1 – 1 Specifications
Type of fuel – Wood
For outdoor use only
Underwriters Laboratories Inc. Listed – 84E4
Electrical Rating 115 VAC/ 60 HZ / 1P
MFS-15 AMP, MCA-15 AMP
Clearance to Combustibles
Top, Rear, Sides
Chimney Connector
Front
Flooring
Water Capacity
H3 – Holds Approximately 100 Gallons of Water
H5 – Holds Approximately 130 Gallons of Water
H6 – Holds Approximately 60 Gallons of Water
Description
H3 – 120,000 BTU
H5 – 180,000 BTU
H6 – 100,000 BTU
Description
H3 – 120,000 BTU
H5 – 180,000 BTU
H6 – 100,000 BTU
HARDY MANUFACTURING CO., INC

SECTION I

GENERAL INFORMATION

18"
18"
48"
Non Combustible
HEATER DIMENSIONS
Wide Depth
30" 52 ½"
40" 52 ½"
30" 40 ½"
FIREBOX SIZES
Wide Depth
24" 32"
34" 32"
24" 24"
(MODEL H3, H5, & H6)
Height
59 ½"
59 ½"
51 ½"
Height
36" + 8" for Grates
36" + 8" for Grates
36" + 8" for Grates
Weight
650 lbs.
850 lbs.
475 lbs.
PAGE 1
