- Page 1 Fitting Manual for pan...
-
Page 2: Table Of Contents
Index Thank you for choosing a quality product from BHM-Tech. The pan digital hearing system Purpose ..............3 is manufactured in Austria in line with the regulations laid down in Medical Device Directive Warning information for hearing aid acousticians ..3 93/42/EEC and latest audiological findings and technical innovations. -
Page 3: Determining The Temple Length
Determining the temple length Preparation of the temple To determine the correct temple length, use the fitting template supplied (Fig.1). Ensure the To prepare the temple, remove the temple from the front of the spectacles if required. The wearing position of the spectacles is correct. temple is cut to length at marking A using a suitable tool (such as with side-cutting pliers) Use a pen to mark Points A and B by putting the fitting template onto the spectacle and the plastic is stripped to the wire core at marking B (Fig. -
Page 4: Cosmetic Adjustment Of The Temple
Cosmetic adjustment of the temple Mounting the adapter The temple must be adapted cosmetically to the hearing system by cutting, sanding or Clean the protruding wire core with spirit. The glued surface must be free of grease (Fig. 9). similar such that a smooth transition is created (Fig. 8). Included with the product is an adapter ring with different adapters suitable for different wire cores (Fig. -
Page 5: Mounting The Hearing System
Apply glue to the wire core and the cut surface and fit the adapter onto the temple. Ensure the adapter sits straight and secure (Fig. 11). Mount the hearing system onto the adapter and secure it using a BHM pin setter and locating Recommendation: Cyanoacrylate quick-action glue with low viscosity (such as pin (on the adapter ring) - Fig. -
Page 6: External Receiver
External receiver Selection and mounting of the earpiece Use the audiogram, the condition of the auditory canal and the datasheet to decide Use the condition of the auditory canal to select the earpiece suitable for your customer whether your customer requires a Normal Power (Fig. 16) or High Power receiver and fit it onto the external receiver (Figs. -
Page 7: Mounting The High Power Earpiece
Mounting the High Power earpiece Cerumen Filter HF3 Mounting tool for High Power earpiece Fit the earpiece over the adapter of the mounting tool. Ensure that the earpiece is fully on the mounting tool. Removing the HF3 filter Open the earpiece by pressing together the mounting tool. Press the HF3 filter as far as it will go into the High Power earpiece. -
Page 8: Mounting And Dismounting The Receiver
Mounting and dismounting the receiver Adaptation of the receiver See Figs. 23 to 25 for fitting and removing the receiver. The tube shape of the receiver can be adapted as follows if required: Place the receiver into the protective sleeve provided (Fig. 26). Rotate the spiral spring onto the receiver tube (Fig. -
Page 9: Special Cases
Note: No battery needs to be inserted for programming. If the customer has a spectacle frame from Coselgi or BHM-Tech, we offer special adapters for these (Figs. 30 and 31). When using the pan with these adapters, an overall length as Remove the programming socket cover and plug the connector of the programming cable with existing BHM-Tech and Coselgi hearing temples is attained. - Page 10 Notes...
- Page 11 7423 Grafenschachen, Austria www.bhm-tech.at According to EU guidelines 93/42/EEC 0 2 9 7 Quality management system according to DIN EN ISO 13485 Perfection made in Austria Responsible for the content: BHM Tech / Design: RABOLD UND CO. / Photos: BHM, Erwin Muik...
