The internal blower kit will increase the circulation of heated air generated by the fireplace into the room
where it is installed. If you desire to distribute the heat in different rooms, please refer to central heating
and zone heating kits (FO-FDHB6-1, FO-FDHC6, FO-FDHCZ1 and FO-FDHCZ2).
All wiring should be in accordance with local ordinances and the National Electric Code.
One thermal switch is all that is required to operate the internal blower, the central heating blower or
both. If the thermal switch is already installed, skip to the installation of the internal blower.
INSTALLATION ON A DELTA
Installation of the thermal switch assembly
1. Remove the bottom central and right louvers.
2. The thermal switch goes in the middle of the central bottom louver opening, on the flange at the
back of the shield below the firebox, with the thermal switch facing upwards (see Figure 1). Make
sure to push the "S" clips onto the flange as far as they will go.
Installation of the internal blower assembly
3. Pass the blower through the bottom louver opening so that the outlet is on the bottom and facing
towards the back (see Figure 1).
4. Slide the blower between the two centering brackets on the fireplace base.
INSTALLATION ON AN ONYX OR OPEL
Installation of the thermal switch assembly
1. Open the bottom louver.
2. Under the firebox, on the left of the right firebox leg, you will find a welded bracket (see Figure 2).
Install the thermal switch on that bracket, with the thermal switch facing upwards. Make sure to
push the "S" clips onto the flange as far as they will go.
If you have an ash pan in your fireplace, make sure that it is still possible to remove the ash pan
once the thermal switch is installed.
Installation of the internal blower assembly
3. Remove the vibration rubber dampers at both ends of the blower and reinstall them on both ends of
the central support (see Figure 3).
4. If your fireplace is equipped with an ash pan: remove the ash pan plug, remove the ash pan and
then remove the ash pan support by unscrewing the screw located at the back of the support.
FO-FDHB5-N
Internal Blower for Delta, Onyx, Opel
FO-FDHB5-N-2007-08
Advertisement
Table of Contents
Related Manuals for RSF Woodburning Fireplaces FO-FDHB5-N
Summary of Contents for RSF Woodburning Fireplaces FO-FDHB5-N
- Page 1 FO-FDHB5-N Internal Blower for Delta, Onyx, Opel The internal blower kit will increase the circulation of heated air generated by the fireplace into the room where it is installed. If you desire to distribute the heat in different rooms, please refer to central heating and zone heating kits (FO-FDHB6-1, FO-FDHC6, FO-FDHCZ1 and FO-FDHCZ2).
- Page 2 6. Connect terminals 5 and 6 of the terminal block to a 110V circuit with 2/14 gauge wiring. Do not forget to attach the ground wire to the fireplace ground screw which is next to the terminal block. 7. Place all wires in such a fashion that they will not come in contact with the firebox. FO-FDHB5-N-2007-08...
- Page 3 FO-FDHB5-N Ventilateur interne pour Delta2, Onyx2, Opel2 et Opel3 La trousse du ventilateur interne permet une meilleure circulation de l'air chaud généré par le foyer dans la pièce où est situé celui-ci. Si vous désirez faire circuler la chaleur dans différentes pièces, consultez les trousses de chauffage central et de chauffage par zone (FO-FDHB6-1, FO-FDHC6, FO- FDHCZ1 et FO-FDHCZ2).
- Page 4 2/14 aux bornes 4 et 5 du bloc de bornes. Cela prend environ 20 à 30 minutes pour que le foyer dégage suffisamment de chaleur pour actionner l'interrupteur thermique afin qu'il puisse, à son tour, activer le ventilateur. Avec l'interrupteur manuel, le FO-FDHB5-N-2007-08...
- Page 5 Équerre soudée / Welded bracket Patte droite de la boîte à feu / Right firebox leg Figure 2 Installation de l'interrupteur thermique dans un foyer Onyx ou Opel / Installation of the thermal switch in an Onyx or Opel fireplace FO-FDHB5-N-2007-08...
- Page 6 Ventilateur interne / Sortie du ventilateur pointant Internal blower vers le haut / Blower outlet pointing up Figure 4 Installation du ventilateur dans un foyer Onyx ou Opel / Installation of the blower in an Onyx or Opel fireplace FO-FDHB5-N-2007-08...
- Page 7 1 Assemblage de l'interrupteur thermique / Thermal Switch assembly (1.13.H#.1.DNP) 1 Interrupteur de vitesse variable / Variable Speed Switch (940001) 1 Sac contenant 4 connecteurs en fourchette / 1 Bag containing 4 spade connectors (942006) INITIALES Notice d'installation et liste de contrôle / Instructions and check list INITIALS FO-FDHB5-N-2007-08...
