MCP6P-M2 Setup Manual
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses , and c an radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .

Advertisement

Table of Contents
loading

Summary of Contents for Biostar MCP6P-M2

  • Page 1 All manuals and user guides at all-guides.com MCP6P-M2 Setup Manual FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1: Introduction.............3 Before You Start..............3 Package Checklist..............3 Motherboard Features............4 Rear Panel Connectors............5 Motherboard Layout ............6 Chapter 2: Hardware Installation........7 Installing Central Processing Unit (CPU)........ 7 FAN Headers................
  • Page 3: Chapter 1: Introduction

    All manuals and user guides at all-guides.com MCP6P-M2 CHAPTER 1: INTRODUCTION EFORE T ART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable work ing environment with sufficient lighting.
  • Page 4: Motherboard Features

    All manuals and user guides at all-guides.com Motherboard Manual OT HERBOARD EAT URES SPEC Socket AM2 AMD 64 Architecture enables 32 and 64 bit computing AMD Athlon 64 / Athlon 64 FX / Athlon 64 Supports Hyper Transport and Cool=n=Quiet x2 / Sempron processors Supports up to 1 GHz Bandwidth Support HyperTransport...
  • Page 5: Rear Panel Connectors

    Board Size 190 mm(W) x 244 mm(L) Special RAID 0 / 1 / 0+1 / 5 support Features Biostar Reserves the right to add or remove support for OS Support Windows 2000 / XP / VISTA any OS With or without notice. ANEL...
  • Page 6: Motherboard Layout

    All manuals and user guides at all-guides.com Motherboard Manual OT HERBOARD AYOUT JKBMS1 JCFA N1 JATXP WR4 JKBM SPWR1 J US BPWR1 JUSB1 JATXP WR1 JUSBLAN1 JA UDIO1 nForce 6100-430 J US B3 JA UDIOF 1 JCDIN1 JUSB2 J US B4 L AN PCI-EX16 BIOS...
  • Page 7: Chapter 2: Hardware Installation

    All manuals and user guides at all-guides.com MCP6P-M2 CHAPTER 2: HARDWARE INSTALLATION (CPU) NST ALLING ENT RAL ROCESSING Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle.
  • Page 8 All manuals and user guides at all-guides.com Motherboard Manual Step 4: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1.
  • Page 9: Fan Headers

    All manuals and user guides at all-guides.com MCP6P-M2 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 10: Installing System Memory

    All manuals and user guides at all-guides.com Motherboard Manual NST ALLING YST EM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot.
  • Page 11 All manuals and user guides at all-guides.com MCP6P-M2 B. Memory Capacity DIMM Socket Total Memory DDR2 Module Location Size DIMMA1 256MB/512MB/1GB/2GB Max is 4GB. DIMMB1 256MB/512MB/1GB/2GB C. Dual Channel Memory installation To trigger the Dual Channel f unction of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pair, shown in the f ollowing table.
  • Page 12: Connectors And Slots

    All manuals and user guides at all-guides.com Motherboard Manual 2.4 C ONNECT ORS AND LOT S FDD1: Floppy Disk Connector The motherboard prov ides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk ty pes. This connector supports the prov ided f loppy drive ribbon cables.
  • Page 13 All manuals and user guides at all-guides.com MCP6P-M2 PCI-EX16: PCI-Express x16 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, f or an aggregate of 8GB/s totally. PCI-Express supports a raw bit-rate of 2.5GB/s on the data pins.
  • Page 14: Chapter 3: Headers & Jumpers Setup

    All manuals and user guides at all-guides.com Motherboard Manual CHAPTER 3: HEADERS & JUMPERS SETUP OW T O ET UP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 15 All manuals and user guides at all-guides.com MCP6P-M2 JATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground...
  • Page 16 All manuals and user guides at all-guides.com Motherboard Manual JUSB2/JUSB3/JUSB4: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC f ront panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) JUSB3...
  • Page 17 All manuals and user guides at all-guides.com MCP6P-M2 JAUDIO F1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC f ront panel. This header allows only HD audio front panel connector; AC’97 connector is not acceptable.
  • Page 18 All manuals and user guides at all-guides.com Motherboard Manual JSPDIF_O UT1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JCMO S1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting and the CMOS data, please carefully f ollow the procedures to avoid damaging the motherboard.
  • Page 19 All manuals and user guides at all-guides.com MCP6P-M2 JPRNT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK...
  • Page 20 All manuals and user guides at all-guides.com Motherboard Manual JUSBPWR1/JUSBPWR2: Power Source Headers for USB Ports Pin 1-2 Close: JUSBPWR1: +5V for USB ports at JUSB1/JUSBLAN1. JUSBPWR2: +5V for USB ports at f ront panel (JUSB2/JUSB3/JUSB4). Pin 2-3 Close: JUSBPWR1: USB ports at JUSB1/JUSBLAN1 are powered by +5V standby v oltage.
  • Page 21: Chapter 4: Raid Functions

    All manuals and user guides at all-guides.com MCP6P-M2 CHAPTER 4: RAID FUNCTIONS PERAT ION YST EM Supports Windows XP Home/Prof essional Edition, and Windows 2000 Prof essional. 4.2 R RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 22 All manuals and user guides at all-guides.com Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 23 All manuals and user guides at all-guides.com MCP6P-M2 RAID 0+1: RAID 0 drives can be mirrored using RAID 1 techniques. Resulting in a RAID 0+1 solution for improved performance plus resiliency. Features and Benefits ­ Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
  • Page 24 All manuals and user guides at all-guides.com Motherboard Manual RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
  • Page 25: Chapter 5: Useful Help

    All manuals and user guides at all-guides.com MCP6P-M2 CHAPTER 5: USEFUL HELP RIVER NST ALLAT ION OT E After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance.
  • Page 26: Award Bios Beep Code

    All manuals and user guides at all-guides.com Motherboard Manual BIOS B WARD Beep Sound Meaning One long beep followed by two short Video card not found or v ideo card beeps memory bad High-low siren sound CPU overheated System will shut down automatically One Short beep when system boot-up No error found during POST Long beeps every other second No DRAM detected or install...
  • Page 27: Troubleshooting

    All manuals and user guides at all-guides.com MCP6P-M2 5.4 T ROUBLESHOOT ING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable.
  • Page 28: Appendencies: Spec In Other Language

    All manuals and user guides at all-guides.com Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Spezifikationen Sockel AM2 Die AMD 64-Architektur unterstützt eine 32-Bit- und AMD Athlon 64 / Athlon 64 FX / Athlon 64 64-Bit-Datenverarbeitung x2 / Sempron Prozessoren Unterstützt Hyper Transport und Cool’n’Quiet Unterstützt HyperTransport mit einer Bandbreite von bis zu 1 GHz...
  • Page 29 190 mm (B) X 244 mm (L) Sonderfunkti Unterstützt RAID 0 / 1 / 0+1 / 5 onen Biostar behält sich das Recht vor , ohne Ankündigung OS-Unterstüt Windows 2000 / XP / VISTA die Unterstützung für ein Betriebssystem zung...
  • Page 30: France

    All manuals and user guides at all-guides.com Motherboard Manual RANCE SPEC Socket AM2 L'architecture AMD 64 permet le calcul 32 et 64 bits Processeurs AMD Athlon 64 / Athlon 64 FX Prend en charge Hyper Transport et Cool’n’Quiet / Athlon 64 x2 / Sempron Prend en charge Hyper Transport jusqu'à...
  • Page 31 Fonctionnali tés Prise en charge RAID 0 / 1 / 0+1 / 5 spéciales Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows 2000 / XP / VISTA support de SE avec ou sans préavis.
  • Page 32: Italian

    All manuals and user guides at all-guides.com Motherboard Manual T ALIAN SPECIFICA Socket AM2 L’architettura AMD 64 abilita l a computazione 32 Processori AMD Athlon 64 / Athlo n 64 e 64 bit FX / Athlon 64 x 2 / Sempro n Supporto di Hyper Tra nsport e Cool’...
  • Page 33 Caratterist iche Supporto RAID 0 / 1 / 0+1 / 5 speciali Sistemi Biostar si riserva il diritto di aggiungere o operativi Windows 2000 / XP / VISTA rimuovere il supporto di qualsiasi sistema supportati operativo se nza pre avviso.
  • Page 34: Spanish

    All manuals and user guides at all-guides.com Motherboard Manual PANISH Especificación Conector AM2 La arquitectura AMD 64 permite el procesado de 32 y Procesadores AMD Athlon 64 / Athlon 64 64 bits FX / Athlon 64 x2 / Sempron Soporta las tecnologías Hyper T ransport y Cool’n’Quiet Admite HyperTransport con un ancho de banda de hasta1 GHz Conjunto de...
  • Page 35 Funciones Admite RAID 0 / 1 / 0+1 / 5 especiales Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows 2000 / XP / VISTA soporte de cualquier SO con o sin aviso previo. operativo...
  • Page 36: Portuguese

    All manuals and user guides at all-guides.com Motherboard Manual ORT UGUESE ESPECIFICAÇÕES Socket AM2 A arquitectura AMD 64 permite uma computação de 32 Processadores AMD Athlon 64 / Athlon 64 e 64 bits FX / Athlon 64 x2 / Sempron Suporta as tecnologias Hyper Transport e Cool’n’Quiet Suporta a tecnologia HyperT ransport com uma largura de banda até1 GHz...
  • Page 37 Característi Suporta as funções RAID 0 / 1 / 0+1 / 5 especiais Sistemas A Biostar reserva-se o direito de adicionar ou remover operativos Windows 2000 / XP / VISTA suporte para qualquer sistema operativo com ou sem suportados...
  • Page 38: Polish

    All manuals and user guides at all-guides.com Motherboard Manual OLISH SPEC Socket AM2 Architektura AMD 64 umożliwia przetwarzanie 32 i 64 Procesor AMD Athlon 64 / Athlon 64 FX / Athlon 64 bitowe x2 / Sempron Procesory Obsługa Hyper T ransport oraz Cool’n’Quiet Obsługa HyperT ransport o szerokości pasma do1 GHz Chipset...
  • Page 39 190 mm (S) X 244 mm (W) płyty Funkcje Obsługa RAID 0 / 1 / 0+1 / 5 specjalne Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows 2000 / XP / VISTA odwoływania obsługi dowolnego systemu operacyjne operacyjnego bez powiadomienia.
  • Page 40: Russian

    All manuals and user guides at all-guides.com Motherboard Manual USSIAN СПЕЦ Гнездо AM2 Архитектура AMD 64 разрешат ь обработка данных (центральн Процессоры AMD Athlon 64 / Athlon 64 на 32 и 64 бит ый FX / Athlon 64 X2 / Sempron Поддержка...
  • Page 41 Специальн ые технически Поддержка RAID 0 / 1 / 0+1 / 5 е характери с тики Biostar сохраняет за собой право добавлять или Поддержка Windows 2000 / XP / VISTA удалять средства обеспечения для OS с или без предварительного уведомления.
  • Page 42: Arabic

    All manuals and user guides at all-guides.com Motherboard Manual RABIC ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻡﻘﺒﺲ‬AM2 ‫ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔ‬AMD 64 ‫ﺏﺖ‬ ‫و‬ ‫إﺝﺮاء اﻟﻌ ﻤ ﻠﻴﺎت ا ﻟﺤﺎﺳﻮﺏﻴﺔ ﺏﺴﺮﻋﺔ‬ ‫وﺣﺪة ا ﻟﻤﻌ ﺎ ﻟﺠﺔ‬ ‫ﻡﻌ ﺎ ﻟﺠﺎت‬AMD Athlon 64 / Athlon 64 FX / ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬Hyper T ransport ‫ و‬Cool’n’Quiet ‫اﻟﻤﺮآﺰﻳﺔ‬...
  • Page 43 ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬RAID 0 / 1 / 0+1 / 5 ‫ﻡﺰاﻳﺎ ﺥﺎﺹﺔ‬ ‫ارﺗﻔﺎع‬ ‫ﻡﻢ‬ ‫ﻋﺮض‬ ‫ﻡﻢ‬ ‫ﺣﺠﻢ اﻟﻠﻮﺣﺔ‬ Windows 2000 / XP / VISTA ‫ﺗﺤﺘﻔﻆ‬Biostar ‫ﺏﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إز ا ﻟﺔ اﻟﺪﻋﻢ ﻷ ي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺏﺈﺥﻄﺎر أو ﺏﺪون إﺥﻄﺎر‬ ‫دﻋﻢ أﻥﻈﻤﺔ ا ﻟﺘﺸﻐﻴﻞ‬...
  • Page 44: Japanese

    All manuals and user guides at all-guides.com Motherboard Manual APANESE 仕様 AMD 64 アーキテクチャでは、32ビットと64ビット計算が可 Socket AM2 能です AMD Athlon 64 / Athlon 64 FX / Athlon 64 ハイパートランスポートとクールアンドクワイアットをサポ x2/ Sempron プロセッサ ートします 1GHzのバンド幅までハイパートランスポート をサポートします チップセット nForce 6100-430 DDR2 DIMMスロット x 2 デュアル...
  • Page 45 All manuals and user guides at all-guides.com MCP6P-M2 仕様 SATAコネクタ 各コネクタは1つのSATAデバイスをサポートします フロントパネルコネクタ フロントパネル機能をサポートします フロントオーディオコネクタ フロントパネルオーディオ機能をサポートします CDインコネクタ CDオーディオイン機能をサポートします S/PDIFアウトコネクタ デジタルオーディオアウト機能をサポートします CPUファンヘッダ CPUファン電源装置(スマートファン機能を搭載) システムファンヘッダ システムファン電源装置 CMOSクリアヘッダ 各コネクタは2つのフロントパネルUSBポートをサポートし USBコネクタ ます 電源コネクタ(24ピン) 電源コネクタ(4ピン) PS/2キーボード PS/2マウス VGAポート 背面パネル シリアルポート LANポート USBポート オーディオジャック ボードサイズ 190 mm (幅) X 244 mm (高さ) RAID 0 / 1 / 0+1 / 5 のサポート...
