1. Power Switch : ON/OFF
2. Led Light: ON/OFF
3. Master Volume: Adjust from Min to Max
4. Bass Knob: Adjust from Min to Max
5. Treble Knob: Adjust from Min to Max
6. Echo Knob: Adjust from Min to Max
7. MIC Volume Knob: Adjust from Min to Max
8. Microphone Input 1
9. Microphone Input 2
10. Power Supply: DC 9V 1.5A
BACK PANEL
1
8
4
11
15
16
17
18
2
5
6
7
10
20
19
11. AUX IN
12. USB Slot
13. TF Card Slot
14. Battery Indicator Light
15. Mode Button: Toggle between USB, TF,
FM, AUX, BT
16. Previous Track Button: Select previous
track
17. Play/Pause Button
18. Next Track Button: Select next track
19. REC/PLAY
20. MIC Priority: ON/OFF
