DoorKing 2361-080 Quick Start Manual

WIRELESS BASEBOARD KIT
This wireless baseboard kit provides wireless communication from the access control system to a wireless tracker expansion
board(s). Use this kit ONLY on DoorKing: 1833, 1835, 1837 and 1838 multi-door access controller access control systems.
Installation
The wireless baseboard REPLACES the 14-pin auxiliary terminal on the access control system's board. The existing 16.5 VAC, 20 VA access control
system's input power transformer is REQUIRED and is rewired to the 10-pin terminal #1-#2. Antenna is REQUIRED, see below for antenna options.
DoorKing Access Control System Board
RS 232
MIC
VOL
3 2 1
SPK
VOL
FEED
BACK
3 2 1
CLK
SEN
1833, 1835 and 1837 ONLY
RING
PHONE CGND PSW MIC COM
4-Pin Terminal:
Must connect to access control
system's Relay 2 for wireless
tracker expansion board
addresses 3-10.
Must connect to access control
system's Relay 1 for wireless
tracker expansion board
addresses 11-18.
Note: Terminals
can be removed
from board for
easy wiring.
18 AWG 100 ft max
16 AWG 200 ft max
8
CH
RESET
PAIRED
8
NET
ON
ID
OFF
SYNC LOST
RCVD
SYNC REVD
ALLOW
DISPLAY
OFF/ON
DENY HEARTBEAT
Wireless Wireless
STATUS
Wireless
Baseboard Baseboard
Baseboard
RF
STAT STRENGTH
ON
MASTER
CODE
Relay 0
NO
NO NC C
Relay 2 Jumper
Main Terminal
SPKR IMD 5VDC IMC Z A 2C 2RY 1C
Relay 2
Main
Door/Gate
10-Pin Terminal:
(card reader) or up to 8 tracker expansion board addresses 11-18 (NOT
wireless) may be HARD wired to the 10-pin terminal (#11-12-13-14) for
Gate/Door control if desired (DO NOT connect HARDwired tracker
expansion boards or card reader to wiegand 1 (terminals 11-14) if
WIRELESS boards will be using wiegand 1). The wiegand 1 input will
activate whatever is wired to the access control system's Relay 1 for the
access control system's programmed strike time.
14) +12 VDC Power
13) Common
12) DATA 1
11) DATA 0
6) 16 VAC Output
5) 16 VAC Output
4) Back-up Battery-NEG
3) Back-up Battery-POS
2) 16.5 VAC Input Power – 20 VA
1) 16.5 VAC Input Power – 20 VA
(Powers RS-232, elevator control, wiegand and wireless baseboard)
Wire polarity
does not matter
ELEVATOR
1
2
3
RF RANGE
DOORKING
2363-010
14
13
12
11
6
5
4
3
2
1
4-Pin Terminal
DOORKING
2361-010
NC
1NC 1NO BAT 16AC 16AC
Relay 1
One 26-Bit wiegand access control device
Optional - Wiegand 1 HARDWIRE input:
activates Relay 1 for the access control
system's programmed strike time.
Note: NOT available when using wireless
tracker expansion board addresses 11-18.
Optional - Additional power for card readers
that use lighting for outdoor use.
Optional - maintains ONLY wiegand
operation during power outage.
REQUIRED
Cabinet Mounted
Dome Antenna
(Vandal-resistant) The range is
approximately 100 ft direct-line-of-sight.
Install on top of the cabinet in the
existing antenna mounting hole (remove
plug).
Important Antenna Note:
VARY GREATLY depending on individual setup
(Antenna height above the ground, background
signal interference, physical obstructions
(trees, buildings etc.) and what antenna
you choose). Adverse weather (rain)
CAN also affect antenna range.
Externally Mounted
10-Pin Terminal
Power
Transformer
14-Pin Auxiliary
Range is approximately 500 ft
Terminal
direct-line-of-sight. Install antenna
vertically as high as possible in free
Connection
air above access control system.
Range testing is HIGHLY recommended
before FINAL installation.
Other Antenna Options
wireless communication range between the
access control system and the tracker
expansion board(s). See Repeater kit
instruction sheet for more information.
DoorKing Part Number
2361-080
Included
Antenna range WILL
Longer Range
Adjustable
Antenna
Included
13 ft of cable
Cabinet Mounted
Longer Range
Fixed Antenna Kit
Sold separately
Kit P/N: 1514-008
Range is approximately
200 ft direct-line-of-sight.
Install on top of the cabinet.
NOT vandal-resistant.
Wireless Repeater
Sold separately P/N 2364-080
The range is approximately
500 ft direct-line-of-sight with
no signal interference or
physical obstructions. May be
necessary to increase the
