User's Manual
AL7000 is intended to measure alcohol in human breath. Readings obtained by this device are used in the
diagnosis of alcohol intoxication.
The accuracy of this device has been established at a Blood Alcohol Concentration of 0.000and0.400%BAC.
Accuracy testing was completed according to DOT regulations.
The AlcoScan Model AL7000 analyzes a breath sample to detect alcohol in the lungs.
This reading is then converted to blood alcohol concentration (BAC).
AL7000 uses an advanced oxide semiconductor sensor to detect alcohol.
..........................................................................................................................................
Specifications
Method of Measure
Breath sample to BAC
Range
0.000% to 0.400%BAC or 0.000‰ to 4.000‰ or 0.000mg/l to 2.000mg/lBrAC
Accuracy
+/-0.01%BAC up to 0.10% BAC
Sensor
Oxide semiconductor
Power
Two 1.5V AA alkaline batteries (included)
Testing Capacity
Approx. 100~200 with new batteries
Operating Temperature 10 – 40 degrees Celsius
Warm Up
Less than 1 minute
Display
3-digit LCD
Size (mm)
105(height) X 50(width) X 18(thickness)
Weight
98g
Sensor Modules
Sensor modules should be replaced approx. 300 tests,
or if damaged by improper testing or handling
Advertisement
Related Manuals for Alcoscan AL7000
Summary of Contents for Alcoscan AL7000
- Page 1 User’s Manual AL7000 is intended to measure alcohol in human breath. Readings obtained by this device are used in the diagnosis of alcohol intoxication. The accuracy of this device has been established at a Blood Alcohol Concentration of 0.000and0.400%BAC. Accuracy testing was completed according to DOT regulations.
- Page 2 *. If you press and hold the Power Switch, you can check the accumulated total test counts. ………………………………………………………………………………………………………………………… AL7000 is the breathalyzer that features Pre-Calibrated Alcohol Sensor Modules to eliminate the need for recalibration. Just snap out, snap in and you’re ready to go! Sensor Module Replacement Please take the following steps to install new sensor module.
- Page 3 Please power on the unit again and make sure the breath is strong and steady during sampling. If you test over 300 tests, AL7000 will display “CAL” sign for 15 seconds then warning up for test. This “CAL” sign will be provided the appropriate time for calibration or replacement sensor module.
- Page 4 ………………………………………………………………………………………………………………………… Contents Breathalyzer, Mouthpieces(x5), AA Batteries(x2), Pouch, Hand strip, 12V DC cable 12V Alternative power alternative power from car cigar jack lighter with provided cable. Mouthpiece Holder It can keep 2pcs mouthpieces inside of breathalyzer. ………………………………………………………………………………………………………………………… Warranty The manufacturer warrants the product to be free from defects in workmanship or material (excluding calibration) under normal use for six (6) months from the date of purchase.
