HDCVT TECHNOLOGY HDM-944H70 User Manual

Hdbaset 4x4 hdmi matrix over cat5e/6/7
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDBaseT 4×4 HDMI Matrix
over CAT5e/6/7
VER 2.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDM-944H70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HDCVT TECHNOLOGY HDM-944H70

Summary of Contents for HDCVT TECHNOLOGY HDM-944H70

  • Page 1 HDBaseT 4×4 HDMI Matrix over CAT5e/6/7 VER 2.0...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shook, lighting strikes, etc.

  • Page 3: Introduction

    1. Introduction The HD BaseT 4x4 HDMI Matrix with simultaneous CAT5e/6/7 and HDMI outputs connects four HDMI sources to eight displays. This matrix features four HDMI outputs and each HDMI output is mirrored to provide a CAT-Cable output which runs simultaneously. It supports the transmission of video (resolutions up to 1080p Full HD and 4Kx2K@30Hz) and supports high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio.

  • Page 4: Specifications

    4. Specifications Technical Video Bandwidth 297MHz[10.2Gbps] Support Video 480i,576i,480p,576p,720p,1080i,1080p24/30/50/60.4Kx2K@30; Resolution Input Ports 4×HDMI, 5×IR Receiver, 1×RS-232, 1xRJ-45(Control), 4x RS232 Output Ports 4×CAT5e/6/7, 4×IR Blaster, 4×HDMI HDMI connector Type A 19 pin female RJ-45 connector WE/SS 8P8C 3.5mm connector (TX and RX) IR Receiver/IR Blaster Human-body Model: ±...
  • Page 5 LOCK Press this button to lock all the buttons on the panel, press again to unlock OUTPUT/INPUT Press the OUTPUT and INPUT button to select the output corresponding input. For example: Press OUPUT ALL>INPUT 1, The OUTPUT A,B,C,D will be set to INPUT 1. Press PTP button, The OUTPUT A,B,C,D will corresponding INPUT 1,2,3,4.

  • Page 6: Rear Panel

    Why is EDID so important with the HDMI Matrix? The Matrix is complex piece of technology that replicates and switches between multiple inputs and outputs. Each connected source device will require one EDID to read. EDID management is carefully handled by HDMI Matrix to provide a single EDID for each source to read.

  • Page 7: Remote Control

    6. Remote Control 1. Press the button to power on the matrix or set it to standby mode. 2. Press the button to select output A for input 1,2,3 or 4 port. Press this button to select the previous input port and to select the next input port.
  • Page 8 attached directly to the front of inputs and covering infrared sensor windows of the source devices. Some later adjustment may be needed to the location of the sensor to achieve the best performance results - sometimes moving the sensor to different areas on the source can improve IR performance. NOTE: Infrared receiving areas of devices can be located by shining a flashlight onto the front of the device –...

  • Page 9: Hdbt Receiver

    8. HDBT Receiver Number Name Function description POWER This LED illuminates when the device is connected with power supply DC 24V Plug the 24V DC power supply into the unit. HDBaseT In Standard HD BaseT signal input port. Connect HD BaseT transmitter with a UTP cable.
  • Page 10 ※ Illuminate: The Transmitter and Receiver are in good connection Connection Signal Indicator Lamp status. ※ Flashing: The Transmitter and Receiver are in poor connection status. ※ Dark: The Transmitter and Receiver are not connected. ※ Illuminate: The HDMI signal with HDCP. Data Signal ※...
  • Page 11 ※ Description 2 GLOBAL IR control Application Example  TV remote can control all TV at the same time.  All DVD remotes can control DVD, but not at the same time.
  • Page 12 ※ Description 3 Bidirectional RS-232 control Application Example  This system provides 4 channel RS-232.

  • Page 13: Operate And Connect

    9. Operate and Connect Connect up to 4 sources such as a Blue-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI inputs on the unit. Do not hot plug! Insert and extract cables carefully with the power switch off.
