Pyle PPHP155ST User Manual page 2

PPHP155ST
1. LCD Screen
2. MP3 Control
MODE: USB/SD/BT/FM Convertor
: Play/Pause
: Repeat one / Repeat all / Random
FOL (FOLDER): Press and hold for 5 seconds to enter the folder option
function model (press the previous/next songs button to choose the folder)
: Previous song, Press and hold for 2 seconds to lower the volume,
Press and hold the volume will go down to zero
: Next song, Press and hold for 2 seconds to increase the volume,
Press and hold the volume will go up to 25
3. SD card input
4. USB Input
5. Clip LED indicator
6. Power LED indicator
7. Mic 1 input level control
8. Mic 2 input level control
9. Line input level control
10. Volume control
11. Treble control
12. Bass control
13. XLR microphone input
14. 6.35mm microphone input
15. RCA phono (R+L) line input
16. 6.35mm line output
17. XLR line input
18. XLR line output
19. Speaker out 8 Ohm
20. Fused IEC mains inlet
21.120 - 240V Switch
22. Main power switch
www.PyleUSA.com
2
