Monocrystalline Solar Panel
User Manual
110 Watt
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #53000
SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nature Power 53000
Summary of Contents for Nature Power 53000
- Page 1 Monocrystalline Solar Panel User Manual 110 Watt WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #53000 SAVE THESE INSTRUCTIONS...
-
Page 2: Important Safety Information
Important Safety Information Thank you for choosing a Nature Power Product. Save the receipt and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only. the distributor cannot be responsible for issues arising from modification. - Page 3 Cautions ● Never touch the end of output cables with your bare hands when the modules are irradiated. Handle wires with rubber-gloved hands to avoid electric shock ● Do not wear metallic jewelry when working on electrical equipment ● Product should be installed and maintained by qualified personnel ●...
-
Page 4: Parts List
Parts List Reference Part Description Quantity 110W Solar panel 11 AMP charge controller SAE-Battery clamp cable SAE-bare end cable Z-brackets Manual Technical Specifications Property Specification Maximum Power - Pmax 110 Watt Voltage at Pmax 18.9 V Open Circuit Voltage - Voc 22.31V Short Circuit Current - Isc 6.27A... - Page 5 Assembly Instructions Selecting the Correct Battery We do not offer batteries. However, please choose a 12 Volt rechargeable battery. Do not attempt to recharge non- rechargeable batteries. 6 Volt battery configurations may also be used if connected in series Negative to Positive. You may choose a Sealed Lead Acid battery, a Gel-Cell or a Deep Cycle 12 Volt battery.
- Page 6 Conn tin an n An inverter can be used to converting the 12 Volt energy created to 120 Volt Electricity. Inverter sizes and types vary depending on your power consumptions needs. Please call us to find a suitable inverter. itiona Solar Panels Connecting Go to www.naturepowerproducts.com for a larger selection of renewable energy products and accessories.
- Page 7 Cont o nt n Any solar panel that is rated 12 watts or higher requires the use of a charge controller. Nature Power Solar panels and charge controllers come equipped with easy j-plug adapters. The Amp Charge controller is designed to protect your 12 Volt batteries from being overcharge by high voltage surges and prevents discharging of the battery overnight.
-
Page 8: Troubleshooting
Trouble Shooting Charge controller not working after battery connected. Confirm that it is a 12V battery and the voltage is higher than 6.5V. Battery are not charging. 1, Check your controller and battery first of all，make sure your battery is available 12V battery. 2, Faulty connections The wires should always be water tight and insulated. - Page 9 Will this kit work with a 12V or 24V battery? This is a 12V battery charging system only. Please call Nature Power Customer Service for more 24V system configuration. How do solar system work? The panel's photovoltaic cells convert the energy in sunlight to electricity, the electricity is then stored in the battery and an inverter will allow you to plug in appliances.
-
Page 10: Limited Warranty
Limited Warranty Nature Power warrants our products to the original purchaser that this product is free from defects in materials and workmanship for the period of 1 year from date of purchase, 2 year warranted to generate up to 80% of rated power from date of purchase. In the case of product defect, contact Nature Power customer service to receive troubleshooting.
