- Page 1 STP 500 Default access data (HTML + SFTP): 192.168.0.120 User: admin Password: geheim...
-
Page 2: Table Of Contents
System menus ................26 User Management ..............26 Network ................28 OpenVPN ................30 Firmware ................31 - Backup: ................31 - Factory reset: ...............31 - Firmware update: ..............32 Reboot the system ..............33 Shut down the system ..............33 USB Functions ................33 - 2 - STP 500... - Page 3 - Copying media data to the device: .........33 - Reset network settings: ............34 - Reset administrator password: ..........34 - Firmware update via USB: .............34 Appendix ...................... 35 Transfer media data to the device ..........35 Media2TS – Converter Software ............36 - 3 - STP 500...
-
Page 4: Safety Regulations And Notes
Open Source software. In relation to the licensor the regulations on liability and warranty in these license terms apply for the whole software. The liability and warranty regu- - 4 - STP 500... - Page 5 Prior permission from the copyright owners may be required for certain public performances and certain commercial uses. You agree to indemnify and hold harmless GSS Grundig Systems GmbH and its Licensors against any breach by You of applicable copyright restrictions in connection with your use of the device.
-
Page 6: General Information
2.1 P aC k i n g C o n t e n t s 1 STP 500 1 Mains cables 1 Brief assembly instructions 2.2 m e a n i n g... - Page 7 LAN 1000-BASE-T: ............. 2 RJ45 socket Data rate: ................. ≤ 800 MBit/s Protocols: ............UDP (User Data Protocol), RTP (Real-Time Transport Protocol) USB sockets ..............2 x USB A 2.0 USB sockets ..............2 x USB A 3.0 - 7 - STP 500...
- Page 8 – by PC, tablet or smart OpenVPN phone with Internet access. Server —> When using mobile terminals – dependent on your mobile contract – additional connection costs / data transfer costs may also be incurred here. - 8 - STP 500...
-
Page 9: Streaming Interface
C e ov e rv i e w 3 4 5 6 Power switch (on/off) Reset IEC connector C14; connector for mains cable USB-A 2.0 interface USB-A 3.0 interface Configuration/WAN interface Streaming interface - 9 - STP 500... - Page 10 We recommend the use of lateral slide rails/component carriers in order to relieve the front panel. • Screw the unit with the mounting screws and the washer to the four cage nuts - 10 - STP 500...
-
Page 11: Configuration
• After the initial configuration, connect the configuration/WAN interface to the LAN network using a CAT-6 cable if you want to process content from the Internet or have remote access. - 11 - STP 500... -
Page 12: Initial Configuration
—> Example for IP address setting with Windows 7 operating system: • For the initial setup open the properties for TCP/IPv4 of the PC: > Control Panel > Network and Sharing Center > LAN connection > Properties - 12 - STP 500... - Page 13 > Internet Protocol Version 4 (TCP/IPv4) > Properties • Activate point "Use the following IP address". • Enter e.g. 192.168.0.2 for the IP address. • Enter for the Subnet mask 255.255.255.0. • Confirm the setting with "OK". - 13 - STP 500...
- Page 14 —> For further logins observe the menus System > Network, System > User Management and System > OpenVPN! —> The Overview window is displayed. —> Changes in the menus are only transmitted to the device when you click the button! - 14 - STP 500...
- Page 15 Via the Help menu you can call up the assembly instructions (PDF) as well as hints about the configuration of a multicast network (PDF). Herein the date and time of the last login is displayed. Select menu language (English/German) - 15 - STP 500...
-
Page 16: Perform Changes
C h a n g es Before leaving a menu, changes must be transmitted to the device. • Therefore click on button After that is displayed for a short time in the upper right corner. - 16 - STP 500... - Page 17 CCTV) a corresponding editing window is displayed ( ) or offered for selection for a new stream ( —> Notes on the columns … can be found below in the explana- tions of the editing windows of the various task types. - 17 - STP 500...
-
Page 18: Tasks Overview
—> If a file is no longer available, it is marked in the task overview ( file not found). —> The Converter for Media menu allows you to convert other file for- mats to the transport stream format (page 25). - 18 - STP 500... - Page 19 —> Please note the following Before leaving a menu, changes must be transmitted to the device. • Therefore click on button —> After that is displayed for a short time in the upper right corner. - 19 - STP 500...
- Page 20 Using the IPTV, IP-Radio/Web-Radio configuration window, you can transcode an IPTV stream or MP3 radio stream or an M3U playlist into the transport stream format in "real time" and output it as a multicast SPTS stream. Switch the stream on or off here. - 20 - STP 500...
- Page 21 —> Use the 239.x.y.z range! It is suitable for streaming TV content and must also be used for Panasonic Viera TVs. For x use only the range of 1…127. The range 0 ... 255 is available for y and z. - 21 - STP 500...
- Page 22 -> Please note the following Before leaving a menu, changes must be transmitted to the device. • Therefore click on button —> After that is displayed for a short time in the upper right corner. - 22 - STP 500...
- Page 23 - converts the signal into a SPTS stream according to the pa- rameters you have selected. —> Here you can, for example, transcode the AAC sound of a camera into MPEG-1 Audio Layer II (MP2). - 23 - STP 500...
- Page 24 -> Please note the following Before leaving a menu, changes must be transmitted to the device. • Therefore click on button —> After that is displayed for a short time in the upper right corner. - 24 - STP 500...
-
Page 25: Converter For Media
Activate the media files you want to transcode here and… … start the transcoding. —> Transcoding can be stopped with —> Transcodings are CPU intensive processes that can last up to the runtime of a media file. - 25 - STP 500... -
Page 26: System Menus
The e-mail is then sent to the user's e-mail address via the outgoing mail server of this e-mail account. —> Therefor the configuration interface must have access to the Internet. Enter the user name(s) here. - 26 - STP 500... - Page 27 If you have not entered an e-mail address for the administrator, the e-mail will be sent to the outgoing account Before leaving a menu, changes must be transmitted to the device. • Therefore click on button - 27 - STP 500...
-
Page 28: Network
The configuration interface and the streaming interface must be as- signed to different IP address ranges (factory setting 192.168.0.120 and 192.168.10.120)! Enter fixed IP addresses which are not yet assigned and are out of the DHCP range of the router. - 28 - STP 500... - Page 29 You can use the Hostname to call up the user interface without entering the IP address. To do this, enter the host name followed by ".local" in the browser (e.g. gss.local). If you operate several devices in the network, you must enter different names here.
-
Page 30: Openvpn
—> Via the ON/OFF button you can deactivate the OpenVPN service. —> Before leaving the menu, changes must be transferred to the device! Therefore click on button —> After that is displayed for a short time in the upper right corner. - 30 - STP 500... - Page 31 —> If you have forgotten your password, you can have a new password sent to you via the button (see User Management on page 26)! —> If you have forgotten your IP address, please refer to the USB func- tions (page 34) for resetting the network settings. - 31 - STP 500...
-
Page 32: Firmware
*.tar.gz update file + added notes —> Aborting the firmware update or interrupting the power supply dur- ing the update might in worst case result in a defect of the device! Update via USB: see USB functions (page 34). - 32 - STP 500... -
Page 33: Usb Functions
• Insert the USB stick into a USB interface. • The media data is automatically copied to the device. —> The following file types are supported: png, jpg, ts, mkv, avi, divx, mp4, mov, mpeg - 33 - STP 500... - Page 34 P dat e v i a • Copy the update file *.tar.gz into the root directory of an "empty" USB stick. • Insert the USB stick into a USB interface. The firmware update is performed automatically. - 34 - STP 500...
-
Page 35: Appendix
• Enter the login data and click on Login. When the connection was estab- lished you will find the directory of you PC on the left, the directory of the device on the right. • Copy the video file into directory mediafiles. - 35 - STP 500... - Page 36 • If necessary, in line Target you can change the destination path and the name for the converted file. • Open the configuration menu via button Configuration. • Select the desired Resolution (SD/HD720/HD1080) and the VideoCodec (mpeg2video = MPEG2; libx264 = MPEG4). - 36 - STP 500...
- Page 37 GSS Grundig Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 633 240 0 • Fax: +49 (0) 911 / 633 240 98 www.gss.de/en • info@gss.de CLASS CLASS Service: Phone: +49 (0) 911/ 633 240 90 • service@gss.de Alterations reserved.
