- Page 1 User manual...
- Page 2 Dear customer! Thank you for choosing our product. The efforts of different specialists of “Siberian Arsenal” scientific production association were put into creation of the modern high-quality technical security devices. Please look through this manual so that the device could serve for a long time and failure- free.
- Page 3 Have you ever thought that set the alarm is expensive and troublesome, we also thought so! Now everything has become much easier. If you decide to protect yourself from the troubles, it would take only 10 minutes! Be sure you can handle easily! You rent a flat, and have no possibility to equip it with alarm.
- Page 4 Settings For setting motion detector you will need: - SIM card with balance. PIN code request should be disabled; - Mobile telephone; - Remote controller; - motion detector; - Battery. For your ease you should record motion detector SIM card telephone number into your telephone book, for example «Cottage guard».
- Page 5 mode? Just change the jumper setting (see page 7). Every 7 days you will receive test SMS messages with balance. 10. If you did not manage to record remote controller in motion detector’s memory or call the number of motion detector within defined period, remove the battery from the motion detector, wait 2-3 minutes.
- Page 6 For the initial setup of motion detector please follow several simple operations. 1.Remove the screw at the bottom part. 2. Remove the motion detector cap.
- Page 7 Insert the SIM card into its holder. Set the jumper in position 1 or 2. 1. Normal mode. Set the jumper to the "S" position. You will receive SMS informing about turning on/off the protection mode. Protection mode can be turned off by remote controller in any time.
- Page 8 Insert the battery into the motion detector slot observing polarity. At power-up, an audible beep sounds. Then three short beeps sound and the LED winks 1 time in 5 seconds. WARNING! Within 30 seconds after this you should record a phone number in motion detector memory (see next.
- Page 9 After 3 short beeps sound, during 30 seconds you should send SMS with your cell phone number to motion detector SIM card number in format: 1)+XXXXXX XXXX, where 1) – index number, XXXXXXXXXXX – your cell phone number in international format Your phone number will be set as the main for alert alarm,...
- Page 10 Since the end of the call, you have 30 seconds to press briefly the remote controller button. After pressing it, the motion detector will record remote controller in it’s memory. During recording, the LED alternately winks red and green. After recording one beep noise will sound.
- Page 11 1. Close the motion detector cap. 2. Tighten the screw at the bottom of the hull.
- Page 12 Within 30-40 seconds a service SMS with installed settings will be received at your mobile phone (which number was saved in motion detector SIM memory). These settings may be changed in the future. More detailed information about additional settings of the signalizator is available in operating manual at www.express-gsm.info in Documentation...
-
Page 13: Installation
Installation Put the motion detector into the place, where it will be protected from exposing to atmospheric precipitation, mechanical damages and access of unauthorized persons. The motion detector should be placed such a way that makes a protected zone well within view. - Page 14 The wall with motion detector shouldn’t receive heavy vibration. Presence of some objects (furniture, screens, plants etc.) in the protected zone makes “blind“ zones behind them and motion detector may not detect human pass such zones. Presence of animals and birds in the protected zone may lead to false alarm. Detecting zones are shown in the picture below.
- Page 15 Motion detector functional Test After installation of the motion detector it is necessary to test its functionality. Use the first and the second testing methods for common mode and the third and the fourth testing methods for economy mode. The first method (jumper is put in “S” position). Press remote controller button.
- Page 16 sound every 4 seconds during 60 seconds (total about 15 times). It is need to leave the protected zone during this period. Leave the protected zone. Wait 2-3 minutes. Enter the protected zone. Wait for receiving SMS with text “Alarm” and incoming call. Press remote controller button.
- Page 17 Turning On/Off the Protection Mode Protection mode is turned on\off by remote controllers, registered in motion detector memory. Remote controllers covering distance is up to 15 m. In order to turn on the protection mode press remote controller button. Remote controller LED lights yellow while waiting for the motion detector response.
-
Page 18: Specifications
Specifications Feature Value Human appearance detection range, not less 10 m Radio remote controller maximum covering distance 15 m GSM module standard GSM-900/1800/1900 Maximum quantity of telephone numbers for warning Maximum quantity of radio remote controllers for turning on/off protection mode Warning period 10 - 40 s... -
Page 19: Package Contents
SAPO.425718.009 Radio remote controller BN-1-S Li Battery CR123A 3,0 V SAPO.425152.030 User manual Contact Details SP «Siberian Russia, 630073, Alpha Arsenal USA, 11375 Arsenal» Novosibirsk, Suite #1-B, 104-20 Queens Blvd., Gorskiy microdistrict, 8a New York, NY tel.: +7 (383) 211-29-63 tel.: +1 718-825-6292... -
Page 20: Warranty
Warranty Warranty period is one year. During this period manufacturer is to repair, change or adjust at option failed product for free. Warranty doesn’t cover the products with mechanical damages, traces of repairing by one’s own or other signs of abuse. Warranty doesn’t cover the battery. - Page 21 FCC Information This device complies with Part 15 of the FCC Results. Operation is subject to the following two conditions: This Device may not cause harmful interface, and This device must accept any interference received, including interference that may cause undesired operation.
- Page 22 The FCC approved GSM module is used in this mobile/fixed application. The antenna (with required gain in its certification) used for the GSM transmitter must be installed to provide a separation distance of at least 20 cm from all persons in order to satisfy RF exposure compliance for the final host device.
