MOUNTING
Drill a 92 x 92 mm hole in the panel sheet.
1
1)
Control unit
3)
Identification label
Fix the unit securely with the blocks supplied.
1
1)
Control unit
2)
Fixing block
10
3
3
2
2
2)
Panel hole dimensions (+0.8mm tolerance)
3)
Fixing screw
4)
Cross-head screwdriver #1X100mm
NT538 ETH
1MN0007 REV. 0
4
1MN0008 REV. 0
