January 2015
900946-001 Rev. 00
Included in this Package
The following items are included in this Media Player FRU package:
3
Qty.
Description
1
1- TouchTunes Media Player
1
2- HDMI male-to-male cable, 12"
2
3- Adhesive velcro pad sets, 1x2", black
1
4- Power-over-Ethernet (PoE) Injector (with power supply)
1
This document
Media Player Device Specifications
HDMI (to HDTV)
Electrical Specifications:
Power over Ethernet (802.3af PoE)
Voltage: 48V DC
Current: 100mA
Power: 5W
Media Player FRU
2
1
Status
USB Power
Reset
(not used)
USB Power
Voltage: 5V DC
Current: 1A
Power: 5W
4
Part #
700752-001
300919-012
401310-001
700764-001
900946-001
Ethernet
(to switch)
USB
(not used)
1 of 3
Advertisement
Related Manuals for TouchTunes Media Player FRU
Summary of Contents for TouchTunes Media Player FRU
- Page 1 January 2015 900946-001 Rev. 00 Media Player FRU Included in this Package The following items are included in this Media Player FRU package: Qty. Description Part # 1- TouchTunes Media Player 700752-001 2- HDMI male-to-male cable, 12” 300919-012 3- Adhesive velcro pad sets, 1x2”, black...
- Page 2 Installation Full installation instructions for the Media Player are provided as part of the Installation guides for the Note: services requiring a Media Player. If you are replacing an existing Media Player, disconnect all cables from the original Media Player, then re- connect these cables to the replacement.
- Page 3 The jukebox cannot output to both VIMs and Media Players simultaneously. Contacting TouchTunes Support If you need help with or have questions about this document, contact TouchTunes by: • Using the email links on the Contacts page on the TouchTunes Dashboard at https://operator.touchtunes.com.
