Summary of Contents for Blizzard H200
- Page 1 Refrigerators and Freezers H200/400/600 L200/400/600...
-
Page 2: Table Of Contents
Original Instruction Dear Customer, Congratulations on your purchase of this product. Like all our products , this product has also been developed on the basis of the latest technology and produced using reliable and modern electrical components. Please take a few minutes before starting operation of the appliance and read the following operating instructions. Save this manual for further reference. -
Page 3: Safety Tips
Safety Tips... -
Page 4: Intended Use
Intended Use Only use this appliance for cooling and storage of food and beverage for commercial purposes. Parts Freezer RN400 RN600 9. Plug 1. Main switch (Optional) 10. Door support 2. Front panel 11. Down panel 3. Lock 12. Door down hinge 4. -
Page 5: Parts
Parts Refrigerator RC400 RC600 RC200 12. Small shelf Main switch (optional) 2. Front panel 13. Door down hinge 3. Lock 14. Down panel 4. Controller 15. Door support 5. Fan panel 16. Plug 6. Fan 17. Evaporator 18. Water container 7. -
Page 6: Location And Installation
Location and Installation The cabinet should be placed in a room that is dry and sufficiently ventilated. To operate efficiently it should not be positioned in direct sunlight or near warm appliances. Please note that optimal cabinet performance is obtained at an ambient temperature between +16 °C and +35 °C. -
Page 7: Operation
Main switch Lock Thermostat Display Plug in the cabinet. The display shows the actual cabinet temperature Servicing Make sure the appliance is switched off at the mains before service is performed on electrical parts. Operation Storing food To get the best results from your appliance, follow these instructions: •... -
Page 8: Temperature Setting And Control(Evco)
Temperature setting and control (EVCO) The front panel of the thermostat Compressor operation light Defrosting light Energy saving light Stand-by light Programming key (service agent only) Machine On/Stand -by (keep pushed) Manual defrost (keep pushed) How to unlock the keyboard (»Loc» message) Push any button for more than 2s, «UnL»... -
Page 9: Defrosting Procedure
Defrosting Procedure Refrigerator: Automatic Defrosting using automatic water evaporation. Automatic defrost The appliance will automatically run defrost cycles Note: The cycle starts from the time the appliance is initially powered up. To manually defrost the appliance: • Press and hold the DEFROST button for 5 seconds. •... - Page 10 3. Take off the door...
-
Page 11: Changing The Door Hinge
Changing the Door Hinge 4. Remove hinge 1 Hinge 2 Hinge 1 5. Change the two hinge positions Hinge 2 Hinge 1 6. Fix hinge1... - Page 12 Changing the Door Hinge 7. Remove Hinge 4 (Lower door hinge) 8. Remove Hinge 3 (Upper door hinge)
- Page 13 Changing the Door Hinge 9. Exchange the position of Hinge 3 and Hinge 4 Hinge 4 Hinge 3 Hinge 3 Hinge 4 10. Fix Hinge 3 and Hinge 4 on the door Hinge 3 Hinge 4...
-
Page 14: Changing The Door Hinge
Changing the Door Hinge 11. Turn the door up side down and connect to the upper hinge. 12. Fix Hinge2... -
Page 15: Cleaning, Care & Maintenance
Cleaning, Care & Maintenance Before cleaning, switch off the cabinet and disconnect from the mains. The cabinet should be kept clean using a mild soap solution. Do not use abrasive cleansers. The plastic parts cannot withstand boiling water (max. temperature +85 °C). When regular cleaning is performed, be sure to wipe clean the rubber door gasket to ensure any sticky substances are removed that would otherwise damage the gasket. -
Page 16: Trouble Shooting
Trouble shooting If your Refrigerator, Freezer appliance develop a fault, please check the following table. Fault Probable Cause Action Check that the unit is plugged in The unit is not switched on The appliance is not working correctly and switched on Call our agent or qualified Plug and/or lead are damaged technician... - Page 17 Model RC200 RCX200 RCG200 RCGX200 RN200 RNX200 RNG200 RNGX200 Climate Class Temp.Range (°C) 0 ~ +8°C 0 ~ +8°C +2 ~ +8°C +2 ~ +8°C -23 ~ -18°C -23 ~ -18°C -23 ~ -18°C -23 ~ -18°C Refrigerant R134/R600a R134/R600a R134/R600a R134/R600a R134/R600a...
-
Page 18: Warranty
Environmental Protection Discarded electric appliances are recyclable and should not be discarded in the domestic waste! Please actively support us in conserving resources and protecting the environment by retur ning this appliance to the collection centres (if available). CAUTION: RISK OF FIRE AND EXPLOSION WITH FLAMMABLE REFRIGERANT R600a. WARRANTY A statutory warranty applies for this product.
