AlcoScan AL3100 USER'S MANUAL
%BAC / Status
Display
Mouthpiece Slot
(Uses Disposable
Straw Mouthpieces)
LED Range
Indicator
The AlcoScan AL3100 is a table-top wall-powered breathalyzer that measures a
breath sample to detect alcohol in the lungs. The reading is converted to blood
alcohol concentration (BAC)> The AlcoScan AL3100 uses an advanced
semiconductor sensor to detect alcohol. The AL3100 uses Pre-Calibrated
Replaceable Sensor Modules to eliminate the need for calibration. The sensor
module should be replaced approximately once every 500 tests.
The AL3100 also features an optional detachable printer unit so that the time, date,
result and name field can be recorded on readout.
Power Button
Ready Indicator
The rear panel
of the AL3100
features a
Case Hatch
Lock, Power
Port, Fan and
Serial Port for
Printer
Connection.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AL3100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alcoscan AL3100

  • Page 1 Replaceable Sensor Modules to eliminate the need for calibration. The sensor module should be replaced approximately once every 500 tests. The AL3100 also features an optional detachable printer unit so that the time, date, result and name field can be recorded on readout.
  • Page 2 Operating Instructions Make sure the AL3100 is plugged into a power source using a cable from the power port. If you are also using a printer, make sure the printer is attached the AL3100 using BOTH the power cable to draw power from the AL3100 as well as the serial cable to provide an operating interface to allow the printer to access results.
  • Page 3: Product Details

    Use AC adapter to DC 12V adapter to power the AL3100. • Printer Power port • The printer draws power from the AL3100. Both the printer power cable and the serial cable must be attached to use the printer. Serial Port Connect the printer to the AL3100 for operation using a serial cable.
  • Page 4: Technical Specifications

    The AL3100 features Pre-Calibrated Replaceable Sensor Modules to minimize maintenance. The sensor module can be conveniently ordered and replaced, eliminating the need for traditional recalibration service. 12) Auto-Power Off: AL3100 features an Auto power-off function when inactive for 15 minutes. 13) Package: AL3100 Unit AL3100 Breathalyzer Unit...
  • Page 5: Warranty

    Warnings: 1. Sensor modules must be replaced approximately every 300~500 tests according to the procedure provided above to ensure continuous accuracy of the AL3100. A high frequency of positives (many high %BAC readings) can shorten the duration before replacement is required.
  • Page 6 Technical Support For technical support, please contact us using the information below. AK GlobalTech Corp 21 Grand Ave. Suite 102 Palisades Park, NJ 07650 Toll-Free 800-943-1016 (M-F 9AM to 6PM EST) Office 201-943-9411 (M-F 9AM to 6PM EST) 201-943-8828 Email support@akglobaltech.com http://AKGlobalTech.com...
