POWERED SUBWOOFER
MSR800W
CONTENTS
CIRCUIT BOARD LAYOUT
DIMENSIONS
(寸法図)
CIRCUIT BOARDS
INSPECTIONS
OVERALL CIRCUIT DIAGRAM
Copyright (c) Yamaha Corporation. All rights reserved. PDF-K126
SERVICE MANUAL
(目次)
(総合仕様)
............................................................3
...................................................4
(特性図)
..................................................4
(パネルレイアウト)
(ユニットレイアウト)
......................................................................5
(結線図)
..............................................................6
(IC ブロック図)
................................................8
(分解手順)
...................................................12
(シート基板図)
......................................................................15
(検査)
(ブロックダイアグラム)
(回路図)
..............................5
......................................9
HAMAMATSU, JAPAN
'05.06

Advertisement

loading

Summary of Contents for Yamaha MSR800W

  • Page 1 BLOCK DIAGRAM (ブロックダイアグラム) このサービ スマニ ュ アルはエ コ パルプ (ECF : 無塩素系漂白パルプ) を使用 し ています。 OVERALL CIRCUIT DIAGRAM (回路図) This document is printed on chlorine free (ECF) paper. 011778 HAMAMATSU, JAPAN 200505-115500 Copyright (c) Yamaha Corporation. All rights reserved. PDF-K126 ’05.06...
  • Page 2 IMPORTANT NOTICE This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically Yamaha Products, are already known and understood by the users, and have therefore not been restated.
  • Page 3: Specifications

    All manuals and user guides at all-guides.com MSR800W ■ SPECIFICATIONS (総合仕様) • General specifications • 一般仕様 Type 形式 Powered Subwoofer パ ワー ド サブ ウーフ ァ ー Speaker unit........... 38 cm cone (8 Ω) ス ピーカーユニ ッ ト ......38cm コーン (8Ω)...
  • Page 4: Performance Graph

    All manuals and user guides at all-guides.com MSR800W ■ PERFORMANCE GRAPH (特性図) Cutoff Frequency 100Hz 90Hz –10 80Hz –20 –30 <SPL> –40 FREQUENCY (Hz) ■ PANEL LAYOUT (パネルレイアウト) • Rear Panel (リアパネル) 1 PHASE switch 1 PHASE スイッチ 2 POWER switch 2 POWER スイッチ...
  • Page 5 All manuals and user guides at all-guides.com MSR800W ■ CIRCUIT BOARD LAYOUT (ユニットレイアウト) INPUT AC INLET ■ DIMENSIONS (寸法図) φ35.0 250.0 590.0 600.0 521.0 Unit: mm (単位)...
  • Page 6: Wiring Diagram

    All manuals and user guides at all-guides.com MSR800W ■ WIRING DIAGRAM (結線図) • VERSION: U, H, B, A, O Connector Assembly 4P L=800 (束線) Connector Assembly 2P L=250 (束線) CN203 CN204 Connector Assembly 6P L=80 (束線) CN201 CN202 CN105 CN106...
  • Page 7 All manuals and user guides at all-guides.com MSR800W • VERSION: J Connector Assembly 4P L=800 (束線) Connector Assembly 2P L=250 (束線) CN203 CN204 Connector Assembly 6P L=80 (束線) CN201 CN202 CN106 CN105 CN102 CN101 CN302 INPUT HARM WOOFER Connector Assembly...
  • Page 8: Ic Block Diagram

    All manuals and user guides at all-guides.com MSR800W ■ IC BLOCK DIAGRAM (IC ブロック図) • TL072CP (AAX67450) • NJM2068L-D (AAX64880) INPUT: IC103 MIX: IC106, IC107, IC108, IC109 INPUT: IC102, IC104 Dual Operational Amplifier • NJM4580L (AAX67460) +DC Voltage Output A...
  • Page 9: Disassembly Procedures

    All manuals and user guides at all-guides.com MSR800W ■ DISASSEMBLY PROCEDURES ■ 分解手順 ウーファー(所要時間:10 分) Woofer (Time required: about 10 minutes) 1-1. [1] のネジ 6 本を外 し 、 ス ピーカーグ リ ルを外 し ます。 1-1. Remove the six (6) screws marked [1]. The speaker grille (図...
  • Page 10 All manuals and user guides at all-guides.com MSR800W Power Transformer 電源トランス (Time required: about 10 minutes) (所要時間:10 分) 3-1. Remove the amplifier assembly. (See procedure 2.) 3-1. ア ンプ Ass’y を外 し ます。 (2 項参照) 3-2. Remove the hexagonal bolt of the power transformer. The 3-2.
  • Page 11 All manuals and user guides at all-guides.com MSR800W MIX Circuit Board MIX シート (Time required: about 10 minutes) (所要時間:10 分) 6-1. Remove the two (2) rotation knobs from the rear panel 6-1. ロ ーテーシ ョ ン ノ ブ 2 個を外 し ます。 (図 2)...
  • Page 12 All manuals and user guides at all-guides.com MSR800W ■ CIRCUIT BOARDS (シート基板図) • AMP Circuit Board to MIX-CN106 to WOOFER to MIX-CN105 Component side (部品側)...
  • Page 13 All manuals and user guides at all-guides.com MSR800W • INPUT Circuit Board to MIX-CN104 OUTPUT INPUT/THRU HIGH PASS Component side (部品側)...
  • Page 14 All manuals and user guides at all-guides.com MSR800W • MIX Circuit Board to INPUT-CN103 PHASE (NORM/REV) PEAK/LIMIT POWER to AMP-CN204 LEVEL CUTOFF FREQ. to AMP-CN201 Component side (部品側) • SW Circuit Board • AC INLET Circuit Board • HARM Circuit Board (J model)
  • Page 15 All manuals and user guides at all-guides.com MSR800W ■ INSPECTIONS Measuring conditions 1-1. Measuring voltage: AC 120 V, 60 Hz (U) AC 230 V, 50 Hz (H, B) AC 240 V, 50 Hz (A) AC 220 V, 50 Hz (O) 8 Ω...
  • Page 16 All manuals and user guides at all-guides.com MSR800W Items Conditions Values Input Output Typical Limited 11 PEAK/LIMIT indicator activation level 100 Hz input LF OUTPUT 63 V 63±2 V (Speaker terminal) * 0dBu=0.775 V 2-4. PHASE switch Input 40 Hz as reference, then check that the phase changes by 180 degrees to accommodate the input signal when the PHASE switch is set to REV.
  • Page 17 All manuals and user guides at all-guides.com MSR800W ■ 検査 測定条件 1-1. 測定条件: AC100V、50/60Hz 1-2. 負荷抵抗: 8Ω / 電力容量 1000W 1-3. LEVEL コントロール: 最小 1-4. CUTOFF FREQ. コントロール: 最大(100Hz) 1-5. 室内温度: 24 ± 4 ℃ 検査 2-1. パワーオンミューティング時間: パ ワース イ ッ チを ON 後、 3 ± 1 秒にて ミ ュ ーテ ィ ン グが解除 さ れ、 リ レーが ON す る こ と を確認 し て く だ さ い。...
  • Page 18 All manuals and user guides at all-guides.com MSR800W 項目 条件 値 入力 出力 標準値 限界値 11 PEAK/LIMIT インジケーター LF OUTPUT 63±2V 100Hz 入力 点灯レベル (スピーカー端子) * 0dBu=0.775 V 2-4. PHASE スイッチ: 入力 40Hz を基準 と し 、 PHASE ス イ ッ チを REV に し た と き 、 入力信号に対 し 位相が 180°変化す る こ と を確認 し て く...
  • Page 19: Parts List

    All manuals and user guides at all-guides.com MSR800W POWERED SUBWOOFER MSR800W PARTS LIST ■ CONTENTS (目次) OVERALL ASSEMBLY(総組立) ..................2 AMPLIFIER ASSEMBLY(アンプ Ass’y) ................4 ELECTRICAL PARTS(電気部品) ..................6 Notes : DESTINATION ABBREVIATIONS Australian model South African model British model...
  • Page 20 All manuals and user guides at all-guides.com PEF-Top Hat (AAX67480) Use the adhesive tape cut in appropriate length. 適当な長さに切って使用します。 290.0 t=1.0 Adhesive tape Amplifier Assembly (See page 4) Ass’y アンプ ) ページ参照 Front Grille Assembly Ass’y フロントグリル...
  • Page 21 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 OVERALL ASSEMBLY 総 組 立 MSR800W Overall Assembly 総 組 立 総 組 立 Overall Assembly Overall Assembly 総 組 立...
  • Page 22 All manuals and user guides at all-guides.com...
  • Page 23 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 AMPLIFIER ASSEMBLY ア ン プ A s s ’ y Amplifier Assembly ア ン プ A s s ’ y   J...
  • Page 24 All manuals and user guides at all-guides.com MSR800W ■ ELECTRICAL PARTS (電気部品) REF NO. PART NO. DESCRIPTION 部 品 名 REMARKS QTY RANK 電 気 部 品 ELECTRICAL PARTS MSR800W Circuit Board INPUT シ ー ト I N P U T...
  • Page 25 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * R103 Carbon Resistor 1/4W 1% カ ー ボ ン 抵 抗 4715-203A-C AAX67690 * R104 Carbon Resistor 1/4W 1% カ...
  • Page 26 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * C170 Ceramic Capacitor 2200P 50V K セ ラ コ ン 150F-222K-K-II AAX68050 * C401 Electrolytic Cap. 50V 20% ケ ミ...
  • Page 27 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * C210 Mica Capacitor 500V J マ イ カ コ ン 150L-220J-K-OMNS AAX65610 * C211 Electrolytic Cap. 50V 20% ケ ミ...
  • Page 28 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * D211 Diode IN4004 AT ダ イ オ ー ド 4804-0040-2 AAX65330 * D212 Diode Stack FMU-22U 10A 200V ダ イ オ ー ド ス タ ッ ク...
  • Page 29 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * Q232N Transistor 2SC4883A FM20 ト ラ ン ジ ス タ 4858-83A0-5 AAX66190 * Q232P Transistor 2SA1859A FM20 ト ラ ン...
  • Page 30 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 * R269 Carbon Resistor 2.2K 1/4W 1% カ ー ボ ン 抵 抗 4715-222A-C AAX67710 * R270 Carbon Resistor 1/4W 1% カ...
  • Page 31 All manuals and user guides at all-guides.com MSR800W REF NO. PART NO. DESCRIPTION REMARKS QTY RANK 部 品 名 Power Transformer 電 源 ト ラ ン ス   J 1806-3849-0 AAX68430 Power Transformer 電 源 ト ラ ン ス   U...
  • Page 32: Block Diagram

    All manuals and user guides at all-guides.com ■ BLOCK DIAGRAM MSR800W INPUT IC101 IC102B MUTE +15Va +15V JK102 Q101 OUTPUT Q102 Q105 +15V HIGH PASS 100Hz – Q104 +4dB JK103 Q103 –15Va –15V OUTPUT ch A –15V (THRU) JK104 IC103A...
  • Page 33 All manuals and user guides at all-guides.com ■ MSR800W OVERALL CIRCUIT DIAGRAM 1/4 (AMP) MSR800W • D10XB20 (AAX65400) DIODE STACK C217 D204 R225 AMP: D238 100P R218 1SS133/176 R220 D208 D212 R204 R227 D206 UF4003 Q215 FMU-22U HSS82 R244 2SC3468...
  • Page 34 All manuals and user guides at all-guides.com ■ MSR800W OVERALL CIRCUIT DIAGRAM 2/4 (MIX) MSR800W C170 2200PF R184 R185 C168 2.2K 0.083U IC109A C148 100P OP AMP C153 R164 R170 IC108A C158 7.5K OP AMP R169 NJM2068L-D 0.1U IC107A 0.082U...
  • Page 35 All manuals and user guides at all-guides.com ■ MSR800W OVERALL CIRCUIT DIAGRAM 3/4 (INPUT) MSR800W INPUT C103 33P OUTPUT HIGH PASS R102 18K 100 Hz (+4 dB) IC101A JK102 NJM4580L R110 C102 NC3MAV R101 100U/16V R103 20K R104 R105 100K...
  • Page 36 All manuals and user guides at all-guides.com ■ MSR800W OVERALL CIRCUIT DIAGRAM 4/4 (AC INLET, SW, HARM) MSR800W AC INLET ※2 J101 Primary Secondary C101 TH101 1000P SCK-0512 T101 CN202 SWITCH JK101 CN101 SW102 W101A CN102 F101 to AMP-CN202 TH102 SCK-0512 POWER ※1...
