Summary of Contents for WELDPRO CUT60Hsv
- Page 1 CUT60HsvCUT40Hsv LINLONG LIMITED Operator’s Manual www.weldpro.com...
- Page 2 Introduction Thank you for purchasing the W Weldpro CUT60Hsvplasma cutter. This machine is designed and built using the very best quality components to afford a great cutting experience and great performance. The purpose of the following information is to provide additional help and understanding for both the set up of this machine as well as for a better understanding of cutting in general.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY WARNING........................ 2 PRODUCT DESCRIPTION....................... 3 TWO YEAR WARRANTY......................4 TECHNICAL PARAMETERS....................5 INSTRUCTIONS FOR THE INSTALLATION................6 OPERATING ......................... 7 MAINTENANCE AND TROUBLESHOOTING................ -
Page 4: Safety Warning
SAFETY WARNING The safety notes contained in this manual are to ensure the correct use of the machinery and to prevent injury to the user or other persons. The welding machine was designed and manufactured with safety in mind. Please refer to the safety warning contained in the manual to avoid accidents. - Page 5 DANGER Please observe the following rules to avoid serious accidents • Never use the equipment for purposes other than welding. • Follow related regulations regarding the characteristics of the power source, choice of place, usage of high- pressure gas, storage, configuration, safe-keeping of the workpiece after welding and disposal of waste, etc. •...
- Page 6 WARNING The gases and fumes are hazardous to health, please wear personal protective equipment according to regulations • Wear exhaust equipment and respiratory protective equipment to prevent gas poisoning or choke. • Use suggested exhaust ventilation system and respiratory protective equipment to prevent injuries or poisoning by gas or dust.
- Page 7 ATTENTION For better work efficiency and power source maintenance, please note the following: • Take precautions to prevent toppling. • Never use welding equipment to unfreeze a pipe. • Lift the power source from side when using a forklift to avoid toppling. •...
-
Page 8: Product Description
PRODUCT DESCRIPTION Congratulations on your purchase. CUT40Hsv/60Hsv is equipped with the most internationally advanced inverter technology. First the 60Hz frequency is inverted to a higher frequency (a frequency over 100KHz) by the V-MOSFET. Then the voltage is reduced, the current is commuted, and the inverter power supply generates powerful DC welding current using the PWM technology. -
Page 9: Two Year Warranty
Weldpro will not be responsible in the event of a product failure, for lost time in operation or use of said product. Rather it will honor solely the product itself only. -
Page 10: Technical Parameters
TECHNICAL PARAMETERS Model CUT40Hsv CUT60Hsv Parameters 1 phase 1 phase 1 phase 1 phase Supply voltage (V) 115V±15% 230V±15% 115V±15% 230V±15% Frequency (Hz) Rated input current (A) Opencircuit voltage (V) Output current (A) 14-20 14-40 20-50 Output voltage (V) 85.6-92 85.6-96... -
Page 11: Instructions For The Installation
INSTRUCTIONS FOR THE INSTALLATION Power cord plug connection (please find installation diagram enclosed) Each machine has been equipped with a power cable which must be connected to the corresponding voltage class according to the input voltage of the cutting machine. If the cutting machine powered by voltage of 115V or 230V is connected to 400VAC, the inside components of the machine may burn out. - Page 12 Installation drawing for the CUT60/40Hsv Switch Switch...
- Page 13 OPERATION Current adjustment knob Pressure adjustment knob Current meter Positive outlet Power indicator light Socket of the torch switch Fault indicator Auxiliary arc Test/2T/4T control switch Gas electric system outlet Pressure meter display The panel pictures above are for reference only. If there is any inconsistency between the image and the actual machine, the actual machine will govern.
-
Page 14: Operating
OPERATING INSTRUCTIONS 1 Operating environment While the operation of the Weldpro 60 amp high frequency plasma cutter is relatively straightforward, there are a few tips and set-up preferences that will aid in the longevity of the machine and it’s consumables. -
Page 15: Maintenance And Troubleshooting
Avoid surging! The input voltage of the cutting machine must match the ranges provided on the main technical data sheet. The automatic voltage compensation circuit will prevent from exceeding the allowable range. If the input voltage is too high, that may damage components. - Page 16 Ensure that there is no high frequency leakage of 102/10kV. The relay is damaged. Input voltage is too low. The machine works properly, but no The pressure of air compressor is too high or too low. arc is generated. LINLONG LIMITED www.weldpro.com...
