Summary of Contents for Avid Technology EXPANSION CHASSIS
- Page 1 N S T A L L I N G A N D S I N G AVI D E X P A N S I O N H A S S I S H A RDWA RE G U I D E .
- Page 2 Copyright and Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Avid Technology, Inc. The software described in this document is furnished under a license agreement. The software may not be reverse assembled and may be used or copied only in accordance with the terms of the agreement.
-
Page 3: Table Of Contents
SCSI IDs ....................4 Bus Termination ..................4 Cable Types and Lengths ................5 3D Effects System Restrictions ................5 Chapter 2 Populated Chassis Installation ......7 Before You Begin....................7 Checking the Kit Contents .................8 Testing the Macintosh.................8 Installing the Expansion Chassis................9 Connecting the Power Cord ...............9... - Page 4 Removing the Quadra 650 Cover ............23 Installing the Interface Card ..............24 Updating the Avid Configuration ROM........... 27 Removing the Expansion Chassis Cover ........... 29 Setting the NuBus ID Rotary Switches............. 31 Installing the NuBus Terminator .............. 32 Connecting the Interface Cable and Lock..........33 Connecting the AC Power Cord...............
- Page 5 Loading Software ..................48 Checking for an Available SCSI ID............48 Installing the 3D Effects Option ..............50 Powering Off the Macintosh and the Expansion Chassis......50 Using the Grounding Wrist-Strap .............50 Replacing the Expansion Chassis Cover ............51 Removing the Expansion Chassis Cover ..........51 Cutting the Shielding .................53...
- Page 6 ........71 Interface Card Problems.................. 72 Empty Chassis Problems ................. 73 Populated Chassis Problems ................74 3D Effects Option Problems................76 Appendix A Expansion Chassis Specifications ..79 Physical Dimensions ..................79 Environmental Specifications ................80 Power Supply Specifications ................80 Power Cord Specifications................
- Page 7 Figures Figure 1 Expansion Chassis and 3D Effects Cover (Rear View) ......2 Figure 2 AC Power Input on the Expansion Chassis ..........9 Figure 3 Interface Cable Connection ..............10 Figure 4 Interface Card and Cable Lock .............11 Figure 5 Interface Card and Cable Lock Insertion ..........11 Figure 6 Interface Card and Cable Locked Together ...........12...
- Page 8 Figure 41 Power Supply Connections ..............57 Figure 42 Connecting the Power Harness ............58 Figure 43 Expansion Chassis and 3D Effects Cover (Rear View) ......60 Figure 44 3D Effect SCSI ID Switch ..............60 Figure 45 Expansion Chassis and 3D Effects Cover (Rear View) ......61 Figure 46 SCSIProbe Results ................
- Page 9 Tables Table 1 Maximum Slots Available ................3 Table 2 Interface Card Slot Assignments ............26 Table 3 Power Macintosh 8100 Card Layout .............38 Table 4 Quadra 950 and Quadra 650 Card Layout ..........39 Table 5 Interface Card Problems ................72 Table 6 Empty Chassis Problems................73 Table 7 Populated Chassis Problems..............74...
- Page 10 C o n ten t s In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ss i s...
-
Page 11: Preface
This manual contains information for installing both the Avid Expansion Chassis and the Avid 3D Effects Option. Chapter 1 – Provides an overview of the Expansion Chassis and the 3D Effects Option. Chapter 2 – Describes how to install a populated Expansion Chassis when it is shipped as part of a new Avid systems. -
Page 12: Symbols And Conventions
Appendix A – Provides mechanical, electrical, environmental, and regulatory specifications for the Expansion Chassis and 3D Effect cover. Appendix B – Describes how to access and replace the two fuses in the Expansion Chassis. Symbols and Conventions This document uses the following special symbols and conventions: 1. -
Page 13: Chapter 1 Overview
The Avid 3D Effects Option is a set of three processor boards that enhance and extend the effects capabilities of the Avid software. The boards are housed in a penthouse cover that you add to the Expansion Chassis and attach to the Advanced JPEG card in the chassis. The 3D Effects Option components include: •... -
Page 14: Chassis Front And Rear Panels
The front panel of the Expansion Chassis has a power on/off switch and a power on indicator. Figure 1 shows the rear panel of the Expansion Chassis. It has an AC power input, a fuse holder, 12 standard NuBus slot openings, and an expansion panel. The expansion panel supports future connector options that use a larger than standard NuBus opening. -
Page 15: Macintosh Compatibility And Slot Limitations
NuBus architecture limitations (some slots in the Macintosh and the chassis are duplicates). For the Macintosh models that can connect to the Expansion Chassis, you can only use from nine to 13 slots between the Macintosh and the chassis. -
Page 16: Rack Mounting Options
Rack Mounting Options The Expansion Chassis, with or without the 3D Effect cover, can be mounted in a standard 19-inch rack. To ensure safe installation in a rack configuration, Avid recommends mounting the chassis in the lower half of the rack. A set of rack- mount slides are available from Avid for mounting the Expansion Chassis. -
Page 17: Cable Types And Lengths
A Power Macintosh 8100 or a Quadra 650/900/950 with a Power Macintosh upgrade card installed. For detailed instructions on performing this upgrade, see Installing Power Macintosh Upgrade Cards. • An Avid Expansion Chassis. For instructions on adding this hardware, see Chapter 4, “3D Effects Installation.” • An Advanced JPEG board. - Page 18 C h apt er 1 • O v er v i ew In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ssi s...
-
Page 19: Chapter 2 Populated Chassis Installation
Macintosh. Use the instructions in this chapter when you install a new Expansion Chassis and Power Macintosh for the first time. If you purchased your Expansion Chassis as part of an upgrade to an existing Avid system, go to Chapter 3,“Empty Chassis Installation,” to complete the installation. -
Page 20: Checking The Kit Contents
A NuBus terminator Testing the Macintosh Before you connect the Macintosh to the Expansion Chassis, test the Macintosh to make sure that it is functioning properly and that the interface card is properly installed. To test the Macintosh and the interface card: 1. -
Page 21: Installing The Expansion Chassis
To connect the power cord: 1. Insert the power cord into the AC power input on the rear panel of the Expansion Chassis (see Figure 2). 2. Plug the Expansion Chassis into the same power strip as the Macintosh. AC power input... -
Page 22: Using The Grounding Wrist-Strap
Using the Grounding Wrist-Strap Your Avid system ships with a reusable grounding wrist-strap. To prevent any dam- age to the Macintosh, the Expansion Chassis, or the interface card, you must wear the wrist-strap when handling the cards or connecting cables. -
Page 23: Figure 4 Interface Card And Cable Lock
The connectors on the interface cable and the interface card fit very tightly together. You’ll need to apply enough pressure to completely seat the connectors. Make sure that the cable is completely seated in the connector on the card before you continue. 4. -
Page 24: Connecting The External Cables
Connecting the External Cables All Power Macintosh systems have the Avid NuBus boards installed in the Expansion Chassis rather than being installed in the Macintosh. Throughout the hardware manuals, whenever you are instructed to connect a cable to a board in the Macintosh, you should now connect to that same board in the chassis. -
Page 25: Connecting The Scsi Cable
Enhancement card NuVista+ card SA 4 Audio card Figure 7: Expansion Chassis Rear Panel Connecting the SCSI Cable Connect the SCSI cable that attaches the Avid disk drives to the SE IV SCSI card (see Figure 7). This is a 68-pin high-density D connector. Tighten the thumb screws to secure the connector. -
Page 26: Connecting The Video Cables
SCSI connector 3D Effects cover Interface cable Figure 8: Expansion Chassis and 3D Effects Cover (Rear View) The 3D Effects cover is a SCSI device that attaches to the Macintosh built-in SCSI bus. To connect the 3D Effects cover: 1. Locate the 25-pin male to 25-pin male SCSI cable. It is approximately 30 inches long. -
Page 27: Figure 9 3D Effect Scsi Id Switch
3. Attach the other end of the cable to the SCSI connector on the back of the Macintosh. Tighten the thumb screws to secure the connector. The 3D Effects cover is a self-terminating SCSI device. It requires no external SCSI terminator. If you have other devices on the Macintosh SCSI bus, make sure that the 3D Effects cover is the last device in the SCSI chain. -
Page 28: Testing The Expansion Chassis
Testing the Expansion Chassis After you install the Expansion Chassis and connect all the cables, you need to test the chassis. Testing verifies that you have connected the Macintosh and the chassis correctly, and that the NuBus cards in the chassis are installed correctly and visible to the Macintosh. -
Page 29: Figure 10 Expansion View Text Slot Information Screen (Full Chassis)
If Text Slot Info does not report the correct information, fix any problems using “Populated Chassis Problems,” in Chapter 6. Then, repeat all the steps in “Testing the Expansion Chassis” on page 16 to ensure that the chassis is completely functional. - Page 30 C h apt er 2 • P o p u l a t e d C h a s s i s I n s ta l l a t i on In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ssi s...
-
Page 31: Chapter 3 Empty Chassis Installation
Empty Chassis Installation Avid ships an empty Expansion Chassis (with no NuBus cards) for all upgrades to existing Quadra 650/900/950 systems. You must install the interface card in the Macintosh and move the NuBus cards from the Macintosh to the Expansion Chassis. -
Page 32: Checking The Kit Contents
A NuBus terminator Loading Software Before you begin installing the Expansion Chassis, you need to load the latest Avid software. The software contains the latest version of the Expansion View utility (version 2.02 or later) that you’ll use to test the chassis during the installation. -
Page 33: Powering Off The Macintosh And Disconnecting Peripherals
Your Avid system ships with a reusable grounding wrist-strap. To prevent any dam- age to the Macintosh, the Expansion Chassis, the interface card, or any of the NuBus cards, you must wear the wrist-strap when handling the cards or connecting cables. -
Page 34: Removing The Power Macintosh 8100 Cover
Removing the Power Macintosh 8100 Cover To remove the Power Macintosh 8100 cover: 1. Loosen the four thumb screws on the rear panel of the Macintosh (see Figure 11). Thumb screws Thumb screws Figure 11: Power Macintosh 8100 Rear View 2. -
Page 35: Removing The Quadra 900/950 Covers
Removing the Quadra 900/950 Covers To remove the Quadra 900/950 cover: 1. Face the rear of the Macintosh and tilt it onto its right side (see Figure 13). 2. Push in the cover tabs and lift the cover up and off the computer. Cover tabs Figure 13: Quadra 900/950 Cover Removal Removing the Quadra 650 Cover... -
Page 36: Installing The Interface Card
To install the interface card: 1. Arrange your hardware so that the Macintosh and the Expansion Chassis are located within 12 inches of each other with the chassis on the right, as you face the front of the hardware. The interface cable is only 20 inches long and you’ll need to allow approximately 4 inches on each end for the cable to bend and to avoid damage. -
Page 37: Figure 15 Handling The Interface Card
2. Remove the following cards from your Macintosh and set them aside on a clean antistatic surface. These are the cards you are moving from the NuBus slots in the Macintosh to the NuBus slots in the Expansion Chassis. •... -
Page 38: Figure 16 Interface Card Slot Locations
Power Macintosh 8100 Quadra 650/900/950 If you are installing the Expansion Chassis on a Broadcast system, place the interface card in slot E in the Quadra 650. These systems also use Expansion View version 2.0x4. The NuBus card slot assignments in “Installing Quadra 650/900/950 NuBus Cards”... -
Page 39: Updating The Avid Configuration Rom
ROM. To update the configuration ROM: 1. Power on the Macintosh. The message “The Expansion Chassis is on a new machine.” appears on the screen. This message prompts you to check the switch settings in the Expansion Chassis. - Page 40 The switch settings are different for each Macintosh and Expansion Chassis combination. Check your switch settings carefully. You can’t set the rotary switches in the Expansion Chassis using the software. You must remove the Expansion Chassis cover and manually set each rotary switch.
-
Page 41: Removing The Expansion Chassis Cover
Removing the Expansion Chassis Cover To remove the Expansion Chassis cover: 1. Remove the two screws at the top front of the chassis using a flat-blade screwdriver (see Figure 17). 2. Lift the front of the cover slightly and slide it forward off the chassis. -
Page 42: Figure 19 Pcb Clamp
4. Locate the PCB clamp at the rear of the chassis interior (see Figure 19). PCB clamp Figure 19: PCB Clamp 5. Remove the three screws that hold the PCB clamp in place. 6. Lift the PCB clamp upward to remove it from the chassis. C h apt er 3 •... -
Page 43: Setting The Nubus Id Rotary Switches
Setting the NuBus ID Rotary Switches Each NuBus slot in the Expansion Chassis has a rotary ID selector switch. The switch has an arrow showing the current ID setting, and numbers and letters indicating the other possible settings for the slot (see Figure 20). -
Page 44: Installing The Nubus Terminator
When you remove the screwdriver, the arrow points to the current setting. Installing the NuBus Terminator The NuBus board in the Expansion Chassis needs to be terminated for the NuBus cards to function properly. To install the NuBus terminator: 1. Make sure that you are wearing the grounding wrist-strap. You must wear the wrist-strap while you are handling the NuBus terminator board. -
Page 45: Connecting The Interface Cable And Lock
Connecting the Interface Cable and Lock The interface cable connects the Macintosh to the Expansion Chassis. The cable lock holds the Expansion Chassis interface card and interface cable together, ensuring that the cable attaches properly to the interface card. To connect the interface cable and lock: 1. -
Page 46: Figure 23 Interface Card And Cable Lock
5. Locate the interface card lock (see Figure 23). Grasp the lock on the sides of the finger holds with your thumb and forefinger. Long straight tab Grasp here Finger holds Short bent tab Grasp here Figure 23: Interface Card and Cable Lock 6. -
Page 47: Figure 25 Interface Card And Cable Lock Insertion
Cable lock Interface card Interface cable Figure 25: Interface Card and Cable Lock Insertion 8. Push the lock flat against the cable connector and slide the bent end of the lock into the cutout (see Figure 26). Slide the cable lock as far as possible to the left. Cable lock Interface card Interface cable... -
Page 48: Connecting The Ac Power Cord
Figure 27: AC Power Input on the Expansion Chassis Testing the Empty Expansion Chassis Before installing any of the Avid NuBus cards, test the Expansion Chassis. To test the chassis: 1. Turn on the power to the Expansion Chassis. -
Page 49: Figure 28 Expansion View Graphic Slot Information Screen (Empty Chassis)
5. Locate the Expansion View application and run it by double-clicking the icon. 6. Choose Graphic Slot Information from the Expansion Chassis menu. You can display the same slot information in text format by choosing Text Slot Information from the Expansion Chassis menu. The Slot Info windows show slot information for both the Macintosh and the Expansion Chassis (see Figure 28). -
Page 50: Installing The Avid Nubus Cards
Installing the Avid NuBus Cards Install the Avid NuBus cards in the appropriate slots in the Expansion Chassis. The following sections describe the NuBus card layouts for each Macintosh. Before handling the NuBus cards, always discharge any static electricity by touching a grounded metal surface such as the Expansion Chassis case. -
Page 51: Installing Quadra 650/900/950 Nubus Cards
3. Install each NuBus card into its slots. Align the connector on the NuBus board in the Expansion Chassis and the connector on the NuBus card. Apply a gentle downward force until the card seats in the connector. -
Page 52: Reconnecting The External Cables
Enhancement card NuVista+ card SA 4 Audio card Figure 30: Expansion Chassis Rear Panel Note that your system may not have all of the NuBus cards shown here. Reconnecting the SCSI Cables Reconnect the SCSI cable that attaches the Avid disk drives to the SE IV SCSI card (see Figure 30). -
Page 53: Reconnecting The Audio Cables
Audio/Video Products manuals in your Avid Hardware binder. Testing the Populated Expansion Chassis After you install the Expansion Chassis and the NuBus cards, and connect all the cables, you need to test the chassis. Testing verifies that you have connected the Macintosh and the chassis correctly, and that the NuBus cards are installed correctly and visible to the Macintosh. - Page 54 8. Open the Avid drive, then open the Utilities folder. 9. Double-click the Expansion View icon to run the application. 10. Choose Text Slot Information from the Expansion Chassis menu. The Text Slot Info window shows the slot numbers, the locations of the slot, and the name of the NuBus card in the slot (see Figure 31 on page 43).
-
Page 55: Figure 31 Expansion View Text Slot Information Screen (Full Chassis)
If Expansion View does not report the correct information, fix any problems using “Populated Chassis Problems,” in Chapter 6. Then, repeat all the steps in “Testing the Populated Expansion Chassis” on page 41 to ensure that the chassis is completely functional. -
Page 56: Reinstalling The Card Guide Assembly
3. Install the card guide assembly in the Expansion Chassis. Make sure that the card guides fit properly so the fingers hold the NuBus cards in place. -
Page 57: Replacing The Expansion Chassis And Macintosh Covers
Replacing the Expansion Chassis and Macintosh Covers To complete the Expansion Chassis installation: 1. Install the Expansion Chassis cover. Make sure that the offset tabs (on the back of the cover) slide under the rear top flange and lay flat. - Page 58 C h apt er 3 • E m p t y C h a ss i s In s t a l l a ti on In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ssi s...
-
Page 59: Chapter 4 3D Effects Installation
The Avid 3D Effects Option is a set of three processor boards that enhance and extend the effects capabilities of the Avid software. The boards are housed in a penthouse cover that you add to the Expansion Chassis. This chapter describes how to install the Avid 3D Effects Option. -
Page 60: Checking The Kit Contents
Checking the Kit Contents Unpack and check the contents of the kit to ensure you have all the necessary parts. The kit contains: • A 3D Effects cover with the processor boards • A Python effects card • An interface cable •... -
Page 61: Figure 34 Finding Unused Scsi Ids With Sexpressiv
3. Record, in the space below, which SCSI IDs are not currently being used. You need this information when you set the SCSI ID selector switch on the rear of the 3D Effects cover. Unused SCSI IDs: ________________ 4. Close the SExpressIV application. Figure 34: Finding Unused SCSI IDs with SExpressIV I n s t al lin g an d U s in g t he A v id E x p a ns i o n C ha s si s C h a p ter 4 •... -
Page 62: Installing The 3D Effects Option
3. Power down the Expansion Chassis. 4. Power down any peripherals connected to the Expansion Chassis. Make sure that you power off both the Macintosh and the Expansion Chassis before you open or remove the Expansion Chassis cover. Using the Grounding Wrist-Strap Your Avid system was shipped with a reusable grounding wrist-strap. -
Page 63: Replacing The Expansion Chassis Cover
Expansion Chassis cover with the new 3D Effects cover. Make sure that your Expansion Chassis is Rev. E or later if you are installing the 3D Effects cover. Earlier revisions of the Expansion Chassis do not have the necessary screw holes along the rear cover flange or the correct power connectors to support the 3D Effects... -
Page 64: Figure 36 Card Guide Assembly Removal
3. Remove the four screws that hold the card guide assembly in place. Lift the assembly up and out of the chassis (see Figure 36). Figure 36: Card Guide Assembly Removal 4. Locate the PCB clamp at the rear of the chassis interior (see Figure 37). PCB clamp Figure 37: PCB Clamp 5. -
Page 65: Cutting The Shielding
Cutting the Shielding Before you attach the 3D Effects cover to the Expansion Chassis, you need to remove the EMI/RFI shielding from the back edge of the chassis. To remove the shielding: 1. Use a pocket knife, or similar cutting implement, to cut the shielding at each of the back corners of the chassis. -
Page 66: Attaching The 3D Effects Cover
Attaching the 3D Effects Cover The 3D Effects cover attaches to the back of the Expansion Chassis with a piano- style hinge. The 3D Effect cover is heavy and cumbersome to install by yourself. You may need to have help while you perform the first three steps in this section. -
Page 67: Attaching The Power Pigtail
Attaching the Power Pigtail If you have an Expansion Chassis that is at revision level E, F, or G, you must install a new power pigtail to properly connect the power harness from the 3D Effects cover. The revision E, F, and G chassis do not have the correct power attachment points. -
Page 68: Figure 40 Connecting The Power Harness
2. Cut the wire-ties holding the Python connector in place. Power supply Card guide bracket NuBus board Python connector Fan assembly Power harness Figure 40: Connecting the Power Harness 3. Loosen the power supply by removing the three screws that hold it in place. The screws are on the bottom of the chassis. -
Page 69: Figure 41 Power Supply Connections
8. Connect the wires for the power pigtail directly to the power supply as shown in the table in Figure 41. Tighten the connector screws as you attach each wire. Connector numbers Power leads Power supply case Power Supply Connections Connector Wire Color Brown... -
Page 70: Connecting The Power Harness
Connecting the Power Harness The 3D Effects boards get their power from the power supply in the Expansion Chassis. To connect the power harness for the 3D Effects boards to the power supply: 1. Route the power harness from the 3D Effects boards down the left side of the chassis, under the card guide bracket, and in front of the Fan assembly (see Figure 42). -
Page 71: Changing The Effects Module
You must replace the effects module on the JPEG card for the 3D Effects to work correctly. To replace the effects module: 1. Remove the JPEG card from the Expansion Chassis. Lay the card on a flat antistatic surface. Make sure that the effects module (the small attached board) is facing up. -
Page 72: Setting The Scsi Id
3D Effects cover Interface cable Figure 43: Expansion Chassis and 3D Effects Cover (Rear View) 3. Set the SCSI ID to one of the available SCSI IDs that you found earlier (see the list of SCSI IDs that you wrote down on page 49), by using the SCSI ID switch (see Figure 44). -
Page 73: Connecting The 3D Effects Cable
3D Effects cover Interface cable Figure 45: Expansion Chassis and 3D Effects Cover (Rear View) 3. Attach the other end of the cable to the SCSI connector on the back of the Macintosh. Tighten the thumb screws to secure the connector. -
Page 74: Testing The 3D Effects Installation
Macintosh. To test the chassis and cover: 1. Power on all the peripherals. 2. Power on the Expansion Chassis. 3. Open the 3D cover and set the support rod in place. Check to see that the green light on the I/O board is lit. -
Page 75: Figure 46 Scsiprobe Results
Figure 46: SCSIProbe Results 7. Open the Monitors control panel. 8. Reinitialize the NuVista+ card as follows: • If you have a Power Macintosh, set Monitor 1 to “thousands” of colors to reinitialize the card. • If you have a Quadra 650/900/950, set Monitor 2 to “thousands” of colors to reinitialize the card. -
Page 76: Figure 47 Expansion View Text Slot Information Screen (Full Chassis)
The Text Slot Info window shows the slot numbers, the locations, and the name of the NuBus card in the slot (see Figure 47). Make sure that all of the cards that are installed in the Macintosh and the Expansion Chassis appear in the Slot Info column. -
Page 77: Reinstalling The Card Guide Assembly
15. Do one of the following steps: a. If the application software runs correctly, the installation is complete. b. If the application software does not run correctly, fix any problems using “3D Effects Option Problems,” in Chapter 6. Then, repeat all the steps in “Testing the 3D Effects Installation”... -
Page 78: Closing The 3D Effects Cover
3. Install the card guide assembly in the Expansion Chassis. Make sure that the card guides fit properly so the fingers hold the NuBus cards in place. -
Page 79: Chapter 5 Expansion View
Expansion View is a software utility that allows you to view which NuBus cards are in the Expansion Chassis, get the correct chassis switch settings for the Macintosh that the chassis is connected to, and update the configuration ROM on the interface card in the Macintosh. -
Page 80: Graphic Slot Information
Graphic Slot Information The Graphic Slot Information command provides a graphical representation of the slots in both the Macintosh and Expansion Chassis in the Graphic Slot Info window (see Figure 50). You can display additional information about a NuBus card by clicking on any of the slots shown on the screen. The slot ID and the card name appear at the top of the window. -
Page 81: Text Slot Information
The Text Slot Information command provides a text listing of the slots in both the Macintosh and Expansion Chassis in the Text Slot Info window (see Figure 51). The window shows the slot number, location, and slot info for each NuBus slot. -
Page 82: Get Config Rom Information
The Update Avid Config ROM command downloads the current version of the Expansion Chassis firmware to the configuration ROM on the interface card. C h apt er 5 • E xp a n s i on V i e w... -
Page 83: Chapter 6 Chassis Troubleshooting
Chapter 6 Chassis Troubleshooting You may experience problems during the installation and operation of your Macintosh and Expansion Chassis. This chapter describes how to solve basic problems with: • The interface card • An empty Expansion Chassis • A populated Expansion Chassis •... -
Page 84: Interface Card Problems
Interface Card Problems Table 5 lists interface card problems. Table 5: Interface Card Problems Problem Solution • Expansion View does not report the Disconnect the interface cable. interface card. • Check the interface card connector for bent pins. • Make sure that the interface card is prop- erly seated in the Macintosh. -
Page 85: Empty Chassis Problems
Empty Chassis Problems Table 6 lists empty Expansion Chassis problems. Table 6: Empty Chassis Problems Problem Solution • Expansion View sees the interface card Power down the system. but not the Expansion Chassis. • Reseat the interface card and interface cable. -
Page 86: Populated Chassis Problems
Populated Chassis Problems Table 7 lists problems that may occur with a populated Expansion Chassis. Make sure you power down the Expansion Chassis and the Macintosh whenever you remove or add NuBus cards to your system. Changing cards or cables with power to the chassis on causes the Expansion View utility to report unreliable slot information. - Page 87 Power off the system. correctly, however some cards do not • Remove the card(s) in question from the function when you start your application Expansion Chassis and install them in the software. Macintosh. • Power on the system and run your appli- cation software.
-
Page 88: 3D Effects Option Problems
The power light on the I/O board is not Shut down the Macintosh. lit. • Power off the Expansion Chassis. • Make sure that the Expansion Chassis is plugged into a working power source. • Open the Expansion Chassis cover. • Check all power harness connections from the 3D Effects boards to the power supply. - Page 89 6 meters (18 ft.). Note: Add 9 inches of cable length to the total for each device on the bus. • Power on the Expansion Chassis. • Start the Macintosh. • Run SCSIProbe to check the SCSI ID again.
- Page 90 C h apt er 6 • C ha s s i s T r ou b l es h oo ti n g In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ssi s...
-
Page 91: Appendix A Expansion Chassis Specifications
Environmental specifications • Power specifications • Power cord specifications • Regulatory Agency Compliance specifications Physical Dimensions Table 9 lists the physical dimensions for the Expansion Chassis. Table 9: Physical Dimensions Dimension Without 3D Cover With 3D Cover Width 19" 19"... -
Page 92: Environmental Specifications
Storage Altitude -300 to 40,000 feet MSL -300 to 40,000 feet MSL The fans in the Expansion Chassis provide 12 feet-per-minute of cooling to the chassis and the 3D Effects cover. Power Supply Specifications Table 11 lists the specifications of the power supply in the Expansion Chassis. -
Page 93: Figure 54 Receptacle (Cee-22)
Use the following guidelines to replace the original cord set: • CEE-22 Requirements: The female receptacle of the cord set, shown in Figure 54, must comply with CEE-22 requirements. Figure 54: Receptacle (CEE-22) • United States and Canada: In the United States and Canada, the male plug is a NEMA 5-15P style and is UL Listed and CSA certified. -
Page 94: Regulatory Agency Compliance Specifications
Regulatory Agency Compliance Specifications The Expansion Chassis and the 3D Effects cover meet the following Regulatory Agency Compliance specifications: Emissions: FCC - part 15 Class A, VDE 0871 Class A, CISPR22 Class A Safety: UL 1950, CSA C22.2 NO. 950, TUV/GS, IEC 950 per EN 60950... -
Page 95: Appendix B Replacing Fuses
Appendix B Replacing Fuses The Expansion Chassis has two fuses. They are in a fuse holder that is part of the AC power input (see Figure 56). The fuses protect both the line and neutral sides of the AC power entering the chassis. This appendix describes how to replace the fuses and give the specifications for the replacement fuses. -
Page 96: Fuse Specifications
7. Remove the fuses from the fuse holders and replace them with new fuses. A pair of spare fuses was supplied with the Expansion Chassis. If you need to purchase additional spare fuses, see Table 13 for information on the correct size, rating, holders, and quantity for your power requirements. - Page 97 Advanced JPEG card, installing 26 Front panel ATTO card, installing 26 Expansion Chassis 2 AudioMedia II card, installing 26 Installation procedure Expansion Chassis 9 , 21 Cables lengths 5 Interface cable, connection 34 types 5 Card guides, adjusting 45 , 67...
- Page 98 Software, loading 20 3D Effects 48 Troubleshooting 3D Effect Option 78 Expansion Chassis 74 , 75 , 76 Wrist-strap instructions for using 10 , 22 , 51 I n de x In st a l l i n g a nd U s i n g t he A v i d E x p a ns i o n C h a ssi s...
