DE VECCHI DVA GIX Series Technical Features

Automatic water softener chronometric

Advertisement

Quick Links

AUTOMATIC WATER SOFTENER CHRONOMETRIC
Width [mm]:
Depth [mm]:
Height [mm]:
Weight [Kg]:
Cylinder capacity : [l]
Liters of resin [l]:
Nominal flow rate at 4 bar:..
Room temperature:
Feed water temperature
Pressure of feed water: ....0,2 ÷ 0,8 MPa (2 ÷ 8 bar)
Power supply: ........INPUT: 230V 50/60 Hz standard
Absorbed power:
Series GIX
TECHNICAL FEATURES
GIX5 GIX8 GIX12
230
250
380
480
515
540
11
12
5
8
:
3.5
5.5
Min 4°C Max 35°C
Min 6°C Max 25°C
120V
60 Hz optional
285
425
650
15
12
9
1500 l/h
4 W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVA GIX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DE VECCHI DVA GIX Series

  • Page 1 AUTOMATIC WATER SOFTENER CHRONOMETRIC Series GIX TECHNICAL FEATURES GIX5 GIX8 GIX12 Width [mm]: Depth [mm]: Height [mm]: Weight [Kg]: Cylinder capacity : [l] Liters of resin [l]: Nominal flow rate at 4 bar:.. 1500 l/h Room temperature: Min 4°C Max 35°C Feed water temperature Min 6°C Max 25°C Pressure of feed water: ..0,2 ÷...
  • Page 2 SETTINGS The GIX chronometric softner series features the Logix 740 valve. Thanks to their user-friendly approach, they can easily be set. They have 4 buttons that are used to set current time, regeneration time, the days on which regeneration shall be carried out or the number of days elapsing between two regeneration cycles.
  • Page 3 CHOOSING THE PLACE OF INSTALLATION: Waste water resulting from the regeneration must be funneled into the floor sink by the flexible pipe. If the floor sink is placed higher than the water softener, the maximum height acceptable is 1.8 metres, provided that the pipe is not longer than 5 metres and the pressure of the water system is at least 2.8 bar If the water softener is near a boiler, check that the...
  • Page 4 The GIX series chronometric softeners can be equipped, upon request, with an optional device for resin sterilization. Such device is installed in the body of the valve and connected to the timer connector. Once installed, the timer will start it during a regeneration cycle.
  • Page 5 lack of maintenance can cause the softener to malfunction The filling of the brine (obstructed ejector) and the lack of suction of the brine (air infiltration in the rapid connections) are the problems that could occur due to lack of maintenance by the installer. FOR THE USER: Maintenance for the user only consists in refilling the brine periodically with sodium chloride (NaCl,...
