Summary of Contents for Alpha Arsenal EXPRESS GSM
-
Page 2: Getting Started
EXPRESS GSM Smart Power Switch USER MANUAL GETTING STARTED GSM Socket ‘EXPRESS GSM Smart Power Switch’ was specifically designed to: manage and wirelessly control via radio channel, security devices that guard and protect closed perimeters against unauthorized penetration; Wireless security alarm unit ‘Motion Detector MD 101’, Wireless security magnetic contact switch alarm unit ‘Door/Window... - Page 3 TURNING POWER ON AND SET UP 1. Remove the battery compartment cover from the Socket. If the battery cover is screwed down; remove the screw. 2. Insert the SIM card into the SIM card holder located on the Socket circuit board. The angled portion of the SIM card should be aligned with the lower right hand corner of the holder.
- Page 4 Within a span of 60 seconds, the Socket stands by for incoming calls, requests from keychain remotes, alarm devices & sirens and SMS's requesting a change in settings (each action of this type extends the standby span an additional 60 seconds). At the end of the final standby span, the Socket automatically exits the programming mode.
-
Page 5: Safety Precautions
9. To add alarm devices such as the ‘Motion Detector MD 101’ and ‘DOOR/WINDOW SENSOR DWS 102’, activate the power by removing the protective plastic insert from in between the battery and the battery holder contacts on the circuit board, while depressing the tamper. At the conclusion of registration, the alarm device indicator flashes red 3 times and the Socket emits a single beep. -
Page 6: Installation
It is prohibited to install the device at medical facilities. Radio signals from the device might adversely affect the operation of some sensitive equipment and possibly cause a threat to human life. It is prohibited to install the device in locations where the use of mobile phones is prohibited. ... - Page 7 3. The ‘PRISMA-S’ siren can be placed in any convenient location; for example, on a bookshelf or hung on a wall. The maximum operating distance for the siren and alarm devices is up to 100 meters in an open space. VERIFICATION 1.
- Page 8 7. Press the ‘B’ button on the keychain remote control. The Socket will enter the <<Disarmed>> mode and the light diode on the keychain remote control will flash green. 8. The light diodes on the siren will flash twice and 2 short beeps will sound. 9.
-
Page 9: Arming And Disarming
In order to turn on the electrical power load, send an SMS- command containing ‘*1’ from a registered telephone to the telephone number of the Socket SIM card. An SMS confirmation that the electrical power load was turned on containing the text ‘Relay turned on from number +xxxxxxxxxxx’... - Page 10 To disarm, press the <<B>> button on the keychain remote control. The Socket will enter the <<Disarmed>> mode and the light diode on the keychain remote control will flash green. The light diodes on the siren will flash twice and 2 short beeps will sound. The primary number will receive an SMS notification containing the text <<Disarmed via keychain remote control No.#>>.
- Page 11 SERVICE CERTIFICATE On the company website www.alpha-safe.com, in the documentation section, the full version of the user manual for operating and setting up the GSM Socket can be found. Together, we have just executed basic setup. If you desire to learn and acquire a greater volume of detailed information, then familiarize yourself with this available resource.
