- Page 1 Owner´s Manual IP Cameras & Domes GBR-IC02 Ceiling Flush Mount Adapter GBR-IC02.21.1.28.07.2011 © ASP AG...
- Page 3 Content: 1. Introduction 2. Package Contents & Needed Items 3. Installation 1. Introduction The Indoor Dome Cameras GCI-H0522V and GCI-K0322V can be mounted with this optional Ceiling Flush Mount Adapter. The items and tools needed for the in-ceiling installation are listed as follows. 2.
- Page 4 Step 2: Press both sides of the Inner Cover and remove it from the Dome Camera unit. Step 3: Unscrew the module-fastened screw, as indicated in the picture. Step 4: Press the sides of the snap-on module, as indicated in the figure, and detach it from the Dome Camera’s housing.
- Page 5 Step 6: Attach the Camera Housing Base to the Flush Mount Adapter’s top plate, aligning the camera’s rear cable entry with the entry hole on the Flush Mount Adapter’s top plate. Step 7: Align the three Captive Screws with the mating screw holes on the Camera Housing Base.
- Page 6 Step 10: Secure the Unit to the ceiling. Do not over- tighten the 3 fixing screws. If you use a power tool, the slip clutch should be set to the lightest setting or the clamps could be damaged. Step 11: The Flush Mount Adapter’s Wing Clamps will draw the Dome Camera Housing to the ceiling board until it is completely flush with...
- Page 7 Step 13: Tighten the Module-fastening Screw. Step 14: Connect the Ethernet cable to the camera’s network connector. Please refer to the Camera Quick Guide for details regarding the Camera Connector Definition. Step 15: Reinstall the Plastic Inner Cover. Step 16: Close the Dome Cover and tighten the two Security Screws.
- Page 8 Step 17: Align the 3 holes in the Trim Ring with the retaining Nut on the Flush Mount Adapter and snap the Trim Ring in place to complete the installation. Specifications GBR-IC02 Suitable for GCI-H0522V; GCI-K0322V Body material Steel Colour...
