Installation Manual
Netra™ 20 Adjustable Rackmount
Installation Guide
For the Sun™ Rack
Sun Microsystems, Inc.
4150 Network Circle
Santa Clara, CA 95054 U.S.A.
650-960-1300
Part No. 816-7774-10
November 2002, Revision A
Send comments about this document to: docfeedback@sun.com
Advertisement
Related Manuals for Sun Microsystems Netra 20
Summary of Contents for Sun Microsystems Netra 20
- Page 1 Netra™ 20 Adjustable Rackmount Installation Guide For the Sun™ Rack Sun Microsystems, Inc. 4150 Network Circle Santa Clara, CA 95054 U.S.A. 650-960-1300 Part No. 816-7774-10 November 2002, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 LOOK GUIs and otherwise comply with Sun’s written license agreements. Use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth in the Sun Microsystems, Inc. license agreements and as provided in DFARS 227.7202-1(a) and 227.7202-3(a) (1995), DFARS 252.227-7013(c)(1)(ii) (Oct. 1998), FAR 12.212(a) (1995), FAR 52.227-19, or FAR 52.227-14 (ALT III), as applicable.
- Page 3 Guide This guide describes the procedure for fitting the adjustable telescopic slide rackmount kit to the Netra 20/Netra™ T4. It also describes how to install the Netra 20 in a Sun Rack. Note – The Netra 20 was originally known as the Netra T4.
- Page 4 1. Press in the button on the slide. Slide (in two parts) Glide Dismantle the Slide FIGURE 1 2. Pull the glide completely out of the slide. 3. Repeat for the other slide. Netra 20 Adjustable Rackmount Installation Guide • November 2002...
- Page 5 4. Using four of the M4 × 8mm panhead Phillips screws supplied, screw the glide to the side of the system chassis. 5. Repeat for the other glide. Fixing the Glides to the System Chassis (Netra 20/Netra T4) FIGURE 2 Adjustable Rackmount Installation Guide...
- Page 6 2. Loosely attach the front bracket to the rear bracket using four M4 screws. Securing the Slides to the Brackets FIGURE 3 3. Extend the brackets and attach them to the ousides of the front and rear rack mounting rails using M6 screws. Netra 20 Adjustable Rackmount Installation Guide • November 2002...
-
Page 7: Installing The System
4. Extend the slides and secure the slides in the required position. From the inside, screw the M6 panhead screws into the pem nuts in the brackets. 5. Push the slides completely into the assembly on each side of the rack and release the stop catches. - Page 8 Sliding the System into the Rack (Netra t 1120/1125 and Sun 72-inch expansion rack shown) FIGURE 4 Netra 20 Adjustable Rackmount Installation Guide • November 2002...
- Page 9 Flange Mount Assemblies 3 off M5x8 counter- sunk Phillips screws per flange (supplied) Flange Mount Assembly (Netra 20/Netra T4) FIGURE 5 Adjustable Rackmount Installation Guide...
- Page 10 Netra 20 Adjustable Rackmount Installation Guide • November 2002...
