- Page 1 WD010611400 1400W...
- Page 2 WD010611400 Thank you for purchasing a VIDO product. We are confident that you will appreciate the quality of the product and you will be entirely satisfied with your purchase. Please read carefully the user safety and operating instruction on how to operate this product correctly within safety...
- Page 3 WD010611400...
- Page 4 WD010611400...
-
Page 5: Component List
1400W ANGLE POLISHER COMPONENT LIST 1) Spindle locking button 2) Auxiliary handle 3) Variable speed dial Lock-on button Switch trigger 6) Brush holder cap 7) Polishing plate 8) Polishing bonnet NORMAL ACCESSORIES 1) Auxiliary handle: 2) Polishing plate: 3) Polishing bonnet: 4) Hex key: 5) Spare carbon brush: 1set... -
Page 6: General Power Tool Safety Warnings
1400W ANGLE POLISHER GENERAL POWER TOOL SAFETY WARNINGS Warning: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 7 1400W ANGLE POLISHER f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 8 1400W ANGLE POLISHER Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory. After inspecting and installing an accessory, position yourself and bystanders away from the plane of the rotating accessory and run the power tool at maximum no-load speed for one minute.
-
Page 9: Double Insulation
1400W ANGLE POLISHER b) Never place your hand near the rotating accessory. Accessory may kickback over your hand. Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging. d) Use special care when working corners, sharp edges, etc. -
Page 10: Important Note
Wear dust mask Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice TECHNICAL DATA Model WD010611400 Voltage 110-120V AC 220-240V AC Frequency 50-60Hz... - Page 11 1400W ANGLE POLISHER OPERATING INSTRUCTIONS Note: Before using the power tool, read the instruction manual carefully. 1. Intended use The machine is intended for sanding, polishing and brushing metal and coated surfaces as well as for polishing stone without the use of water. 2.
-
Page 12: Maintenance
1400W ANGLE POLISHER turned in the direction of 6. And lower speed is obtained when it is turned in the direction of 1 (See Fig 7). The required speed depends on the material and the working conditions and can be determined through practical testing. -
Page 13: Troubleshooting
1400W ANGLE POLISHER brush results in motor trouble. To inspecting or replacing the carbon brushes, use a screwdriver to remove the brush holder caps (See Fig 10 ). Take out the carbon brushes (See Fig 11). If it becomes worn to or near “wear limit” (See Fig 12), replacing the new ones, reinstall the holder cap firmly. Note: Both carbon brushes should be replaced at the same time. -
Page 14: Explosive View
1400W ANGLE POLISHER EXPLOSIVE VIEW... -
Page 15: Part List
1400W ANGLE POLISHER PART LIST DESCRIPTION Q’TY DESCRIPTION Q’TY Polishing plate Stator Spindle Motor housing Woodruff key Screw Dust cap Brush holder cap Screw Carbon brush Gear box cover Brush holder Bearing Decorating ring Circlip Right handle Gear Screw Sleeve bearing Switch trigger Circlip Variable speed controller... - Page 16 MADE IN CHINA Copyright @ WIDO Machinery Co., Ltd. All rights reserved. www.widopt.com...
