  • Page 1 Specifications Operating Instructions zebris Medical GmbH www.zebris.de Text-Release: 20/03/15...

  • Page 2: Table Of Contents

    DAUM ERGO F (F 1.6 & C- M 1.8) ............44 RAINING ORCE SETUP AND OPERATION OFT HE FDM-T SYSTEM ..............45 ..................45 OSITIONING OF THE MEASURING SYSTEM ................ 46 NSTALLATION OF THE DETACHABLE CABLE GUARD ............47 ONNECTION OF THE MEASURING SYSTEM TO MAINS SUPPLY 6.3.1...
  • Page 3 8.2.3 ......................60 SE OF MULTIPLE SOCKETS ......... 61 LECTROMAGNETIC OMPATIBILITY ANUFACTURER ECLARATION (M) ................. 64 ECLARATION OF CONFORMITY MEDICAL LINE (S) ................65 ECLARATION OF CONFORMITY SPORTS LINE zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 3/65...

  • Page 4: User Notes

    1.1 Introduction Dear Customers, We are delighted that you have chosen a zebris product. Since 1987 zebris Medical GmbH has been developing and producing measuring systems for application in medicine, reha- bilitation, diagnostics, sport and science, thereby satisfying high demands as regards technology, safety and functionality.

  • Page 5: Manufacturer

    CE mark. The user manual for the FDM-T measuring system therefore consists of several sections: 1. FDM-T Specifications and Hardware User Manual 2. zebris FDM User Manual for the application software 3.

  • Page 6: Conventions And Symbols Used

    This symbol indicates a potential hazard that can cause a loss of eyesight. This warning indicates the type of hazard and how it can be avoided. Item number of the measuring system / accessories Serial number of the measuring system zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 6/65...

  • Page 7: Application And Safety

    The patient’s weight is limited by the maximum permissible weight of the treadmill. For the application of the FDM-T with children or patients with severe movement disorders, a fall stop safety is strongly recommended.

  • Page 8: Safety

    2.2 Safety 2.2.1 Environmental conditions FDM-T Measuring Systems are suitable for application in dry interiors with level ground such as those in hospitals, doctors' surgeries and laboratories. Temperature range 10°C to 40°C Relative humidity 30% to 70% FDM-T systems must NOT be operated in wet zones, wet rooms (swimming pools, saunas) or climatic chambers.

  • Page 9: User Obligations

     the valid industrial safety regulations.  the valid accident prevention.  For the safety, reliability and performance of the components delivered by zebris, re- sponsibility is assumed, if:  assembly, extensions, re-settings, changes or repairs were carried out through zebris or third parties authorised by zebris, trained technicians or employees of au- thorised dealers.

  • Page 10: General Safety Instructions

     The patients’ data and measuring data may only be copied, moved, or deleted using the data-base function provided by the zebris application programs. In the case of data be- ing changed intentionally without using the database functions, the user alone bears the full risks involved.

  • Page 11: Safety Instructions For The Treadmill

    2.2.5 Safety instructions for the Treadmill  The treadmill belonging to the FDM-T Measuring System is a very powerful device. For safe operation of the FDM-T System it is mandatory to adhere exactly to the safety reg- ulations described in the following.

  • Page 12: Prohibited Use

     We also point out that if any changes are made to this certified device or its accessories without the prior written consent of zebris, your legal right to operate the device will be void. If changes are made to the device without obtaining approval, the operator is obli- gated to carry out suitable investigations and tests in order to guarantee safe use.

  • Page 13: Product Description

     User Manual for FDM-T system, treadmill, zebris FDM software 3.2 Specification FDM-T Sensor The sensors of the different FDM-T system only vary in size of the measuring area, the number of single sensors included in the sensor module and the supported sampling fre- quency.
  • Page 14 REF-No. 124.3056 Sensor Area / cm 94.8 x 40.6 Number of Sensors 112 x 48 / 5376 Resolution 1.4 Sensors /cm Sampling Frequency 100 Hz Infrared Interface optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 14/65...
  • Page 15 88 x 39 / 3432 Resolution 1.4 Sensors /cm 1.4 Sensors /cm 0.6 Sensors /cm Sampling Frequency 100 Hz 120 / 240 Hz 120 Hz Infrared Interface optional IR-Box optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 15/65...
  • Page 16 1.4 Sensors /cm 0.6 Sensors /cm Messfrequenz 120 / 240 Hz 120 Hz 120 / 240 Hz 120 Hz IR Schnittstelle optional IR-Box optional IR-Box optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 16/65...
  • Page 17 128 x 56 / 7168 88 x 39 / 3432 Resolution 1.4 Sensors /cm 0.6 Sensors /cm Sampling Frequency 120 / 240 Hz 120 Hz Infrared Interface optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 17/65...
  • Page 18 1.4 Sensors /cm 0.6 Sensors /cm Sampling Fre- 120 / 300 Hz 120 Hz 120 / 300 Hz 120 Hz quency Infrared Interface optional IR-Box optional IR-Box optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 18/65...
  • Page 19 128 x 44 / 5632 Resolution 1,4 Sensors /cm 0,6 Sensors /cm Sampling Frequency 100 / 200 / 300 Hz 100 / 200 / 300 Hz Infrared Interface optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 19/65...
  • Page 20 0.6 Sensors /cm 1.4 Sensors /cm 0.6 Sensors /cm Sampling Frequency 120 Hz 100 Hz 120 Hz 100 Hz Infrared Interface optional IR-Box optional IR-Box optional IR-Box optional IR-Box zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 20/65...

  • Page 21: Measuring Principle Fdm-T Systems

    Schiebe- Schiebe- register register Burstgenerator, Ansteuerlogik Programm- daten Gleichrichter, Verstärker, CPU-internes 8-Bit ADC Flash Datenbus Optokoppler & Galvanische Trennung mit Kalibrierdaten Gleichrichter Kalibrier- Flash externes AC-Netzteil entspricht IEC 601 zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 21/65...

  • Page 22: Controls And Connectors

    MEASURE The measure LED will be illuminated during the measurement. This LED will be illuminated when the USB socket is connected to the PC and the hardware driver of the platform is installed properly. zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 22/65...

  • Page 23: Zebris Sync

    3.7 zebris SYNC The zebris SYNC is the standard solution for synchronization of the FDM-T system with third party measuring devices. The SYNC-IN and SYNC-OUT sockets provide input and output for support of „sample by sample“ In- and Out synchronization. Both sockets provide galvanic protection between third party systems and FDM-T sensor.

  • Page 24: Synchronization Input (Sync-In)

    Socket Coding: 30° View Socket, Front Side Respective Plug for SYNC-IN: LEMO-Part-No.: FGA.00 303.CLADxxxx View Plug Coding: 30° Plug, Solder Side Pin Assignment Pin 1 Clk_IN Pin 2 Activ_IN Pin 3 zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 24/65...

  • Page 25: Synchronization Output (Sync-Out)

    If a third party device is connected to the synchronization output SYNC-OUT then depend-ing on the setting of the configuration window of the application software, a FDM-T sys-tem- controlled, will trigger a synchronized measurement of the third party device either via start/stop or “sample by sample”...

  • Page 26: Ir-Synchronization Box For Dab-Bluetooth (Zebris Emg)

    3.7.3 IR-Synchronization Box for DAB-Bluetooth (zebris EMG) For synchronizing of the FDM-T system with the zebris DAB-Bluetooth the optionally avail- able IR synchronization box is required. REF-No. 183.2021 / IRS-E Infrared Sync, cable length 1m The IR synchronization box is connected to the system in the IR socket of the Interface box and then fixed simply and safely to the treadmill frame using the integrated magnet.

  • Page 27: Spare Parts Fdm-T System

    Cable protection cover for mounting on the interface box incl. fixation screws 181.1515 PS Treadmill V2 Power supply unit 60W/16VDC for FDM-T sensors equiv. to EN 60601-1 & UL 720.0001 zebris FDM Software for operation system Windows 7 32/64 Bit...
  • Page 28 Mains adapter 110W / 24V DC, Supports up to 3 SYNC Light plus. 185.0011 SYNCLight plus Adapter Cable for Master-Slave connection of up to 3 SYNCLight plus, length 1m zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 28/65...
  • Page 29 FDM. 155.1006 Gait Training Type P Module for gait training by visual stimulation on h/p/cosmos pulsar. Contains video projector with clamp and software extension for zebris FDM. zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 29/65...

  • Page 30: Video-Module

    4 Video-Module 4.1 Conection to the FDM-T System The FDM-T system can capture data simultaneously with up to 2 video cameras like the zebris SYNCCam which is available as an accessory. Alternatively high quality DV- camcorders with an external microphone socket can be used for video capture.

  • Page 31: Connection Scheme Synccam Und Synclight

    4.1.3 Connection scheme SYNCCam und SYNCLight zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 31/65...

  • Page 32: Connection Scheme Synccam Und Synclight Plus

    4.1.4 Connection scheme SYNCCam und SYNCLight plus zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 32/65...

  • Page 33: Synccam

    4.2 SYNCCam The SYNCCam is an accessory of the FDM-T system and perfectly adapted to be used in combination with the force distribution measurement. All adjustments of the camera are carried out via hardware setup integrated to the zebris FDM Software. The camera is con- nected to the PC by a USB cable of type A-B included within the shipment.

  • Page 34: Led Video Lights (Synclight / Synclight Plus)

    The LED video lights SYNCLight and SYNCLight plus are accessories of the FDM-T sys- tems and perfectly adapted for use in combination with zebris SYNCCam as well as the force distribution measurement.
  • Page 35 Directional Characteristic SYNCLight and SYNCLight plus can be operated in landscape or upright position which the individual lighting situation requires. zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 35/65...

  • Page 36: Synclight

    4.3.1 SYNCLight If the synchronization signal from the interface box of the FDM-T system is connected to the VIDEOSYNC socket the SYNCLight will be automatically turned on and off when a measurement is started or stopped. In order to use the synchronization set the SYNC-Mode switch to position SYNC. At posi- tion CONT the SYNCLight plus is switched on permanently.

  • Page 37: Synclight Plus

    4.3.2 SYNCLight plus The SYNCLight plus supports the zebris VIDEOSYNC as well as more complex synchro- nization modes that may be required for use of industrial cameras. In order to use the synchronization modes set the SYNC-Mode switch to position SYNC.
  • Page 38 LEMO- Part No. The SYNC IN is the standard synchronization FGA.00 303.CLADxxxx tool (zebris SYNC) of all zebris measuring sys- tems and intended to be used to synchronize the lighting system with the measuring signal of other zebris measuring systems (e.g. CMS).
  • Page 39 Value. Begin of Illumination Timing Properties when Camera Trigger Input switching the Light OFF: No Delay (0µS) No Delay! No adjustment of Trigger-Output necessary! End of Illumination zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 39/65...

  • Page 40: Gait Training Module

    WARNING safety (safety bow with chest strap) should always be used with treadmills featuring an inverse driving direction. zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 40/65...

  • Page 41: Gait Training Type M And L (H/P/Cosmos Mercury Und Locomotion)

    Please regularly check (recommended after 25 operating hours each) that all screws of the handrail and projector mount are tightly fastened. WARNING zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 41/65...

  • Page 42: Gait Training Type Q And P (H/P/Cosmos Quasar Und Pulsar)

    Please regularly check (recommended after 25 operating hours each) that all screws of the handrail and projector mount are tightly fastened. WARNING zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 42/65...

  • Page 43: Gait Training Typed ( Daum Ergo

    Please regularly check (recommended after 25 operating hours each) that all screws of the handrail and projector mount are tightly fastened. WARNING zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 43/65...

  • Page 44: C- Mil 1.8)

    Please regularly check (recommended after 25 operating hours each) that all screws of the handrail and projector mount are tightly fastened. WARNING zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 44/65...

  • Page 45: Setup And Operation Oft He Fdm-T System

    6 Setup and Operation oft he FDM-T System 6.1 Positioning of the measuring system For setup, installation and safety related instruction of the treadmill please refer to the user manual of the treadmill manufacturer. NOTE A safety zone of at least 2m in length and 1m in width must be kept free immediately behind the treadmill in case the person should stumble.

  • Page 46: Installation Of The Detachable Cable Guard

    For the commissioning of the FDM-T system for the stance and gait analysis, the associ- ated power supply, a USB cable type A-B as well as the installation CD with the zebris FDM application software are necessary. All components are included in the scope of de- livery of the FDM-T measuring system.

  • Page 47: Connection Of The Measuring System To Mains Supply

    6.3 Connection of the measuring system to mains supply 6.3.1 Power supply of the FDM-T Sensors For connecting the FDM-T sensor to the power supply, connect the power supply unit to the mains socket and the power socket on the interface box.

  • Page 48: Connection Of The System

    For connecting the treadmill to the power supply, please additionally observe the respec- tive instructions in the Operating Instructions given by the treadmill manufacturer. The connection for the treadmill and FDM-T power supply unit must be plugged directly into the wall socket. It is not permissible to use extension cables and/or multiple sockets.

  • Page 49: Computer Requirements

    The requirements for the PC are specified in the User Manual of the zebris FDM software. If the computer is not supplied with the measuring system, the man- ufacturer shall not be held liable for any damage or malfunctions that result from defective software installation or incompatible hardware.

  • Page 50: Installing The Zebris Fdm Software

    FDM user manual. 6.6 How to switch the FDM-T sensor On/Off The FDM-T sensor is switched on and off by software control as soon as the zebris FDM software on the PC is started or shut down.

  • Page 51: Recommendations For Recording

    6.8 Recommendations for recording There are a few things one should bear in mind for obtaining significant measuring results using the FDM-T system. The following points relate to the data recording of a person dur- ing gait and describe the ideal measuring situation.

  • Page 52: Maintenance And Safety Inspections

    User Manual supplied by the treadmill manufacturer.  In order to keep the friction between the running belt and the FDM-T sensor as low as possible, the system must be lubricated at regular intervals with silicone oil. zebris rec- ommends lubricating at least every 6 months.

  • Page 53: Mandatory Periodic Inspections And Stk

    For further information please see the User Manual supplied by the treadmill manufacturer.  For the FDM-T force sensors, no technical safety tests are stipulated by zebris.  If the type plate or other important labels (warning notices) are damaged or obliterated they have to be replaced by the manufacturer for safety reasons.

  • Page 54: Maintenance Of The Fdm-T Sensor

    7.4.2 Calibration Procedures The measuring accuracy of the FDM-T sensor is to be checked from time to time using a defined application of force. To do this, the user, knowing the body weight, can stand on the platform on one foot. The...

  • Page 55: Trouble-Shooting

    7.5 Trouble-Shooting In the case of faults, please first check the following points first:  Are the FDM-T sensor and treadmill connected correctly to the mains? (Green Power LED on the interface box and power switch on the treadmill illumi- nates.) ...

  • Page 56: Cleaning And Disinfection

    WARNING For conformation that disinfection has been carried out, it is advised to place a visible sign on the running surface reading "disinfected". NOTE zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 56/65...

  • Page 57: Disposal

    7.7 Disposal 7.7.1 Packaging All the transport packaging supplied by zebris can be recycled within Germany via the local recycling depots. In order to guarantee the re- use of the recyclables contained in the packaging, zebris Medical GmbH participates in the Dual System ZENTEK which takes over the proper disposal of the packaging.

  • Page 58: Safety Standards And Classification Of The System

    8.1 Classification acc. to Annex IX of Directive 93/42/EEC If a CE mark with a four-digit number (0535) is imprinted on the type plate of your FDM-T system it is classified as a medical product of Class I with measuring function.

  • Page 59: Vicinity Of The Patient / Test Person

    In case of non-observance, dangerous leakage currents can occur. The following components of the FDM-T system may be used in the vicinity of the patient:  Treadmill (medical versions) ...

  • Page 60: Use Of Multiple Sockets

     In commercially available multiple sockets, system components set up within and out- side the vicinity of the patient must never be plugged in together. (Example: It is forbid- den to connect the PC and the power supply unit of the FDM-T sensors to the same multiple socket.) ...

  • Page 61: Electromagnetic Compatibility / Manufacturer's Declaration

    The use of accessories, particularly cables for connecting to the PC, that are not supplied by zebris for use with the FDM-T system, or explicitly recommended for use with the device, can lead to a re- duced resistance to EMC interference of the FDM-T system.
  • Page 62 Guidelines and Manufacturer's Statement - Electromagnetic Emission The FDM-T force-distribution measuring system is intended for use in the electromagnetic environment described below. The custom- er or user of the FDM-T force-distribution measuring system should ensure that it is operated in such an environment. Emitted interference measure-...
  • Page 63 Guidelines and Manufacturer's Statement - Electromagnetic Interference Immunity The FDM-T force-distribution measuring system is intended for use in the electromagnetic environment described below. The custom- er or user of the FDM-T force-distribution measuring system should ensure that it is operated in such an environment. Interference immunity...

  • Page 64: Declaration Of Conformity Medical Line (M)

    8.4 Declaration of conformity medical line (M) zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 64/65...

  • Page 65: Declaration Of Conformity Sports Line (S)

    8.5 Declaration of conformity sports line (S) zebris Medical GmbH FDM-T Technical Data and Operating Instructions Page 65/65...
