Installation Instructions for 81374
Sheet Metal Shears
18 Gauge Capacity
Save This Manual
Keep this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the
manual near the assembly diagram (or month and year of purchase if product has no number). Keep this
manual and the receipt in a safe and dry place for future reference.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
1-800-345-4545 jegs.com

Advertisement

loading

Related Manuals for Jegs 81374

Summary of Contents for Jegs 81374

  • Page 1 Installation Instructions for 81374 Sheet Metal Shears 18 Gauge Capacity Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.

  • Page 2: Table Of Contents

    Power tools create sparks which may ignite the dust or fumes. 3. Keep children and bystanders away while operating a power tool. Cluttered or dark areas invite accidents. Distractions can cause you to lose control. 1-800-345-4545 jegs.com...

  • Page 3: Safety

    Trigger is dangerous and must be repaired. 3. Disconnect the plug from the power source before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. 1-800-345-4545 jegs.com...
  • Page 4 3. If the blades jam, turn the Switch off immediately. 4. Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact JEGS. 5. Avoid unintentional starting. Prepare to begin work before turning on the tool.
  • Page 5 6. Grip tool as lightly as possible (while still keeping safe control of it). Let the tool do the work. 7. To reduce vibration, maintain the tool as explained in this manual. If any abnormal vibration occurs, stop use immediately. SAVE THESE INSTRUCTIONS. 1-800-345-4545 jegs.com...
  • Page 6 Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. 2. Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration. (See Outlets for 2-Prong Plug.) 1-800-345-4545 jegs.com...
  • Page 7 Alternating Current WARNING marking concerning Risk of Amperes Fire. Do not cover ventilation ducts. Keep flammable objects away. xxxx/min. No Load Revolutions/Minute (RPM) WARNING marking concerning Risk of electrical shock Properly connect power cord to appropriate outlet. 1-800-345-4545 jegs.com...

  • Page 8: Specifications

    Note: For additional information regarding the parts listed in the following pages, refer to Parts List and Diagram on page 14. Functions Power Switch Oil Port Power Cord Guide Upper Blade Lower Blade Figure A 1-800-345-4545 jegs.com...

  • Page 9: Operation

    3. Secure loose workpieces using a vise or clamps (not included) to prevent movement while working. There must not be objects, such as utility lines, nearby that will present a hazard while working. 1-800-345-4545 jegs.com...
  • Page 10 5. To cut material, fit the Guide over the edge of the material, and move the tool slowly forward along the desired cut line. 6. To prevent accidents, turn off the tool and unplug it after use. Clean, and then store the tool indoors out of children’s reach. Oil Port Area above Upper Blade Figure D 1-800-345-4545 jegs.com...

  • Page 11: Maintenance

    • cracked or broken parts, and • any other condition that may affect its safe operation. Sharpening Blades When sharpening the Blades, maintain original angles. (See Figure E) Upper Blade Upper Blade Lower Blade 12° 8° 4° Figure E 1-800-345-4545 jegs.com...
  • Page 12 4. Make a few practice cuts on scrap material before cutting your workpiece. WARNING! If the supply cord of this power tool is damaged, it must be replaced only by a qualified service technician. Upper Socket Screw Lower Socket Screw (not shown) 1-800-345-4545 jegs.com...
  • Page 13 See Extension Cords in Grounding section on page 6. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. 1-800-345-4545 jegs.com...

  • Page 14: Parts List And Diagram

    Hex Key (not shown) Gear Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. 1-800-345-4545 jegs.com...
  • Page 15 Assembly Diagram 1-800-345-4545 jegs.com...
