TECSYSTEM NT538 ETH Instruction Manual page 7

TECHNICAL SPECIFICATIONS
Housing NORYL 94 _V0
Absorption 7,5VA
Digital linearity of sensor signal
Self-diagnostic circuit
Protection treatment of the electronic part
DISPLAY AND DATA MANAGEMENT
2x13mm displays with 3 digits to display temperatures, messages and channels
3 LEDs to display the state of the alarms of the selected channel (ALARM-TRIP-FAULT)
4 leds selection of display mode (SCAN-AUTO-MAN-T-MAX)
2 LEDs to display the state of FAN1 and FAN2
Temperature control from 0°C to 240°C (*)
1 alarm thresholds for each channels
1 Trip thresholds for each channels
2 ON-OFF thresholds for FAN 1 and FAN 2 in common for all enabled channels
Sensor diagnostics (Fcc-Foc-Fcd)
Data memory diagnostics (Ech)
Access to programming through front keyboard
Automatic exit from relay programming, display and test after 1 minute's inactivity
Incorrect programming warning
Selection between channel automatic scanning, hottest channel or manual scanning
Storage of maximum temperatures reached by channels and alarm status
Front key to reset the alarms
Voting function
Fail Safe function
(*) On demand, available version from -40°C to 200°C with alarm temperature management range from 0°C to 200°C
NT538 ETH
NT538 ETH
●
●
●
●
Option
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
