Page 1: User Manual
USER MANUAL S-325 Project Workstation by Gear4music THANK YOU FOR CHOOSING THE S-325 WORKSTATION BY GEAR4MUSIC, WHEN YOU OPEN THE BOX, PLEASE CHECK THE PARTS AND UNDERSTAND THEIR FUNCTIONS... - Page 2 ASSEMBLY INSTRUCTIONS Join the two side legs together using the support cross bar as illustrated below.
- Page 3 2) Now assemble the speaker stands using the wooden shelves provided. Align the speaker bracket square with the shelf, and tighten the screws to fix the shelf into position. (Be careful not to over tighten the screw as this may cause damage to the shelf)
- Page 4 3) Attach the top cross bar Select the correct speaker height for both speaker stands before securing the cross bar...
- Page 5 4) Attach the lower shelf brackets to the lower support cross bar.
- Page 6 5) Fit the lower shelf on to the attached brackets. (Be careful not to over tighten the screw as this may cause damage to the shelf)
- Page 7 Before placing any equipment on the workstation please check all the screws and fixtures to Make sure they are securely fixed FOR MORE INFORMATION PLEASE CONTACT GEAR4MUSIC Sales@gear4music.com...
