Summary of Contents for Duux Ovi
- Page 1 evaporative humidifier user manual...
- Page 2 Don’t let his good looks distract you from its quality. Ovi provides the best of both worlds: great style with high performance humidification. Equipped with a 360° water filter, it removes calcium particles from the water and protects your humidifier against hard water stains to extend its lifespan.
-
Page 3: Table Of Contents
Table of contents 1. Product overview 2. Installation & use 3. Functions 4. Maintenance 5. Technical specifications 6. FAQ... -
Page 4: Product Overview
1. Product overview Max. water supply indicator Top cover Anti-bacterial filter Water supply Power entrance cable Power plug Aromatics tray Water Power / tray water supply indicator Power / mist output switch... -
Page 5: Installation & Use
2. Installation and use Note: Please take notice of below instructions Placement and the separately included warning sheet before Please place away from walls, windows and using the product. furniture. Installation • Please do not set up in a place where humidity Top: at least 100cm directly hits curtains, furniture, indoor plants or... -
Page 6: Filling The Water Tank
Filling the water tank • If there is interference with TV, radio or Note: Please check that the power is off other electrical devices, please move the before removing the water tank from the device. device. • When moving the device please move it Pour water in from the top, with the base of the device held securely placed in a watering can. - Page 7 Stop the water supply if the water supply entrance is closed with the water supply stop indicator. Attention: If water continues to be supplied after the water supply entrance is closed by the water supply stop indicator, water can spill over the top, enter the device and can cause a breakdown.
- Page 8 Connecting the product Put the power plug into a wall outlet. Caution: • Do not plug in the device or pull plug out of the power supply with wet hands or use the product. • Thoroughly dry your hands before you use the device, in particular after pouring water in the water tank.
- Page 9 Switch the power / humidifying switch to OFF after use and remove the power plug. Attention: When removing the power plug, please always do so while holding the power plug. If you remove the power plug by pulling the power cable, it can cause the power cable to break.
-
Page 10: Functions
3. Functions Note: see product overview (chapter 1) for Attention: When the water supply entrance is reference. closed, please do not supply water forcibly. It can lead to water getting into parts other than the water tray, Top cover which can result in the breakdown of the main body. The structure is such that the evaporated steam is spread efficiently. -
Page 11: Maintenance
4. Maintenance Important: Be sure to remove the power plug from the outlet before carrying out maintenance. Important: Do not soak immerse the power plug or the device in water. Important: We recommend daily maintenance to prevent the growth of bacteria and scale inside the water tank. - Page 12 Weekly maintenance (filter and main body) Note: If using on consecutive days, please carry out maintenance by applying the following procedure once a week. If this type of maintenance is not conducted, scale may form on the inside and shorten the life of the equipment or cause a breakdown.
-
Page 13: Spare Parts
Attention: Please do not use metal scourers, Immerse the removed filter in lukewarm melamine sponges, polishing powers, or solvents water below 40°C and dry in a place with like benzene, thinner, alcohol or other. proper ventilation with no direct sun light after washing. -
Page 14: Technical Specifications
5. Technical specifications Weight: 2.8 kg Power consumption: 6-19w Water tank capacity: Effective area: 258 mm Mist output: 200ml/h Max. operation time: Power cord length: 1.5m Main materials: 307 mm The appearance ABS, PP and specification of the device may be Model no.: changed without DXHU01... -
Page 15: Faq
6. FAQ Q. How often should I replace my filter? Q. Strange noises accompany the use of the A. Depending on the hardness and amount of product. calcium in your tap water, we suggest to replace A. This device evaporates using a fan. Therefore, a your filter approx. every 3 to 6 months. After fan is constantly rotating during the operation this period it will become less effective in terms of this device and there are times you would... - Page 16 Designed in The Netherlands bij Duux International BV. Made in P.R.C. Duux International BV, P.O. Box 145, 5400 AC Uden Netherlands, www.duux.com © 2016 Duux. All rights reserved. DUUX® is a trademark of Duux International BV, registered in the EU and other countries.
- Page 17 • The warranty may only be invoked if you provide Duux with the original purchase receipt along with the • La garantie ne peut être invoquée si vous fournissez Duux ou son distributeur avec la preuve d’achat defective product.
- Page 18 En caso de que no se le ofrezca ninguna solución, se le solicita que se ponga en contacto con el van de babyfoon. Als deze niet in staat is het probleem op te lossen zullen zij contact opnemen met Duux Duux-Kundendienst in Verbindung.
