Bellman & Symfon BE1260 Quick Start Manual

Pager charger
Buttons and controls
Charger brackets
Charging pins Charging LED

Technical specifications

In the box
BE1260 Pager charger with
pre-mounted backup batteries
External power supply
1 1.2 V NiHM rechargeable battery
intended for the pager
Supporting legs and screws + plugs
Charging LED
Green light: The pager is charging
No light: The pager is fully
charged or the power supply is not
connected to mains power.
Warning! When using the pager charger ONLY USE RECHARGEABLE NiMH BATTERIES in the pager.
Non-rechargeable batteries will start to leak if the pager is placed in the charger and the battery acid will
damage the electronics. The resulting damage is not covered by warranty.
2 bed shaker jacks
Power and battery
Mains power: 8 VDC / 800 mA
Battery power
4 1.2 V NiMH rechargeable batteries
Note: The backup batteries must be
changed at a service center.
Pager charging time
Normal charging time: ~ 6 h
W. depleted backup batteries: ~ 24 h
Vibrator power: 2.0 – 4.0 VDC
Environment
For indoor use only
BE1270 bed shaker
Supporting legs
Dimensions and weight
Height: 78 mm, 3"
Width: 88 mm, 3.5"
Depth: 43 mm, 1.7"
Weight: 385 g, 16.3 oz. incl. batteries
Accessories
BE1270 Bed shaker
Connects up to two bed shakers
BE9086 External trigger cable
Use output B
BE1260
