SurgeX SX1115RL Installation Instructions

SurgeX

Installation Instructions

SX1115RL

Mounting

The SurgeX SX1115RL is designed to be installed in a 19 inch equipment rack and

requires one unit (1-U) of rack space. Remove the product from its packaging and

slide it into place in the rack being careful to feed the power cord into the rack first

and guide it so that it does not get caught or jammed as the product is installed.

Use the four screws provided with the product to secure the rack ears to the rack

rails. These screws can be tightened by hand and do not require tools.

Connect power to the unit by plugging the cord into a 120V ac receptacle.

The SX1115RL has 8 receptacles on the rear panel: six switched, and two always

on. Each receptacle is rated for a maximum load of 15 amps, but the total load also

must not exceed 15 amps. Plug the equipment cords into the always-on and

switched receptacles as needed to power the equipment.

The always-on receptacles provide power as long as power is supplied to the

SurgeX and the AC voltage is within normal limits. The six switched outlets

provide power only when the front panel switch is on.
