Pro-X XW-IS4 User Manual

Hide thumbs Also See for XW-IS4:

Advertisement

Quick Links

Download this manual
XW-IS4
Intercom System
Intercom System

Advertisement

loading
Need help?

Need help?

Do you have a question about the XW-IS4 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-X XW-IS4

Summary of Contents for Pro-X XW-IS4

  • Page 1 XW-IS4 Intercom System Intercom System...

  • Page 2: Table Of Contents

    Table of Contents 1. IMPORTANT INFORMATION ......1 2. SAFETY PRECAUTIONS ........1 3. STATEMENT ............2 4. OVERVIEW ............3-5 5. OPERATION ............6-9 6. TROUBLE SHOOTING ........10 7. PACKING CONTENT ........... 11...

  • Page 3: Important Information

    Important Information Read this user’s manual carefully before use and retain for future reference. The XW-IS4 warranty may NOT apply to below cases: ■ Repairs or product modification and alterations executed by unauthorized service personnel. ■ When damages caused by accidents include but not limited to lightning, water or fire.

  • Page 4: Statement

    ● With other devices working under the similar frequency nearby; Introduction XW-IS4 is a Full-Duplex wireless Intercom system. It's designed for operation of live show, program production, broadcast, and other applications where wireless communication is required. It features advanced digital wireless and Audio Codec technology to allow the director, camerapeople and control room communicate with each other freely without cables.

  • Page 5: Overview

    Front Panel of Base Station XLR Socket Auxiliary Audio Enable Button of All Channels for Headphone Enable Button Enable Button and (2nd Audio Voice Control Status Indicator of Input/Output) Enable Button IS-HS1 to IS-HS4/ IS-BP1 to IS-BP4 2-Wire/4-Wire Mute Button for Built-in Speaker Power Switch Selector Button...
  • Page 6 Control Panel of Wireless Headset (IS-HS) IS-HS Calls Base Station / IS-HS Registers on Base Station Indicator of Working Status MIC-Enable Button in Half Duplex 1.9G/1.8G Frequency Points Selector DIP Switch TALLY Light Jack Earphone Jack Power LED Power Switch Battery Box (AAA Battery×3) Volume Control Dial...
  • Page 7 Control Panel of Belt Pack (IS-BP) MIC-Enable Button in Half Duplex Volume Control Knob Headphone Jack Tally LED Tally Output Antenna Battery Box (AA Battery×3) or Nokia BL-5C Lithium-ion Battery Belt Pack Calls Base Station / CALL Belt Pack Registers on Base Station Power Switch 1.8G 1.9G 1.9G/1.8G Frequency...

  • Page 8: Operation

    Operation Installation 1.Check to be sure that frequency points are same selected on both IS-HS/IS-BP and Base Station. 2.Screw antennas on the back panel of Base Station. 3.Apply AC power to Base Station via AC power cord or power Base Station with a 10-20V DC power supply.

  • Page 9: Base Station

    Base Station 1.Logout/Registration Mode Press “MUTE” button and turn on the power switch in the same time, keep “MUTE” button pressed till 4 Channel status indicators flash quickly (200ms “ON”, 200ms “OFF”). Release “MUTE” button, Base Station is in Logout/Registration mode. 2.Logout In Logout/Registration Mode, the channel keeps previous registration information if its status indicator is on.
  • Page 10 Volume Control of Headphone/Speaker There are a 3-pin MIC socket and built-in speaker (1st Audio input/output) and a 4-pin Headphone socket (2nd Audio input/output) on Base Station. Volume level of MIC can be adjusted via “MIC LEVEL” dial. Volume level of Headphone and Speaker can be adjusted via “VOL”...
  • Page 11 2.Base Station communicates with all IS-HS/IS-BP in Half Duplex When the set works in Full Duplex, press “ALL” button to quit all IS-HS/IS-BP from intercom and the set works in Half Duplex. Base Station “CHx” status indicator stays on, IS-HS “SYS” LED stays on, IS-BP LCD displays “Half Duplex”. 3.Base Station communicates with selected IS-HS/IS-BP in Half Duplex When the set works in Full Duplex, press and hold Base Station “CHx”...
  • Page 12 Auxiliary Audio Input Press Base Station “AUX” button, the auxiliary audio input channel is enabled and “AUX” LED lights up. Press the button again, the auxiliary audio input channel will be disabled and “AUX” LED will be off. When “AUX” is on, Audio connected with this port will be input to the system. The Headphone or Speaker of Base Station outputs sound according to the position of “HEADPHONE/SPEAKER”...

  • Page 13: Troubleshooting

    Troubleshooting Fault Solutions Base Station cannot be 1.Make sure AC power cord is well inserted in a functional turned on power outlet 2.Check if the fuse under AC IN is broken The working distance 1.Check if antennas of Base Station are loose or broken being less than 250m and be sure they are installed in the right way or communication quality...
  • Page 14 Standard Packing Please check whether the following items are present in the package. If not, please contact your dealer. Item Quantity Remarks XW-IS4 Base Station Headphone IS-HS (XW-IS-HS) 4 selectable units of IS-HS /IS-BP in total IS-BP (XW-IS-BP) BL-5C Lithium Battery...
