -
Page 11: Preparing A Used Memory Card For Recording
ADPRO iFT Gateway Hardware Installation Manual Preparing a Used Memory Card for Recording If you want to record on a used memory card, it is recommended to format it first, to remove all data. You can use a tool such as SDFormatter (downloadable from www.sdcard.org). If the memory card is still not usable after formatting, it may contain bootable partitions. You have to remove these first. One method is to run DiskPart from the Windows Command Prompt. You need to run the Command Prompt as an Administrator. To clean partitions and remove bootable flags from a used memory card, proceed as follows: 1. Insert the memory card in your PC. 2. Open the Windows Command Prompt. 3. Type diskpart and press Enter. 4. Type list disk and press Enter. A list of disks appears. 5. Type select disk x (where x is the disk number that corresponds with the memory card) and press Enter. In the example, the disk number is 1 (disk with size 28 GB). Caution! Be careful to select the correct disk. If you accidentally select your PC's hard disk instead of the memory card, you will clear all information from you disk and your PC will become unusable. 6. Type clean and press Enter. - Page 12 Gateway Hardware Installation Manual ADPRO 10. Type detail disk and press Enter. The disk information appears. 11. Check that Boot Disk indicates No. 12. Type exit and press Enter to exit the DiskPart tool. You can now use the memory card for recording on your iFT Gateway. 33104_01...
-
Page 13: Led Status Indications
ADPRO iFT Gateway Hardware Installation Manual LED Status Indications The LED on the iFT Gateway indicates the status of the system. Day-to-day operation, XO status Description Blue, continuous Booting (uboot/linux) Blue 1 s on, 1 s off (repeat) Starting XO software Blue, continuous XO running without issues Blue 2 s on, red 1 s on (repeat) XO running with system fault Red, continuous XO no longer running Blue 2 s on, 0.2 s briefly on/off (repeat) XO running and recording Blue 2 s on, red 1 s on, blue 0.2 s on/off (repeat) XO running with system fault, and recording 33104_01... -
Page 14: Connectors
Gateway Hardware Installation Manual ADPRO Connectors The image below indicates the connectors on the XO device: Micro SD: memory card slot. Ethernet: network connector (RJ45) USB1: for XO I/O Interface USB module or HDMI: do not use. 3G/4G wingle. USB2: for XO I/O Interface USB module or DC 5V: 3.5 mm jack for power supply (5 VDC, 3G/4G wingle. 2 A). AV/OUT: audio line out Status LED Caution! The audio out (AV/OUT) and power in (DC 5V) connectors look similar. Take care to use the correct connectors. 33104_01... -
Page 15: Network Connection
ADPRO iFT Gateway Hardware Installation Manual Network Connection An XO device requires an IP network connection for communication with the client PC, the IP cameras, the CMS (alarm transmission), and optional peripherals such as Net I/O units. The iFT Gateway can connect to the IP network: wired: using an Ethernet cable on the XO device's Ethernet port, connecting to a switch or router in the local network. You must use the wired connection for commissioning the iFT Gateway. wireless: using the built-in Wi-Fi. This feature is disabled by default, therefore you need to commission the iFT Gateway using the wired Ethernet connection. After commissioning, you can enable and configure the Wi-Fi connection. For details, see the XO Client Software User Manual for iFT Gateway (33103). using a combination of wired and wireless connections. Below is an example of a fully wired network with the iFT Gateway, a client PC, IP cameras, and a Net I/O module. Below is an example of a fully wireless network with the iFT Gateway, a client PC, and IP cameras. Depending on your configuration, make sure that the IP addresses of the iFT Gateway, client PC, IP cameras… are in the correct network range. 33104_01... - Page 16 Gateway Hardware Installation Manual ADPRO Caution! If you want to use Wi-Fi, make sure that your wireless network is reliable and stable. If not, video may not be visible or may not be recorded, and alarms may not be transmitted! 33104_01...
-
Page 17: Xo I/O Interface Usb Modules
XO I/O Interface USB Modules The XO I/O Interface USB module offers command inputs and relay outputs. There are single and double modules, but on the iFT Gateway, you can only use a single module. XO I/O Interface USB module: Rear view, single module: For detailed information, see the XO I/O Interface USB Module Technical Manual (32688). Overview of Inputs and Outputs The image below shows the inputs and outputs on a single module: IN1–20 are voltage-free contact inputs. Each input has its own GND. C1–8 are voltage-free relay contact outputs. Each output has a common terminal (C1–C8) and both a normal open (NO1–NO8) and normal closed (NC1–NC8) terminal. Use the appropriate terminal for each output. Do not use both NO and NC terminals for the same output. The connectors labelled N.U. are not used. Input Circuits Below are the NEOL, SEOL, and DEOL configurations for the inputs. For correct operation, you also have to indicate the used input circuit configuration in the XO client software. For more information, see the XO Client Software User Manual for iFT Gateway (33103). 33104_01... -
Page 18: Connecting Inputs And Outputs
Gateway Hardware Installation Manual ADPRO Normally open – NEOL Normally open – SEOL Short circuit = alarm Short circuit = alarm Open circuit = idle 1K1 = idle (Default setting) Open circuit = tamper Normally closed – NEOL Normally closed – SEOL Short circuit = idle Short circuit = tamper Open circuit = alarm 1K1 = idle Open circuit = alarm Normally open – DEOL Short circuit = tamper 1K1 = alarm 3K3 = idle Open circuit = tamper Normally closed – DEOL Short circuit = tamper 1K1 = idle 3K3 = alarm Open circuit = tamper Connecting Inputs and Outputs Depending on the type, the I/O card can be equipped with Dinkle (standard) or Phoenix spring insertion ... -
Page 19: Network I/O Units (Net I/O)
Units Technical Manual (33355). Caution! Before plugging or unplugging any extension units, switch off the power to the base unit. Plugging or unplugging extension units with power on may result in permanent and irreparable damage to the base and/or extension units. Base unit: Extension unit: For detailed installation instructions, including programming the IP address and updating the software, see the ADPRO Network I/O Units Technical Manual (33355). To configure the inputs and outputs, see the XO Client Software User Manual for iFT Gateway (33103). 33104_01... -
Page 20: Via Wingle
Gateway Hardware Installation Manual ADPRO 4G Via Wingle The Huawei E8372 wingle offers a 4G connection on your XO device. Before you can use the wingle, you need to prepare it on your PC. Then you can insert it into your XO device and specify the PPP settings in the XO client. For details, see the XO Client Software User Manual for iFT Gateway (33103). You can insert the wingle into either of the device's USB ports. 33104_01... -
Page 21: Audio
IP Camera List (26742). Usage of IP audio modules is similar to IP cameras with audio in capabilities. For details, see Using IP Audio Devices on page 23. Note If the connection bandwidth is low, it is recommended to disable live audio streaming. Audio IN is unbalanced audio. Changing the audio settings requires a system restart. In the XO client, you have to enable the audio inputs for recording and listening in the live view. For more information, see the XO Client Software User Manual for iFT Gateway (33103). 10.2 Audio OUT (Talkback) 10.2.1 Options Talkback to the site works via the Live Video window in the XO client software. You select a camera, and then use the microphone (typically connected to the client PC) to talk to the site via the speaker that is associated with that camera. If you need only one speaker on your site, you can connect an amplified loudspeaker to the AV/OUT (line out) connector of the iFT Gateway. -
Page 22: Troubleshooting Talkback
Gateway Hardware Installation Manual ADPRO 10.2.2 Troubleshooting Talkback You can test talkback using the XO client (as of firmware version XO 4.3). The audio out setup screen provides a test button to play a sound clip. For details, see the XO Client Software User Manual for iFT Gateway (33103). If talkback does not work, check the following: In the XO client software, check the access rights of the user: Audio talk must be allowed. Routers may block UDP packets. In the audio setup in the XO client, specify TCP, or configure the router to allow UDP packets. Use the PC headphones plug instead of the PC microphone plug. Check the configuration of the microphone on your computer. For details, see below. To configure the microphone on your computer in Windows Vista/Windows 7, proceed as follows: 1. Click Start, and then click Control Panel. 2. Click Sound, and then click the Recording tab. 3. If you have more than one sound device, check if the device you want to use with the XO device is the default device. If not, right-click the desired device, and click Set as Default Device. -
Page 23: Using Ip Audio Devices
ADPRO iFT Gateway Hardware Installation Manual 5. Click OK, and close Control Panel. 10.3 Using IP Audio Devices There are several IP audio devices that you can use for audio in/out, such as the Axis Network Horn Speaker (C3003-E) and the Axis P8221 I/O Audio Module. For details on the supported features of the IP audio devices, see the Supported IP Camera List (26742). You manage an IP audio device on the XO device as if it were an IP camera with audio in and audio out capabilities: You connect the IP audio device to the IP camera network, and enable it in the XO client as an IP camera. The audio device occupies one IP channel. As there is no video from the device, the system will display a speaker icon in the live/recorded video windows. You enable audio in and audio out just like for an IP camera. You select it for talkback in the Live Video window just like a camera with audio out. You can set up recording for the device. When you play back the recording, the system will display a speaker icon instead of video, but you will hear the recorded sound (audio in from the built-in microphone and audio out from talkback). 33104_01... -
Page 24: Current Consumption
Gateway Hardware Installation Manual ADPRO Current Consumption Motherboard max. 450 mA (320 mA on average) USB ports max. 750 mA each Note Measurements were made on iFT Gateway with: USB port 1, Huawai wingle (operational on 4G): approx. 250 mA USB port 2, XO I/O Interface USB module with all 8 output relais on: approx. 250 mA; with all 8 output relais off: approx. 50 mA. 33104_01... -
Page 25: Diagnostics
ADPRO iFT Gateway Hardware Installation Manual Diagnostics 12.1 Log Files and Reports In case of major troubles with the XO device, the system allows to generate a number of log files and reports. In some cases, the Honeywell Support Division may ask you to activate and capture some log files and reports that can be helpful to resolve technical issues. 12.2 Retrieving Log Files The XO device can output its internal trace buffer to hard disk to allow logging for longer periods without losing the data. You need to enable logging first. To enable logging and retrieve log files, proceed as follows: 1. Type the device’s IP address in the address bar of your internet browser, and add /log.php to the address. For example: http://10.0.0.10/log.php. The Internal Logging page appears. It displays instructions to enable logging. If logging is not yet enabled, the Log list at the bottom of the page is empty. 33104_01... - Page 26 Gateway Hardware Installation Manual ADPRO 2. To enable logging, connect to the device via Telnet and enter the following Telnet commands: tr,1 tr,output,file After you have enabled logging, links to the log files appear on the web page in the Log list: 3. To retrieve a log file, click the link on the web page. Depending on your system settings, the system will open the file in the browser, or will (ask to) download the file. 33104_01...
-
Page 27: Retrieving Reports
ADPRO iFT Gateway Hardware Installation Manual 4. If you have downloaded the file, double-click it to open it. If the following message appears, choose Select a program from a list of installed programs, and then set Notepad as default application. 12.3 Retrieving Reports The XO device also generates reports. You can view these reports via the internet browser. Type the IP address of the XO device in the address bar of the browser and add /report.php to the IP address. Example: http://10.0.0.10/report.php The Server Report contains the following information: General Memory usage Time + zone Processes Uptime Performance Vmstat I/O stat PID stat MP stat 33104_01... - Page 28 Gateway Hardware Installation Manual ADPRO Network Interfaces – available Interfaces – enabled Routes Listen ports Netstat – all DEV stats Sockstat ARP cache Filesystem Mounts S.M.A.R.T Fsck Open files Free disk space Hardware Memory Mainboard Udev database Server Server version Server process memory usage Files Active config 33104_01...
-
Page 29: Web
ADPRO iFT Gateway Hardware Installation Manual Web Pages There are several web pages to consult with the XO device. To open these web pages in your internet browser: type the IP address in the address bar, followed by the extensions as described in the table below. Web page Description index.php This is the main page of the XO device. If the XO client has been installed, this page automatically opens the XO client application. If the application has not yet been installed, you will be redirected to the setup page (setup.php). setup.php On this page you can download the XO client application. tools.php This page contains the links to the internal logging, the core dump and the network trace: log.php Here you can download the log files (see Retrieving Log Files on page 25). report.php Here you can consult essential information on the configuration (see Retrieving Reports on page 27). core.php Here you can download the core dump (crash info) and watch dump (hang info) when you encounter these specific problems. The Honeywell Support Division may ask you to send these files to them for further investigation. Always mention the version when providing a core dump! phpshell.php This is a Linux console through a web browser. You need a username and password to use this tool. This is by default only accessible for the Honeywell Development Team. net.php Here you find a network sniffer for network tracing. You can use it for checking why a certain client cannot connect to the XO device. -
Page 30: Maintenance
Gateway Hardware Installation Manual ADPRO Maintenance An iFT Gateway device requires almost no maintenance. Keep the device dust-free. Caution! Do NOT clean the device with water or any corrosive products. Use only dust cloths and wipes to clean the outside. 33104_01... -
Page 31: Product Labelling
ADPRO iFT Gateway Hardware Installation Manual Product Labelling 15.1 Labels All ADPRO products are labelled. The labels contain the following information: A: Product number (0AN-4IP-0TB-0IN-0OUT / 0xRS485-NO DTC), part number (66000000), and serial number B: MAC address in aabbccddeeff format. 33104_01... -
Page 32: Declaration Of Conformity
Gateway Hardware Installation Manual ADPRO 15.2 Declaration of Conformity 33104_01... - Page 34 www.security.honeywell.com UK and Europe +44 1442 242 330 D-A-CH +49 431 23284 1 The Americas +1 781 740 2223 Middle East +962 6 588 5622 Asia +86 21 5240 0077 Australia and New Zealand +61 3 9936 7000 A Disclaimer about this document, statements about Intellectual Property, Copyrights, and Liability, as well as a General Warning are available in an earlier section of this document. Document No: 33104_01 P/N 19532220...
