Eurolec PC TEMP Series Operating Instructions

EUROLEC INSTRUMENTATION LTD.

Battery Fitting

Open the Battery compartment, by removing the screw from the
back of the Instrument and lifting off the cover.
Insert one 9 Volt battery PP3 style (MN 1604 or equivalent), and connect
to the PP3 terminals. It will only fit one way.
Refit the battery compartment cover.

Probe Insertion

Insert the probe plug into the socket at the top of the Instrument,
ensuring correct probe type and polarity observed, by aligning it up
correctly. Also ensure that the plug pins are pushed firmly into the
socket.
NOTE: For safety, do not bring probe into contact with any surface
connected to a hazardous voltage i.e. above 50Volts.

Operation:

Depress the button marked
button marked
Apply probe tip to substance being measured, and allow reading to
stabilise. This stabilisation time will vary with the different sizes of
probes.
The ⇑ and ⇓ buttons on the PC Temp K2 model are used to select the
display scale (or resolution). To display temperatures over 200° C the ⇑
button must be pressed.
Press and hold the ON button
thermometer in a low light area.
There is an auto shut -off facility, which will turn the instrument off
automatically after approx. 5 minutes.
PC TEMP Series
PORTABLE THERMOMETERS
OPERATING INSTRUCTIONS
********************
to turn it OFF.
to turn the Instrument ON and the
to turn on the backlight, when using the
