GLG Creator DLX IP65 RGBWAUV
Please read this manual before using.
General Information
(1) Product statement
First of all thank you for purchasing our GLG lighting product Creator DLX IP65 18*12W 6 in 1
outdoor slim par light, for your safety and better use of this product, please read the user manual
carefully before using, and strictly in accordance with the procedures, so as to avoid personal
safety or damage caused by the misuse of lamps and lanterns.
(2) Product introduction
18*12W RGBAW+UV 6 in 1 led, excellent cooling, great brightness, lower power consumption,
special 42mm lens, flicker free & very soft linear dimmer 0-100%, extremely heavy heat sink, very
strong structure, which has very long life span. 14, 7,8,9,3 channel mode for your optional, auto
run, sound active, DMX 512 & master slave.
www.goedlichtengeluid.nl
USER MANUAL
铝 ( 6 0 6 3 )
info@goedlichtengeluid.nl
GLG Lighting products
T E L ： 0 2 0 - 2 6 2 7 2 9 1 7
F A X ： 0 2 0 - 2 6 2 7 1 4 4 1
1
Advertisement
Table of Contents
Related Manuals for GLG Creator DLX IP65 RGBWAUV
Summary of Contents for GLG Creator DLX IP65 RGBWAUV
-
Page 1: User Manual
General Information (1) Product statement First of all thank you for purchasing our GLG lighting product Creator DLX IP65 18*12W 6 in 1 outdoor slim par light, for your safety and better use of this product, please read the user manual carefully before using, and strictly in accordance with the procedures, so as to avoid personal safety or damage caused by the misuse of lamps and lanterns. -
Page 2: Safety Instructions
This device is also designed for outdoor use. The fixture must be used in an area with good ventilation. The fixture can not be used directly into water nor in an area where rain will drop directly. Also GLG advise for long period use outdoor to protect the fixture with a water protecting cover. -
Page 3: Product Features
GLG Lighting products 1.Product features: * Mast slave. * DMX 512 * Multi kinds of DMX mode. * Auto run, master, DMX512, sound active, programming. * Parameters download between lights. * 16BIT Gray rate 16BIT * Fan’s speed automatic adjustable. - Page 4 GLG Lighting products 2.2 Menu www.goedlichtengeluid.nl info@goedlichtengeluid.nl...
- Page 5 GLG Lighting products www.goedlichtengeluid.nl info@goedlichtengeluid.nl...
- Page 6 GLG Lighting products 2.3 Static settings [STAT] * Press 【 E NTER 】 i nto stat setting at 【 S TAT 】 manu. * Press 【 E NTER 】 key to choose 【 R ed 】 【 G reen 】...
-
Page 7: Run Mode [Run]
GLG Lighting products menu. Note: When entering the sub-menu to adjust, if no DMX, this fixture is automatically set to be master, others are slave. 2.5 Run mode [RUN] * Choose [RUN] menu and press [ENTER] into [RUN] mode. * Press [UP]/[DOWN] to choose running mode. - Page 8 GLG Lighting products [STAG] [ARC.1] [AR1.d] [ARC.2] [AR2.d] [AR2.S] [HSV] For the exact channel value, pls check the DMX channel value sheet for reference. * Press 【 M ENU 】 r eturn back to the previous menu, the parameters that you choose can automatic save.
- Page 9 GLG Lighting products Note: when setting [Time] as 0, and not running this scene, and enter into next scene mean you close the running of this scene. 2.10 Fixture settings [SET] * At [SET] menu, and press [ENTER] into the fixture parameters settings, [UPLD] is automatically send, except address code and color correction parameters.
- Page 10 GLG Lighting products Press [UP/DOWN] to choose dimming speed. [OFF] dimming speed fastest. [DIM1] dimming speed fast. [DIM2] dimming speed slow. [DIM3] dimming speed slower. [DIM4] dimming speed slowest. * At [LED]] menu press [ENTER] to turn on/off of the display.
- Page 11 GLG Lighting products 2.11 Color temperature balance parameters [CAL1] * At [CAL1] menu, press [ENTER] into color temperature balance parameters settings. Press [UP/DOWN] to choose WT[01-11] to enter into. WT[01-11] has 6 color’s parameter for optional. 【 R ed 】...
- Page 12 GLG Lighting products Red 100%/ Green 0%/ Blue DOWN 131-150 Red 100%/ Green UP/ Blue UP 151-170 Red DOWN/ Green DOWN/ Blue 100% 171-190 Red 100%/ Green 100%/ Blue 100% 191-200 WHITE1:3200K 201-205 WHITE2:3400K 206-210 WHITE3:4200K 211-215 WHITE4:4900K 216-220 WHITE5:5600K...
- Page 13 GLG Lighting products 0-255 Auto run speed Preset dimmer speed. 10-29 fastest dimming speed. 30-69 fast dimming speed. 70-109 faster dimming speed. 110-169 slower dimming speed 170-255 slowest dimming speed choose or ID code at the same time 10-209 each 10 value corresponds to one ID.
- Page 14 GLG Lighting products 3.5 .DMX512 Channel sheet（AR2.d mode） Channel Value C ontrol function （ ） 0-255 Master dimmer 0-255 Green 0-255 Blue 0-255 White 0-255 Amber 0-255 0-255 No value 0-255 3.6 .DMX512 Channel sheet（AR2.S mode） Channel Value （ C ontrol function ）...
-
Page 15: Specifications
GLG Lighting products 3.8 .Specifications： GLG Creator DLX IP65 18PCS RGBWA+UV 6 in 1 LED *Voltage: AC100/240V, 50/60Hz *Power consumption: 270W *Light source: 18*12W (RGBWA+UV 6IN1) *lens angle: 25 degree, 42mm lens *Strobe: 0-16Hz, from slow to fast, adjusting *Electronic dimmer from 0 to 100%...
