- Page 1 USER’S MANUAL AND TECHNICAL DESCRIPTION MAJESTIC II BED REV.09/2018...
- Page 2 Dear Customer: With our beds, you have chosen a product of our company made with the highest demands in terms of quality in its components, ensuring the fulfilment of all requirements throughout its useful life. Thanks to the careful selection of materials, the most modern production technology and precise work of our employees, our products and services are focused on ensuring the requirements of our customers and achieve their full satisfaction by providing safe, reliable and consistent functionality.
-
Page 3: Table Of Contents
User manual MAJESTIC II bed Index 1) Introduction......................................6 Delivery.....................................7 2) Safety instructions....................................7 3) Environment conditions..................................8 4) Technical parameters ...................................9 Power supply ................................11 Important information about EMC ........................12 5) Specifications of the variant................................17 6) Bed description..................................... - Page 4 List of figures ............................ 11 Figure N. 1- Electric connections MAJESTIC II bed .............................. 18 Figure N. 2- ..........................20 Figure N. 3- Equipotential connector Trendelemburg and reverse Trendelemburg positions..............25 Figure N. 4- Nurse panel ..............................26 Figure N. 5- Patient handset.
- Page 5 User manual MAJESTIC II bed Tables list Table N. 1- Technical parameters for Majestic II .............................. 9 ....................................10 Table N. 2- Bed dimensions ............................10 Table N. 3- Cables and electric components list Table N. 4- Guide and manufacturer declaration – electromagnetic emissions................13 Table N.
-
Page 6: Introduction
The articulated bed model MAJESTIC II is not designed for patients with mind illness diseases or to be used in operating theatres. Any other use of the Medisa bed that is not the planned one, excludes the Company for any liability. -
Page 7: Delivery
User manual MAJESTIC II bed WARNING: Medisa is not responsible of any harm, damage, injury or accident that may occur due to misuse, carelessness or negligence. Safety and product use instructions must be strictly followed Medisa reserves the right to modify this manual due to product upgrades or ... -
Page 8: Environment Conditions
During maintenance, use only proper and original components. Medisa will not be responsible of damages or injuries that may arise. Use only mattresses and accessories from Medisa; in the contrary, a malfunction may occur on the side rails adjustment, jeopardizing patient safety. ... -
Page 9: Technical Parameters
Mattress weight ± 20kg Accessories weight ±45kg Patient weight ± 215 (in application environments Mattress weight ± 20kg Accessories ±15kg whatever is placed in the accessories NOTE: MAJESTIC II weight (standard) can vary depending on accessories or installed variation Page 9... - Page 10 Bed dimensions Approximate measures of standard beds Table N. 2 - Component/ Measures (cm) Specifications element Length Width ±1 cm Without packaging Length without bed extension. Optional bed Mattress 208-214 extension : +15 cm length Without bumpers or side rails ...
-
Page 11: Power Supply
User manual MAJESTIC II bed Electric connections Figure N. 1 – a) Power supply. The power supply is covered by a highly resistant plastic housing. Its main function is to convert the signals it receives from the patient's command and from the supervisor. -
Page 12: Important Information About Emc
• The MAJESTIC II electromedical equipment needs special precautions regarding electromagnetic compatibility (EMC) and needs to be installed and used according to the information contained in this documentation. -
Page 13: Table N. 4- Guide And Manufacturer Declaration – Electromagnetic Emissions
Table N. 4 – Guide and manufacturer declaration – electromagnetic emissions Electromanetic emissions The MAJESTIC II device it is intended for use in an electromagnetic environment specified below. The client or the user of the MAJESTIC II bed should ensure that it is used in said environment... -
Page 14: Table N. 5- Guide And Manufacturer Declaration – Electromagnetic Immunity 1
Table N.5 – Guide and manufacturer declaration – electromagnetic immunity Electromagnetic immunity The MAJESTIC II device it is intended for use in an electromagnetic environment specified below. The client or the user of the MAJESTIC II bed should ensure that it is used in said environment... -
Page 15: Table N. 6- Guide And Manufacturer Declaration – Electromagnetic Immunity - 2
To assess the electromagnetic environment due to fixed RF transmitters, a study of the electromagnetic site should be considered. If the measurement of the field strength at the location where the MAJESTIC II is used exceeds the applicable prior RF compliance level, the MAJESTIC II should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorientation or relocation of the MAJESTIC II. -
Page 16: Table N. 7- Recommended Separation Distances Between Portable And Mobile Rf Communications Equipment
Recommended separation distances between portable and mobile RF communications equipment and MAJESTIC II bed The MAJESTIC II bed is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or user of the MAJESTIC II can help prevent electromagnetic... -
Page 17: Specifications Of The Variant
5) Specifications of the variant The next features are the standard equipment, as well as the possibilities for personalizing bed MAJESTIC II. Standard equipment o Totally electric bed with columns height adjustment. -
Page 18: Bed Description
6) Bed description Figure N.2 – Majestic II bed COMPONENTS: 1. Round bumpers on each corner. 2. Four ABS sections cover, easily detachable C 3. Base. 4. Four 150 mm wheels. Central brake and steer. 5. Accessories sockets (for IV pole, lifting pole, Balkan beam, etc.). -
Page 19: Installation
User manual MAJESTIC II bed 7) Installation 1. Remove the packaging completely and dispose of it respecting the environment. 2. If beds are delivered in double package (two beds in the same pallet, one above the other) take out carefully the top bed and leave it on the floor. This process must be done by two person at least 3. -
Page 20: Connection To Power Supply
Note: The following label marks the connection position c. Battery charge As standard Equipment, MAJESTIC II bed includes battery. Before using the product, check that the battery is connected to the control box. Battery should be charged connecting the bed to the power supply. Charging process can be observed in the nurse panel. -
Page 21: Bed Adjustment
User manual MAJESTIC II bed Battery status signal (placed on nurse panel) Table N. 8- Orange warning light Battery condition The capacity of the battery is enough (complete charge 1. All levels on before use) Battery on charge, keep charging until end of lights blink. -
Page 22: Standard Movements
a. Standard movements. All accessible positions, as height or mattress adjustments, and individual positions, can be adjusted through nurse panel, patient handset, or buttons on side rails following the next procedure: 1. Press the selected key, and maintain it pressed to achieve the desired position. -
Page 23: Lower Leg Rest Section Adjustment
User manual MAJESTIC II bed iii. Lower leg section adjustment The multiple tilting positions are controlled by electric motor, within the defined ranges previously indicated. To adjust sections, press the appropriate button in the handset until the backrest reaches the desired position. -
Page 24: Programmed Positions Configuration
When height is adjusted with the side rails into its highest position, you must be check that any of the patient or anyone else body parts excels between the gaps on side rails or above them to avoid damages in any person While making these procedures, check that there are no objects above or under the mattress that can impede the height adjustment... -
Page 25: Figure N. 4- Trendelemburg And Reverse Trendelemburg Positions
User manual MAJESTIC II bed Security functions for positioning the patient into Trendelemburg or reverse Trendelemburg position. Sections achieve the horizontal position at the same time and the bed gets an inclination of maximum 16º regarding horizontal plane. This position only can be adjusted through nurse panel. -
Page 26: Nurse Panel
The effect of an unequal load and speed on lineal motors may produce a slight inclination once the height is adjusted. The downward inclination of the head could endanger the health of the patient; therefore, we recommend that you check the incline occasionally to align the position of both columns if necessary. -
Page 27: Locking Of Movements
User manual MAJESTIC II bed ii. Blocking of functions The bed allows disabling the individual positions configuration when any of them could harm the patient. For that, blocking keys are used in nurse panel in the following way: 1. Depending on the function that is desired to be blocked, press the lock key (number S14 on nurse panel) during 1 or 2 seconds. -
Page 28: Embedded Controls On Side Rails
D. Embedded controls on side rails (optional). Optionally, beds could include controls embedded into the side rails. Use them the same as previously described: Keys: 1-2: Backrest adjustment 3-4: Leg section adjustment 5-6: Auto contour: backrest and legrest sections adjust at the same time 7-8: Height adjustment 9: Cardiac chair position 10: Light: when pressed, the light under the bed is... -
Page 29: Automatic Auto-Regression Backrest System
12) Headboard and footboard MAJESTIC II bed is equipped with ABS headboards and footboards. They are easily detachable without tools, and have a system to block / unblock that avoids an accidental extraction. -
Page 30: Side Rails
To remove them, proceed in the opposite way 13) Side rails. MAJESTIC II bed is delivered with 4 split HDPE side rails, easily adjusted with one hand. Only original side rails can be used. Medisa is not responsible of the possible harm occasioned by other side rails or inadequate use of them. -
Page 31: Split Side Rails Adjustment
User manual MAJESTIC II bed If siderails are damaged, the bed cannot be used until side rails are replaced When the bed is adjusted with the side rails up, guarantee that the patient has no contact with side rails, and that any part of his body or of other... -
Page 32: Central Brake
Before adjusting the side rail checks that there are no objects that can impede it. 14) Central brakes. The bed is equipped with a centralized brake system that serves to facilitate the transport and handling of the bed by a single person and avoid possible injury to health personnel. -
Page 33: Bed Extension
User manual MAJESTIC II bed During bed transport, remember to disconnect it from the power supply and do not step on the cable. This cable must be hold in the hook placed in a safe place of the bed during transport. -
Page 34: Accessories
16) Accessories. Only Medisa accessories must be used for the bed. If you use other accessories the bed could be damaged and risk increases. In these cases, Medisa is not responsible of the consequences ACCESSORIES LIST Detachable Headboard and footboard... -
Page 35: Small Accessories Holder
Figures N. 18 and 18b- IV pole and monkey pole (example images) b) Small accessories holder MAJESTIC II bed is equipped with two series of hooks (placed on each side of the bed) for different types of accessories. Maximum load is 5 kg with zero leverage, and 10 kg for two hooks. -
Page 36: Other Accessories
Figure N. 20- 17) Sections covers extraction MAJESTIC II bed has four sections in ABS covers that protect the structure and electric components from dirt. Extracting these covers allows reaching the structure of the bed for cleaning and disinfection procedures. Once the covers are removed, it is possible to clean all metal components and mechanisms of the bed, as well as electrical components (motors, power box, battery box, the control unit and cables). -
Page 37: Cleaning Procedures
If you use incorrect detergents or disinfectants, do not respect our instructions regarding the dose and combination of other agents, or maintain the bed incorrectly, it could cause risks of which Medisa is not responsible. The person authorized by the maintenance service provider is responsible for the selection and application of an appropriate disinfectant. -
Page 38: Cleaning Recommendations
C. Cleaning recommendations. Cleaning recommendations Table N. 12- Cleaning Surface recommendations We recommend you to clean every day all those parts of the bed exposed to the effects of contamination, in particular, because of bare-hand contact and frequent use. Use a cloth with an appropriate cleaner or disinfectant to clean the sections of the Daily cleaning bed. -
Page 39: Maintenance Schedule
Table N. 16- Declaración del fabricante Medisa will provide to the service personnel that require it, diagrams, and list of components, descriptions, calibration instructions or other information that helps the service personnel to repair the parts of the equipment that can be repaired by the service personnel. -
Page 40: Technical Checking
The user can request Medisa's Technical Service to perform a preventive check of the bed every twelve months. Medisa will issue a certificate to these repair companies, which must carry out the verification, confirming it in the list of maintenance procedures performed. -
Page 41: Functional Checking Of Side Rails
User manual MAJESTIC II bed II. Functional check of the handrails The handrails must be checked in accordance with DIN EN 60601-2-52. Check that the locking mechanism of the handrails is working correctly and that there are no visible deformations or signs of wear on the handrails. -
Page 42: Functional Checking Of Brakes
III. Functional checking of brakes Check that all brakes Works correctly in all their positions (steering, brake and unbrake) IV. Motors functional check Actuate each motor from their beginning to the final way. Pay special attention to unusual noises, check speed, easy movement, etc. and check that the selected function goes in the appropriate direction. -
Page 43: Measures According To Din En62353
User manual MAJESTIC II bed In beds with a potential cable connection (see diagram below), the impedance of the potential equalization within the bed should also be measured. The impedance must be less than 0.2 Ω (I = 5 ... 25 A, R = U / I <0.2 Ω). -
Page 44: Storage
Problems and solutions Table N. 15- Description of the problem Cause Solution One control does not work; it’s The bed is not not possible to adjust height or connected to the power Check power supply sections. supply One control does not work; it’s The function is blocked not possible to adjust height or Check and unblock the... -
Page 45: Use Life And Environmental Protection
The MAJESTIC II bed does not contain or is composed of dangerous substances such as cadmium, mercury, and asbestos, PCB or CFC. In addition, the noise produced by the bed complies with the requirements of the Public Health protection regulations against the undesirable effects of noise and vibration in the internal protected areas of buildings. -
Page 46: Warranty And Service
a. Information for the user regarding electric and electronic equipment. This symbol on the product or on the documentation means that the electrical or electronic components used must not be discarded together with the community waste. To properly destroy the complete product return them to the places specified for this purpose, where they will be freely accepted. -
Page 47: Symbols
User manual MAJESTIC II bed Exclusions The guarantee does not cover the installation, start-up, cleaning, replacement or supply of any type of spare accessories. Moreover, this guarantee does not cover any damages caused by an Act of God or as a result of the following: improper installation, improper... -
Page 48: Finished Product Certificate
Equipotential DC current AC current Designed only for adult patients Warning of entrapment 25) Finished product certificate for MAJESTIC II bed. Order No.: Customer: Serial number: Date of acceptance I confirm that the maintenance staff and sanitary staff have been trained to use the bed. -
Page 49: Labels With Lot Numbers
User manual MAJESTIC II bed 26) Lot number label All the beds are identified by means of a label placed on the lower frame, under the ABS housing. When you contact the manufacturer or distributor (claims, technical service, and orders), provide them with the data included in the identification label:... -
Page 50: Declaration Of Conformity
28) Declaration of conformity Page 50...
