- Page 1 INSTALLATION MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LP860* P/NO: MFL67738206 (1306-REV00) www.lg.com Printed in Korea...
-
Page 3: Table Of Contents
USB LG Smart Install Utility . . . . . . . . . . . . . . . . . . . . -
Page 4: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS Parts and buttons * Image shown may differ from your TV . Screen SETTINGS INPUT Buttons LG Logo Light and Remote control sensor Speakers Button Description Scrolls through the saved programmes . Adjusts the volume level . OK ꔉ Selects the highlighted menu option or confirms an input . SETTINGS Accesses the main menu, or saves your input and exits the menus . INPUT Changes the input source . Turns the power on or off . / I LED Clock connection This TV can be connected to a LED Clock /DVI IN via the CLOCK port . -
Page 5: Ezmanager
314000, 234000, 154000, 90000 khz’ . EZ-Manager Wizard y Image shown may differ from your TV . EZ-Manager Wizard Welcome to LG’s EZ-Manager Wizard Use this setup wizard to configure the TV for Pro:Centric and/or Free- To-Guest (FTG) operation. Select ‘Next’ to continue. If a Pro:Centric Server will not be installed and/or you do not wish to use the wizard to configure this TV for FTG Mode, you may exit the wizard. -
Page 6: Automatically For Setup
EZ-Manager Wizard - Automatically for Setup 1 . From the TV Configuration Options screen, you can choose how to proceed with the configuration of this TV . Whether you will configure the TV for Pro:Centric operation via the wizard or use a USB memory device to configure the TV, you may first wish to set the Room Number on the TV . EZ-Manager Wizard 2 3 4 TV Configuration Options To configure the TV for Pro:Centric operation, select ‘Next’. To set the optional Room Number, select ‘Room Number’. To access the TV’s USB Download Menu, select ‘USB Configuration’. This setup wizard will continue automatically in 60 seconds. - Page 7 2 . This step automatically searches for the Pro:Centric Server . If was found the Pro:Centric data channel, select the "Next" . EZ-Manager Wizard Room # 1716 Searching for Pro:Centric Server... It may take 1 min 00 second(s). This step automatically searches for the pro:centric Server. If there is no Pro:Centric Server installed, you do not need continue with this procedure.
- Page 8 3 . Downloading the Pro:Centric application files takes few minutes . EZ-Manager Wizard Room # 1716 Processing the Pro:Centric Configuration... Downloading the Pro:Centric application files takes a few minutes. Please wait... Retrieving files from data Freuquency 698000 Application files In progress... Maintenance files Pending... - Updating Configuration File - Updating Splash Logo Image Warning - Do not remove AC power or the signal cables during these steps.
-
Page 9: Manually For Setup
EZMANAGER EZ-Manager Wizard - Manually for Setup 1 . Select a Label and/or enter the Room Number using the numeric keypad on the remotes . To continue, move and select 'Next' . EZ-Manager Wizard 2 3 4 TV Configuration Options To configure the TV for Pro:Centric operation, select ‘Next’. To set the optional Room Number, select ‘Room Number’. To access the TV’s USB Download Menu, select ‘USB Configuration’. This setup wizard will continue automatically in 60 seconds. - Page 10 3. Configure the appropriate Pro:Centric settings in the TV. EZ-Manager Wizard Room # 1716 Pro:Centric Mode Country Media Type 698000 Frequency (KHz) Symbolrate (kS/s) 6900 Modulation 256QAM Signal Strength Signal Qualit y data channel found Back Next Exit EZ-Manager Wizard Room # 1716 Pro:Centric Mode Country...
- Page 11 4 . Downloading the Pro:Centric application files takes few minutes . EZ-Manager Wizard Room # 1716 Processing the Pro:Centric Configuration... Downloading the Pro:Centric application files takes a few minutes. Please wait... Retrieving files from data Freuquency 698000 Application files In progress... Maintenance files Pending... - Updating Configuration File - Updating Splash Logo Image Warning - Do not remove AC power or the signal cables during these steps.
-
Page 12: Usb Lg Smart Install Utility
Next USB Configuration Room Number TV Software Update(Expert) USB LG Smart Install Utillity Integrated USB Downloading The Follwing update les are found in the USB device. Select the le you want to apply to update this TV All checked files will be downloaded when you press enter key. - Page 13 2 . Downloading the Pro:Centric application files takes few minutes . Room # 1716 USB LG Smart Install Utillity Downloading Data... Warning - Do not remove the USB device during this process Maintenance File Comlete xxLP860H-ZA_TLL_EU.til File Name: Boot Logo File Ready xxLP860H-ZA_Bootlogo.jpg File Name: Ready Software File(CPU) xxLP860H-ZA_CPU.epk...
-
Page 14: Installation Menu
T he abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’ . T he wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators . y Image shown may differ from your TV . Installation Menu (V2 . 2 3) LG Hotel Mode Setup LG Hotel Mode Setup USB Cloning Password Change Set ID Setup Configuration Setup External Speaker IR Setup... -
Page 15: Lg Hotel Mode Setup
LG Hotel Mode Setup y Image shown may differ from your TV. Installation Menu (V2.23) LG Hotel Mode Setup LG Hotel Mode Setup USB Cloning LG Hotel Mode Setup (V2.23) Password Change ▲ Hotel Mode Operation Set ID Setup Yes ◄ ► Configuration Setup • Power On Status External Speaker • Setup Menu Display • Programme Change IR Setup • Input Source Change Network Setup Pro:Centric • Menu Display • OSD Display Power Saving • LG IR Operation CEC Setup ▼ Clock Setup Previous PreLoadedApp Setup Media Share S/W V 02.03.00.01 / MCU V 02.05 / FPGA V d. 279 Use the button to select the LG Hotel Mode Setup. -
Page 16: Lg Hotel Mode Setup
(3) Setup Menu Display - Decide to enter 'Setup Menu Display' or not in the 'Main Menu' by setting 'Setup Menu Display' as Yes(Enter Possible) or No(Enter Impossible) on the "LG Hotel Mode Setup" OSD . (4) Programme Change - Decide to change channel or not by setting 'Programme Change' as Yes(Change Possible) or No(Change Impossible) when present source is TV . - Page 17 (7) OSD Display - Decide to display OSD or not by setting 'OSD Display' as Yes(Mark) or No(No Mark) . - When 'OSD Display' is set to No(No Mark), all OSD is not displayed except installaion menu . (8) LG IR Operation - Decide whether work the LG remote control or not . - Set to Yes(Work) or No(Do Not Work) . - When ‘LG IR Operation’ is set to NO(Not Work), all keys don’t work . - Although set to No, it can work in Service mode . - Although set to No, Home key action to enter the ‘Installation Menu’ and key action to enter Password are available . - When ‘LG IR Operation’ is set to Yes(Work), all keys are available . (9) Local Key Operation - Decide to operate 'Local Key' or not by setting “Local Key Operation" as Yes(Work) or No(Do Not Work) .
- Page 18 (12-1) Input Source - Set whether it is turned on by the set input source or by the last stored input source. - It is turned on by the Last Memory Input if the Input source is turned off. - It is turned on by the Last Pr. If the Input source is turned off and the Last Memory Input is the RF. - All sources supported by the said model can be set as Input source.
- Page 19 - The max value for the No . of PR is 10 . - Can not set more than maximum available programme number . In other words if Start PR . are set to 195, number of programme can not set more than 5 . - Radio Programme should be in sequence with starting programme . Initial Configuration and Configuration Detail Item Active De-active Initial Hotel Mode Operation Power On Status Setup Menu Programme Change Input Source Change Menu Display OSD Display LG IR Operation Local Key Operation Max Volume 0~100 DTV Channel Update Auto Manual Auto Power On Default Input Source ATV~MAX_INPUT Programme (1-Max PR) Volume 0~100 A/V Setting Radio Video Blank Start PR . No .
-
Page 20: Usb Cloning
USB Cloning Procedure (1) Overview USB Cloning Procedure Commercial TVs have the capability to support cloning internal TV data and programme information with an external clone device called “TVLink-Loader”, in order to copy TV data accurately and quickly. The clone internal functions use slightly different internal processes for the two types of commercial TVs. However, the UI of cloning feature remains the same in both. Regarding the demands over the current cloning feature for quicker cloning, better portability and etc, we would like to announce the cloning process via USB port, named as USB Cloning. USB cloning process is divided into 2 main processes. One is writing the previously saved TV data into the TV, and one another is reading of current TV data into USB memory card. To avoid any confusion due to the words, it is clearly specified as “Receive from USB” and “Send to USB” in the whole process. -
Page 21: Send To Usb
Send To USB y Image shown may differ from your TV. “Send To USB” must be done first before “Receive From USB” process, as it generate the file to be used in “Send To USB”. While writing is in process, the user must not turn TV off nor unplug the USB memo- ry card. The steps in “Send To USB” are explained below. The following images might be slightly different than the OSD image. Plug in USB memory card into the port on target TV. Saving 42LD420C-ZA00001.TLL ... 87% Send To USB Select the file name and press OK to start 42LD420C-ZA00001.TLL The process will be shown with progress Previous bar, and as soon as sending the current profile is finished, a message acknowl- edging the learning process is complete will pop up. Receive From USB Once the internal TV data and its channel map information is written to the USB memory card, the user can start “Receive From USB” process with the data file generated and stored in USB memory card. As previously warned in “Send To USB” process, the user should not turn TV off nor unplug the USB memory card. Detailed steps for “Receive From USB” are illustrated below. The following images might be slightly different than the OSD image. -
Page 22: Loge Image Download
Logo Image Download Make a ‘LG_DTV’ folder on the USB flash drive and then copy the splash image file to that folder . USB Cloning Logo Image Download Receive from USB 1024X768 .jpg Send to USB Logo Image Download Previous Previous Select Logo Image Download Select a Splash Image file you want . You can see a new Splash Image on TV which TV Software Update(Expert) you downloaded while turning on TV . UPGRADING . . . Do not unplug! Wait till the download process is completed . After completion of download, TV set will restart automatically . MENU INPUT NOTE Splash Image update function supports only JPEG format file of less than 1 MB filesize . ► Except for JPEG images with progressive encoding . ► We recommend you that splash image resolution match the TV`s panel resolution . -
Page 23: Password Change
Password Change y Image shown may differ from your TV . - To ensure more security, Password can be changed by installers’ own design . Installation Menu (V2 . 2 3) LG Hotel Mode Setup USB Cloning Password Change Password Change Password Change Set ID Setup Configuration Setup Change Password External Speaker Confirm Password IR Setup Previous Network Setup Pro:Centric Power Saving CEC Setup Clock Setup PreLoadedApp Setup Media Share S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 Use the button to select the Password Change and then press the OK button . -
Page 24: Set Id Setup
Set ID Setup Installation Menu (V2.23) LG Hotel Mode Setup USB Cloning Password Change Set ID Setup Set ID Setup Set ID Setup Set ID Lock Configuration Setup ◄ ► Set ID External Speaker IR Setup Previous Network Setup Pro:Centric... -
Page 25: Configuration Setup
Configuration setup y Image shown may differ from your TV . Configuration Setup Installation Menu (V2 . 2 3) Select RCU Disable LG Hotel Mode Setup ◄ ► Number of RCU USB Cloning Splash Offset Time Password Change Set ID Setup RS232 DC Power Outlet Configuration Setup Configuration Setup One Channel Map External Speaker Lock Mode IR Setup DTV Channel Update Auto Network Setup On Timer Operation Pro:Centric Disable Scart Out ◄ ► Power Saving RGB Overlay in RF CEC Setup Radio Name Display... - Page 26 Interface box RS-232C IN (CONTROL & SERVICE) Type of Connector: D-Sub 9-Pin Male Signal Signal requirements RX RS232 Standard RS232 specification TX RS232 Standard RS232 specification IR from TV Power ground 6, 8 Not connected +5VDC 10%, max 100mV ripple Male connector on box, 1.5 A +12VDC 10%, max 100mV ripple...
- Page 27 (8) On Timer Operation - It is a mode to select 'On Timer Operation' working one time or repeatedly . 'ONE' : 'On Time' in the user menu operates only one time when the 'On Time' menu is set to 'ON' . 'Repeat' : 'On Time' operates repeatedly when the 'On Time' menu is set to 'ON' . (9) Scart Out - The monitor out signals can or cannot be output through the SCART cable, depending on the setting value of scar t out .You can set to Enable or Disable using the < > button . The default value is Enable . (10) RGB Overlay in RF - It is a mode to select whether to display RGB Data together on RF image or not . When ‘RGB Overlay In RF’ is set to ‘Yes’, Overlay Mode get to ‘Enable’ and you can see RGB Data signal as well as general RF Image . - This is mainly used to provide information to the hotel guest . (11) Radio Name Display - Instead of "Audio Only", the name of a radio channel is displayed on the screen when a radio broadcast is playing . - Set to Yes(Work) or No(Do Not Work) . - If the setting is "Yes", the name of a radio channel is displayed for the radio channel . - If the setting is "No", the text "Audio Only" is displayed for the radio channel .
-
Page 28: External Speaker
External Speaker Installation Menu (V2.23) LG Hotel Mode Setup USB Cloning Password Change Set ID Setup Configuration Setup External Speaker External Speaker External Speaker IR Setup Volume Control ◄ ► Network Setup Output 0.01 Watt Pro:Centric Main Speaker Power Saving... -
Page 29: Speaker Output Setup
Speaker output SETUP Connect the external speaker to the SPEAKER OUTPUT(STEREO) jack on the TV . Control port for Speaker out SPEAKER OUT VOLUME STEREO CONTROL (8 ) EAKER A A A K Method of Volume control port Cable • Each Up/ Down pin is pulled Spec . to 3 .3V with CPU GPIO . • CPU detects sort - to - gnd for GND / Up / Down volume control . -
Page 30: Ir Setup
IR Setup Installation Menu (V2 . 2 3) LG Hotel Mode Setup USB Cloning IR Setup Password Change Set ID Setup Paywall Disable ◄ ► Configuration Setup Input Source External Speaker Programme IR Setup IR Setup Standard Network Setup Ring 1 Pro:Centric Ring 2 Power Saving Standard CEC Setup Ring 1 Ring 2 Previous Clock Setup PreLoadedApp Setup Media Share S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 Use the button to select the IR Setup . -
Page 31: Network Setup
Network Setup Installation Menu (V2.23) LG Hotel Mode Setup Network Setup USB Cloning Network Setting Press OK ◄ ► Password Change Network Status Press OK Set ID Setup WOL(Wake Up Frame) Disabled Configuration Setup WOL(Magic Packet) Disabled External Speaker Wake On Wireless LAN Disabled IR Setup PCR Offset Network Setup Network Setup Audia PTS Offset Pro:Centric Power Saving Video PTS Offest CEC Setup IGMP Version Clock Setup MAC Address AA:BB:CC:DD;EE:39 PreLoadedApp Setup Previous Media Share S/W V 02.03.00.01 / MCU V 02.05 / FPGA V d. 279 (1) Network setting • One-click network connection... - Page 32 (2) Network Status - You can also check whether the IP settings are configured properly using the Enter button. (3) WOL(Wake Up Frame) - Sets the Wake On LAN function to Enable or Disable. Use "Wake Up Frame". (4) WOL(Magic Packet) - Sets the Wake On LAN function to Enable or Disable. Use "Magic Packet". (5) Wake On Wireless LAN - Sets the Wake On Wireless LAN function to Enable of Disable. Use “Wake Up Frame and Magic Packet”. (6) PCR Offset - Controlling standard clock of input stream depends on network condition. (7) Audio PTS Offset - Controlling output stream timing of audio. (8) Video PTS Offset - Controlling output stream timing of video. (9) IGMP Version - You can select IGMP Version of multicast packet.
-
Page 33: Pro:centric
Pro:Centric Pro:Centric Installation Menu (V2.23) Mode Off LG Hotel Mode Setup ◄ ► WORF Setting Disable USB Cloning Room Number Setting Password Change Press OK Medium Type Set ID Setup RF Freq. (kHz) ------ Configuration Setup Mod. Type External Speaker DVB-T IR Setup P.C IP Setting (IP a) Network Setup P.C IP Setting (IP b) Pro:Centric Pro:Centric P.C IP Setting (Port) Power Saving Receive Data Enable CEC Setup Clock Update Clock Setup Clock Freq.(kHz) ------ PreLoadedApp Setup Clock service ID Media Share Clock IP Setting (IP a) S/W V 02.03.00.01 / MCU V 02.05 / FPGA V d. 279... - Page 34 - Sets the RF modulation type to DVB-T or DVB-C. The default value is DVB-T. (6) Mod. Type - Sets the RF modulation type to DVB-T or DVB-C. The default value is DVB-T. (7) P:C IP Setting - It can be set using the or number buttons. • (IP a) : Sets the first number in the IPv4 address. • (IP b) : Sets the second number in the IPv4 address. • (IP c) : Sets the third number in the IPv4 address. • (IP d) : Sets the fourth number in the IPv4 address. • (Port) : Sets the actual port number where the Pro:Centric server is running. It can be set using the or number buttons. - The default value of IP a/b/c/d is 0 and the range is between 0 and 255. The default value of Port is 80 and the range is between 0 and 65535. (8) Receive Data - Sets Enable or Disable. When it is set to Disable, all the sub items are disable. (9) Clock Update - It can be set to "Off" or "Clock Freq". The default value is 'Off'. - If it is set to "Off", the time set from the main menu will be used. If it is set to "Clock Freq", the time will be updated from a specific frequency (10) Clock Freq.(KHz) - The default value is '------'. - Set the RF frequency of the channel from which to update the time. (11) Clock service ID - The default value is 0.
-
Page 35: Power Saving
Power Saving Installation Menu (V2 . 2 3) LG Hotel Mode Setup USB Cloning Password Change Set ID Setup Power Saving Configuration Setup External Speaker Static Saving 100(OFF) ◄ ► IR Setup Keyless Off Hours Network Setup Pro:Centric Previous Power Saving Power Saving CEC Setup Clock Setup PreLoadedApp Setup Media Share S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 Press the button to select the Power Saving . -
Page 36: Cec Setup
S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 Use the button to select the CEC Setup . (1) Control - D etermines whether to use TVLink-CEC . The default value is No . When No is selected, you cannot set subitems . (2) IR Decoding - Determines whether to decode the LG remote control . If No is selected, the TV does not decode it and sends signals only to the IR Out port . You need to run Forced Initialize below once to apply it . If Yes is selected, the TV decodes and changes it into a CEC Message and sends it to Command via the HDMI CEC Line . The default value is No . (3) Custom Code - Sets the custom code used for NEC Format of the remote control . The default value is 4 . The TV remote control that LG is currently using is 4 so this item is always set to 4 and disabled . -
Page 37: Clock Setup
Clock Setup Installation Menu (V2 . 2 3) LG Hotel Mode Setup USB Cloning Clock Setup Password Change Set ID Setup Clock Display No ◄ ► Configuration Setup Dimming Standby External Speaker Dimming PowerOn IR Setup Clock Source Network Setup Programme Pro:Centric Offset ATV Clock Power Saving CEC Setup Previous Clock Setup Clock Setup PreLoadedApp Setup Media Share S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 Press the button to select the Clock Display . -
Page 38: Preloadedapp Setup
PreLoadedApp Setup Installation Menu (V2 . 2 3) LG Hotel Mode Setup USB Cloning Password Change Set ID Setup Configuration Setup External Speaker ◄ ► IR Setup Network Setup Pro:Centric Power Saving CEC Setup Clock Setup PreLoadedApp Setup PreLoadedApp Setup Media Share S/W V 02 . 0 3 . 0 0 . 0 1 / MCU V 02 . 0 5 / FPGA V d . 279 If you want to use a particular app, you can choose from the menu . you can setting each apps... -
Page 39: Media Share
Media Share Installation Menu (V2.23) LG Hotel Mode Setup USB Cloning Media Share Password Change Smart Share Yes Set ID Setup ◄ ► Wi-fi Screen Share Yes ◄ ► Configuration Setup Yes External Speaker ◄ ► TV Name Edit Press OK IR Setup ◄ ► [ TV ] GLOBAL-PLAT4 TV Name Network Setup SoftAP Pro:Centric Yes ◄ ► Power Saving - Use Default Setting Yes ◄ ► CEC Setup - Security Key Edit Press OK ◄... -
Page 40: Download Extra Contents
DOWNLOAD EXTRA CONTENTS Download Extra Contents(flash file) toTV set The Pro:Centric application can be downloaded to your TV . FLASH (* .SWF) / GEM/HTML supporting file An SWF file complied with Flash Lite 3 .0 or earlier (the 3 .0 version is recommended) • Mode must be set to Flash, GEM or HTML under Pro:Centric in Installation Menu . • The folder called /hcapfs/as/abs_service/ must exist in USB drive root directory . • The file called xait .xml must exist in the /hcapfs/as/abs_service/ folder . • T he file called I_AM_FLASH must exist in the /hcapfs/config/ folder with Flash mode . • T he file called I_AM_GEM must exist in the /hcapfs/config/ folder with GEM mode . • T he file called I_AM_HTML must exist in the /hcapfs/config/ folder with HTML mode . • Y ou will have no response even if selecting Yes in step 3 when the above conditions are not met . y Image shown may differ from your TV . C onnect the USB device to the USB IN jack on the TV . - Page 41 You can see a new Application File on TV . Continue to replace ‘Extra Contents’ with one in USB memory? Select ‘Yes’ . MENU INPUT Wait till the download process is completed . After completion of download, TV set will restart automatically . TV is in updating process . Please wait for a while . ■ To stop playing the Application file Change Mode other than Flash or GEM under Pro:Centric in Installation Menu . When you change the Mode, the downloaded content is deleted from the memory . NOTE ► W hen playing the Application file(FLASH or GEM file), the buttons are controlled according to the settings of the Extra Contents option .
-
Page 42: Download A Splash Image
DOWNLOAD A SPLASH IMAGE Download Splash Image file to TV set Make a ‘LG_DTV’ folder in the USB flash drive and then copy splash image file to the folder . y Image shown may differ from your TV . C onnect the USB device to the USB IN jack on the TV . AUX LAN HDMI/DVI IN (RGB) Move OPTION Language(Language) ● Country : UK ● SPEAKER Disability Assistance ● SETUP PICTURE AUDIO TIME Standby Light : On ● Smart Share Setting ● VOLUME CONTROL Factory Reset ●... - Page 43 You can see a new Splash Image on TV which TV Software Upgrade you downloaded while turning on TV . The Following update files are found in the USB device . Select the file you want to apply to update this TV Or press EXIT to cancel the update . TV Software Update LOGO Image Download MENU INPUT TV Software Update(Expert) UPGRADING . . . 100% DO not unplug! Wait till the download process is completed . After completion of download, TV set will restart automatically . NOTE Splash Image upgrade funciton supports JPEG and BMP format file of less than 8MB filesize . ► Except for JPEG images with progressive encoding . ► The resolution of Splash image should be 1920 x 1080 for full HD panel, 1360 x 768 for HD ► panel . TV keep splash image until you change a new splash image . ►...
