- Page 1 MAGNUM TIG THF 238 PRO INSTRUCTIONS MANUAL WARNING! FOR SAFETY REASON PLEASE READ AND UNDERSTAND THE FOLLOWING INSTRUCTIONS BEFORE FIRST USE OF THE DEVICE.
-
Page 2: General Instructions
1. General instructions Read the operating instructions! The operating instructions provide an introduction to the safe use of the products. An incorrectly performed installation can result in material damage and injure persons as a result. For this reason, we do not accept any responsibility or liability for losses, damages or costs arising from incorrect installation, improper operation or incorrect usage and maintenance or any actions connected to this in any way. -
Page 3: Safety Instructions
2. Safety instructions DANGER! Electromagnetic fields! The power source may cause electrical or electromagnetic fields to be produced which could affect the correct functioning of electronic equipment such as IT or CNC devices, telecommunication lines, power cables, signal lines and pacemakers. •... - Page 4 WARNING! Smoke and gases! Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to the ultraviolet radiation of the arc! • Ensure that there is sufficient fresh air! •...
- Page 5 CAUTION! Installation site! The machine must not be operated in the open air and must only be set up and operated on a suitable, stable and level base! • The operator must ensure that the ground is non-slip and level, and provide sufficient lighting for the place of work.
- Page 6 3. Applications Magnum THF 238 PRO is intended for tungsten electrode welding but also MMA welding. The device is made for metal arc welding of low-alloy, high-alloy, carbon steels, aluminium and its alloys, The manufacturer is not liable for damage caused by improper use of the device. 4.
- Page 7 4.2.1 Control panel description Welding mode selection button. Select desired welding mode by pressing the button. MMA – stick welding mode TIG HF – tungsten electrode welding with High Frequency arc ignition TIG Lift – tungsten electrode welding with lift arc ignition TIG welding features TIG Punkt –...
- Page 8 4.2.2 TIG welding parameters description Gas bottle symbol – Adjustment of a shield gas supply before arc ignition lp – Start amps. Start current lasts while welding pool creates than it ramps up to welding current. tn – Current ramping time. Setting the time it takes for start current to reach welding current value. lb –...
- Page 9 4.2.4 Spot welding (TIG Punkt) Spot welding in the device gives you an option to make short welds in a given time gaps. Using this feature there are fewer parameters to be set: pre gas, welding current ( Is ), pulse balance, post gas and a time gap between the welds.
- Page 10 Service centre does not cover the postage cost for sending the device for repairs or sending it back after repairs. Spaw S.C. – Service Centre ul. Kosiarzy 3 30-731 Krakow...
