Biostar M7TDB Datasheet

Biostar M7TDB Datasheet

Engineering validation test report
Hide thumbs Also See for M7TDB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
E
NGINEERING
CHANGE CONTROL
Description of Change
Initial Release
Project:
M7 TDB Intel 845 For Pentium 4/Socket 478 ATX Motherboard
Date:
2001/9/24
Owner:
Biostar Group
Contact:
TEL: 886-2-2218-0150 FAX: 886-2-2218-1552
Home Page:
1
M7 TDB
V
ALIDATION
COVER SHEET
Revision
0.91
1.1
1.2
http://www.biostar.com.tw
T
R
EST
Sections/Pages Affected
EPORT
Date
2001/5/24
2001/7/2
2001/7/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7TDB and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar M7TDB

Summary of Contents for Biostar M7TDB

  • Page 1 COVER SHEET CHANGE CONTROL Description of Change Revision Sections/Pages Affected Date Initial Release 0.91 2001/5/24 2001/7/2 2001/7/20 Project: M7 TDB Intel 845 For Pentium 4/Socket 478 ATX Motherboard Date: 2001/9/24 Owner: Biostar Group Contact: TEL: 886-2-2218-0150 FAX: 886-2-2218-1552 Home Page: http://www.biostar.com.tw...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT INFORMATION ..............4 Motherboard General Information................4 Chipset Details......................4 BIOS Details........................4 CPU Supports ......................4 Memory Supports ......................4 On-board Features and Devices...................4 Mechanical........................5 DESIGN REVIEW ..................7 Mainboard Voltage Measurement ................7 Bus Clock ........................7 REQUIRED BIOS DEFAULT SETTINGS..........8 BIOS FEATURES SETUP..................8 CHIPSET FEATURES SETUP...................8 POWER MANAGEMENT SETUP ................8 PnP / PCI CONFIGURATION..................9 INTEGRATED PERIPHERALS ................9...
  • Page 3 Joystick ........................40 Keyboard ........................41 LAN Card ........................41 Memory ........................42 Modem Card ......................43 Mouse ........................43 Power Supply......................43 Printer ........................44 Scanner ........................44 SCSI Card ........................44 Sound Card ........................45 LAN HUB........................45 USB HUB ........................45 Display Card ( 4X only ) ...................45 ZIP/LS120 .........................46 Monitor ........................46 SOFTWARE COMPATIBILITY LIST..........

  • Page 4: Product Information

    PRODUCT INFORMATION Motherboard General Information Vendor Biostar Model Number M7 TDB Version Number V0.91/V1.1/V1.2 Platform Micro ATX Flex ATX FCC Logo CE Logo Chipset Details System Chipset Vendor Intel North Bridge Revision RG82845 South Bridge Revision FW82801BA Super I/O Chip Vendor...

  • Page 5: Mechanical

    ATA-3 Compliance ATAPI Compliance Ultra DMA 33 Support Ultra DMA 66 Support ATA-100 Support USB Connector Support AGP 4X Slot Support Support AGP SideBand Addressing Mode Power on By LAN Infrared Support Enhanced Parallel Port DMI Compliance Hardware Monitor Support ACPI v1.0/APM v1.2 Compliance On-board Graphics Controller On-board Network Adapter...
  • Page 6 Daughter Card Slot in PCB None Excellent Fair Poor Wake-on LAN connector in PCB None Excellent Fair Poor Wake-on Modem connector in PCB None Excellent Fair Poor CD Audio-in Connector in PCB None Excellent Fair Poor AUX Audio-in Connector in PCB None Excellent Fair...

  • Page 7: Design Review

    DESIGN REVIEW Mainboard Voltage Measurement Voltage List Voltage SPEC Voltage Measured Result Battery Voltage 3.0V 3.14 Pass Battery Current 2.8 uA Pass 5.0V+-5% 5.11 Pass +12V 12.0V+-5% 11.56 Pass -5.0V+-5% -5.09 Pass -12V -12.0V+-10% -11.93 Pass +3.3V +3.3V+-5% 3.37 Pass Bus Clock Clock Frequency Spec Value (MHz)

  • Page 8: Required Bios Default Settings

    REQUIRED BIOS DEFAULT SETTINGS Lists Specification Result BIOS FEATURES SETUP Virus Warning Disabled Pass CPU L1 & L2 Cache Enabled Pass Quick Power On Self Test Enabled Pass HP370/ SCSI Boot Priority HP370,SCSI Pass First Boot Device Floppy Pass Second Boot Device HDD-0 Pass Third Boot Device...

  • Page 9: Pnp / Pci Configuration

    Video Off Method DPMS Pass Video Off In Suspend Pass Suspend Type Stop Grent Pass Modem Use IRQ Pass Suspend Mode Disabled Pass HDD Power Down Disabled Pass Soft-off by PWR-BTN Instant-off Pass PWRON After PWRT-Fail Former-Sts Pass CPU THRM-Throttling Pass Wake-Up by PCI Card Disabled...

  • Page 10: Pc Health Status

    AC97 Audio Auto Pass AC97 Modem Auto Pass Init Display First Pass Onboard FDC Controller Enabled Pass Onboard Serial Port 1 3F8/IRQ4 Pass Onboard Serial Port 2 2F8/IRQ3 Pass UART Mode Select Normal Pass RxD , TxD Active Hi , Lo Pass IR Transmission Delay Enabled...

  • Page 11: Functionality

    FUNCTIONALITY Setup Installation Test Of Operating System Pass/Fail DOS 6.22 Pass Windows 98 Second Edition Pass Windows ME Pass Windows NT 4.0 Workstation Pass Windows 2000 Per Pass Windows 2000 Server Pass Linux (Red Hat 7.1) Pass Windows XP Home Edition Pass Windows XP Professional Pass...
  • Page 12 Buzz None SMI Function Test SMI Pin Function Test Pass Time Out Function Test Pass Power LED Flash Check Pass CPU FAN Stop Check None Power On Control Power On By RTC Test Pass Power On By LAN Test (Intel SPD3) Pass Power On By Modem Test Pass...
  • Page 13 Plug-n-Play Test Pass Memory Parity Test Pass Pattern Test Pass Extended Pattern Test Pass Walking 1’s Test Pass Walking 0’s Test Pass Random Memory Test Pass Address Test Pass Refresh Test Pass Data Bus Test Pass IDE HDD Test Pass IDE CD Test Pass Drive Speed Test...

  • Page 14: Windows Me Operating

    I82557 Ethernet chip Pass Comments: Test Platform Windows ME Operating Comment Pentium 4 - 2.0 GHz Memory Kingston / Value RAM 256M *2 Quantum 40G CDROM BTC 52X Sound Card Onboard Video Card Power Color / TNT2 M64 CNR Card Lectron / PCTel CNR LAN Card Intel 82559...
  • Page 15 Wake Up By LAN Test Pass Wake Up By Ring Test Pass Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass Memory Comparability Test Running AVI Files With Multi Stress Pass Winstone 2001 Test Pass 3D Mark 2001 Test (Continue loop 10) Pass BCM Memory Test Pass...
  • Page 16 Add Joystick PnP Test Pass Add ZIP PnP Test Pass PCI Slots Test Add LAN Cards Test Login Server Test Pass Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass Power On By LAN Test Pass Wake On LAN Test (Standby Mode) Pass Shut Down By The LAN Test Pass...
  • Page 17 Netscape Browser Test Pass Connect to ISP For 12 hours Pass Download Files using AMR Modem (Over 10MB) Pass Modem Fax Function Test (Transmit a fax to Fax Machine) Pass Modem Fax Function Test (Transmit a fax to Modem) Pass Modem Fax Function Test (Receive a fax from Fax Machine) Pass Modem Fax Function Test (Receive a fax from Modem)
  • Page 18 3D Processing Pass 3D Quality Pass 3D WinMark Pass Playing *.AVI files (Stress Test for Over Night) Pass Audio Function Test Audio Drivers Setup Installation Test Pass System Properties Information Review Pass Audio Control Panel Function Test Pass CD-In Function Check Pass Game Port Test Pass...
  • Page 19 Voice 32 1.49 DirectSound3D CPU Util , 44.1 kHz , 16 bits Static Hardware Voice Voice 8 0.709 Voice 16 1.56 Voice 32 3.27 DirectSound3D CPU Util , 44.1 kHz , 16 bits Streaming Hardware Voice Voice 8 0.897 Voice 16 1.72 Voice 32 2.72...
  • Page 20 ZIP Driver Test Pass Memory Test Pass PCI Test Pass Video Test Pass AGP Test Pass SCSI Test Pass COM Loopback Pass Serial Port Internal Test Pass Parallel Port Internal Test Pass Parallel Port Loopback Pass USB Test Pass CMOS Test Pass Keyboard Test Pass...
  • Page 21 MultiMedia(Full Duplex Test(Win9x)) Pass Storage(MCI CD Test) Pass BIOS(Unreported I/O) Pass BIOS(Sysparse) Pass BIOS(Unreported Memory) Pass Legacy Free Test Pass Multimedia(Mixer Driver Test) Pass Multimedia(Wave Driver Test) Pass Video(Driver Scenario Test(PC99)) Pass Video(Driver Scenario Test) Pass Video(AGP Transfer Mode Test) Pass Video(AGP Interface Test) Pass...

  • Page 22: Windows2000 Operating

    Moto Racer 2 Pass Myst Pass Microsoft Midtown Pass Microsoft Motocross Pass Microsoft Age Of Empires Pass Microsoft Monster Truck Pass NBA Live99 Pass O.ZONE Pass Quake III Pass Red Alert Pass Rush Hour Pass RedLine Racer Pass SEGA Manx TT Pass SEGA Rally 95 Pass...
  • Page 23 Setup installation Microsoft Office 2000 Test Pass Hibernate(S4) Test Standby Button for S4 (Enter) Pass Power Button for S4 (Enter and Wake up) Pass Windows Set RTC Time out for S4 (Enter and Wake up) Pass Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass Wake Up By LAN Test Pass...
  • Page 24 Add LAN Card Test Pass Power On By LAN Test (Intel 82558B) Pass Wake On LAN Test (Standby Mode) Pass Shut Down By LAN Test Pass Add Sound Card Test Pass Add Modem Card Test Pass Wake On Modem Test (Standby Mode) Pass Add Digital Video Card Test Pass...
  • Page 25 Processor Test Pass Memory Test Pass Audio Test Pass Video Test Pass Graphics Test Pass Hard Disk Test Pass Floppy Disk Test Pass CD-ROM Test Pass Stress Test –Loop 100 Pass MS Mouse Pass MS Joystick Pass MS ScanDisk Pass Winbench 99 (1.2) Business Disk WinMark 99 Pass...

  • Page 26: Windows 98Se Operating

    Pass Others SYSmark 98 Pass Wintune 98 Test Pass SYSmark 2000 Pass Game Test 3D Pinball Pass Freecell Pass Minesweeper Pass Solitaire Pass Forsaken Pass Quake III Pass Age Of Empire Pass Comments: Test Platform Windows 98SE Operating Comment Pentium 4 1.9 GHz Memory MOSEL 128M X3 IBM DTLA –307030...
  • Page 27 Enter S3 mode For 1/5/10/30/60/120/720 Minutes Then To Do Wake Up Test. Pass Wake Up By LAN Test Pass Wake Up By Ring Test Pass Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass VGA Function Test VGA Drivers Setup Installation Test Pass Display Properties Information Review...

  • Page 28: Windows Xp (Home Edition ) Operating

    Disk WinMark Pass GDI/USER Inspection Tests Pass High-End Disk WinMark 99 Pass High-End Graphics WinMark 99 Pass Video Tests Pass Others BAPCo SYSmark 2000 Pass 3Dmark 2000 Pass Final Reality Pass WinTune 98 Test Pass WinDVD 2000 Pass Comments: Test Platform Windows XP (Home Edition ) Operating Comment Pentium 4 1.9 GHz...

  • Page 29: Windows Xp (Professional ) Operating

    2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winstone 2001 Business Winstone 2001 Pass Content Creation Winstone 2001 Pass Winbench 99 V1.2 Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass High-End Disk WinMark 99 Pass...

  • Page 30: Linux (Red Hat 7.1) Operating

    CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winstone 2001 Business Winstone 2001 Pass Content Creation Winstone 2001 Pass Winbench 99 V1.2 Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass...
  • Page 31 FDD Connector Test Read 1.44 Floppy Disk Pass Format 1.44 Floppy Driver Pass IDE Connectors Test CD-ROM Data Read Test Pass DVD-ROM Data Read Test Pass LAN Ports Test Peer to Peer Data Transfer Test Pass PCI Slots Test Add SCSI Card Test Pass Add LAN Card Test Pass...

  • Page 32: Reliability Test

    RELIABILITY TEST Motherboard General Information Vendor Biostar Model Number M7TDB Temperature rate ( ℃ ) 0 ~ 45 ℃ 0 ~ 60 % Humidity rate ( % ) Time ( hr ) 72 hr Windows Me Test Program Continuous Play DVD + Tomb2 DEMO...

  • Page 33: Over Clock Test

    OVER CLOCK TEST Test Platform Windows Me (FSB:100 MHz) Pentium 4 1.8 GHz Memory NEC 256M X3 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card ASUS V7700 CPU Front Side Bus Clock Winstone 2001 Business Winstone 2001 40.7 42.2 43.2...

  • Page 34: Performance Test

    PERFORMANCE TEST Test Platform Windows ME Memory NEC 256M X3 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card ASUS V7700 P4-1.5 GHz P4-1.7 GHz P4-1.8 GHz Winstone 2001 Business Winstone 2001 37.7 40.6 40.7 Content Creation Winstone2001 41.4 45.6 46.9...
  • Page 35 Test Platform Windows ME P4-1900 P4-2000 Memory MOSEL 128M X3 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card ASUS V7700 Winstone 2001 Business Winstone 2001 45.5 47.3 Content Creation Winstone2001 51.8 Comments: Winbench 99(1.2) Business Disk WinMark 99 6070 6050 High-End Disk WinMark 99...
  • Page 36 Test Platform Windows ME IBM DTLA 307030 ATA-100 30GB CD-ROM SONY CDU711 Sound Card Onboard Video Card ASUS V7700 Geforce 2 (1024x768x32bit) Motherboard M7 TDF M7 TDB P4-1.8G P4-1.9G P4-1.8G P4-1.9G (Northwood) (Willamette) (Northwood) (Willamette) Memory Samsung 256M DDR-266 NEC 256M SDRAM PC-133 Winstone 2001 Business Winstone 2001 48.7...

  • Page 37: Windows 2000 (Sp2)

    Test Platform Windows 2000 (SP2) Memory Nanya 512M X3 IBM DTLA-307020 ATA-100 CD-ROM PIONEER DVD-116 ATA-66 Sound Card On-Board CODEC Video Card Nvidia GeForce 2 PRO P4 -1.7 G P4- 1.8 G P4- 1.9 G P4- 2.0 G (Northwood) Winstone 2001 Business Winstone 2001 44.7 50.3...

  • Page 38: Hardware Compatibility List

    HARDWARE COMPATIBILITY LIST Vendor Model Frequency Type Result Intel Pentium 4 1500 MHZ/1.5G Socket 478 Pass Intel Pentium 4 1700 MHZ/1.7G Socket 478 Pass Intel Pentium 4 1800 MHZ/1.8G Socket 478 Pass Intel Pentium 4 1800 MHZ/1.9G Socket 478 Pass Intel Pentium 4 1800 MHZ/2.0G...

  • Page 39: Dvd-Rom

    Logitech QUICK CAM CD-Ver 4.1 Pass Logitech QUICK CAM HOME 1.0.3.1425 Pass Kodak DC240 Pass O’RIT M-318 CD-Ver 0.91 Pass Comments: DVD-ROM Vendor Model Transfer Rate Type Result CREATIVE DVD2240E ATAPI Pass CREATIVE DVD6240E ATAPI Pass CREATIVE DVD8401E ATAPI Pass CREATIVE DVD1242E ATA-33...

  • Page 40: Hdd

    Vendor Model Size Type Result FUJITSU MPD3108AT 10.8G ATAPI Pass FUJITSU MPG3307AT 30.7G ATA-100 Pass DJNA-370910 9.1G ATA-66 Pass DPTA-372050 20G1 ATA-100 Pass DNES-309170 9.1G SCSI Pass DCAS-34330 4.3G WIDE SCSI Pass DHEA-36481 6.4G ATA-33 Pass DHEA-DPTA-372050 ATA-33 Pass DTLA-307030 ATA-100 Pass DTLA-307020...

  • Page 41: Keyboard

    Logitech Wingman Pass Logitech Wingman Formula Force Pass Logitech Wingman extreme digital 3D Game Port Pass Microsoft Side Winder Feedback Pro Game Port Pass Microsoft Side Winder 3D Pro Game Port Pass Microsoft Side Winder Dual Strike Pass Microsoft Side Winder Joystick Pass RockFire QF-606U...

  • Page 42: Memory

    GFC2206 Pass Intel SB82558B Pass Intel GD82559 Pass Intel 82550EY SERVER Pass Comments: Memory Vendor Model Size Type Result Hitachi (Malaysia) 5264805FTT75 PC-133 Pass Hitachi (Malaysia) 5264805FTT75 128M PC-133 Pass HYUNDAI GM72V66841ET75 PC-133 Pass HYUNDAI GM72V66841ET75 128M PC-133 Pass Infineon HYB39S64800CT-7.5 PC-133 Pass...

  • Page 43: Modem Card

    Comments: Modem Card Vendor Model Drivers Type Result AZTECH MDP 3858SP-UE vxd 2.1.2135.7.1 PCI Pass AZTECH MDP 7800U 4.90.3000 Pass 3Com U.S Robotics 0637 vxd v1.00.017 Pass Lucent I56PSP-T3 7.66-9K-03 Pass 3Com U.S Robobit 56K FAX V 5.3 NAM Pass MDX-56KRE Pass WELL...

  • Page 44: Printer

    Comments: Printer Vendor Model Drivers Type Result CANON BJ-80K Ver 2.0 Pass EPSON STYLUS PHOTO 750 2.00.2452 USB /LPT Pass DeskJet 990Cxi Pass Deskjet 990 cxi V13.0 IrDA/LPT/USB Pass DeskJet 695C Pass Comments: Scanner Vendor Model Drivers Type Result Scan Jet 4200C CD-Ver 2.01 Pass MUSTEK...

  • Page 45: Sound Card

    Comments: Sound Card Vendor Model Drivers Type Result AVORTEX AU8820B2 4.05.0110 Pass CREATIVE Sound Blaster CT4670 Ver 2.0 Pass CREATIVE Sound Blaster SB0060 Ver 2.4 Pass CREATIVE ES1371 4.05.1119 Pass Ensoniq ES1370 4.02.1033 Pass Comments: LAN HUB Vendor Model Transfer Rate Result 3COM 100/10 Switch office400...

  • Page 46: Zip/Ls120

    DIAMOND Viper V770 Ultra RIVA TNT2 Ultra 4.12.01.0650 Pass ELSA GLORIA II NVIDIA Quadro 4.12.01.0650 Pass ELSA ERAZOR X Geforce256 4.12.01.0650 Pass ELSA ERAZOR Geforce 2 GTS 4.12.01.0650 Pass ERAZOR III LT-A32 ELSA RIVA TNT2 M64 4.12.01.0650 Pass GLADIAC ULTRA ELSA Geforce 2 ULTRA 4.12.01.0650...
  • Page 47 PHILIPS 107MP 17” Pass SAMPO AlphaScan 761 17” Pass SAMPO AlphaScan 712 a 17” Pass SAMPO AlphaScan 950 21” Pass OPTIQUEST Q100 19” Pass View Sonic E790 19” Pass View Sonic E810 19” Pass HITACHI SUPERSCAN 811 19” Pass Comments:...

  • Page 48: Software Compatibility List

    SOFTWARE COMPATIBILITY LIST Version Result MS-DOS 6.22 Pass IBM PCDOS Pass Windows Windows98 Second Edition Pass Windows ME 4.90.3000 Pass Windows NT Workstation Pass Windows 2000 Profession Release Pass Windows 2000 Server Release Pass Windows XP Home Edition Beta 2 Pass Windows XP Professional Beta 2...

  • Page 49: Vcore Waveform Measurement-Ver0.90

    VCORE WAVEFORM MEASUREMENT-Ver0.90 Finished Date: 90/05/14 CPU_1.75v setup 1. Select the RUN Button –changes to read “STOP” when operating. 2. Adjust the Toggle Frequency to the desired setting. 3. Adjust the Duty Cycle to the desired setting. 4. Adjust the Slew Rate to the desired setting. 5.
  • Page 50 Vcore Waveform RESULT PASS PS: 1. Transient and Static Waveform : VID setting : 1.75V , Icc :60A , Frequency : 2KHz 2. Static Test Range : +0mV~ -185mV 3. Transient Test Range : +0mV~ -185mV...

  • Page 51: Vcore Waveform Measurement-Ver0.91

    VCORE WAVEFORM MEASUREMENT-Ver0.91 Finished Date: 90/06/13 CPU_1.475v setup 1. Select the RUN Button –changes to read “STOP” when operating. 2. Adjust the Toggle Frequency to the desired setting. 3. Adjust the Duty Cycle to the desired setting. 4. Adjust the Slew Rate to the desired setting. 5.
  • Page 52 Vcore Waveform RESULT PASS PS: 1. Transient and Static Waveform : VID setting : 1.75V , Icc :60A , Frequency : 2KHz 2. Static Test Range : +0mV~ -185mV 3. Transient Test Range : +0mV~ -185mV Os-con 850μF...
  • Page 53 Vcore Waveform RESULT PASS PS: 1. Transient and Static Waveform : VID setting : 1.75V , Icc :60A , Frequency : 2KHz 2. Static Test Range : +0mV~ -185mV 3. Transient Test Range : +0mV~ -185mV GSC : 3300μF/6.3v...

  • Page 54: Vcore Waveform Measurement-Ver1.2

    VCORE WAVEFORM MEASUREMENT-Ver1.2 Finished Date: 90/07/10 CPU_1.475v setup 1. Select the RUN Button –changes to read “STOP” when operating. 2. Adjust the Toggle Frequency to the desired setting. 3. Adjust the Duty Cycle to the desired setting. 4. Adjust the Slew Rate to the desired setting. 5.

  • Page 61: Thermal Image Test - Ver 1.2

    THERMAL IMAGE TEST – Ver 1.2 Motherboard General Information Vendor Biostar Model Number M7TDB Revision Temperature ( ℃ ) 35 ℃ 0 ~ 60 % Humidity rate ( % ) Thermo Tracer NEC TH5104 Test Program 3Dmark2000 Comments: The component temperature measured value was based on 35℃ check in the...

  • Page 62: Four Corner Test

    FOUR CORNER TEST Test Equipment & Environment M/B TYPE M7TDB CPU Level P4 1.7GHz/100 RAM TYPE Winbond 128M pc133 x4 VGA TYPE ELSA GEFORCE2 ULTRA Power Supply FP ISR0007091 Floppy PANASONIC JU-257 IDE1 Primary QUANTUM CX6400AT IDE1 Secondary SEAGATE ST34321A...
