Panasonic TX-47PT1 Service Manual

Panasonic TX-47PT1 Service Manual

Video projection system, euro5-vp chassis
Hide thumbs
Table of Contents

Advertisement

Quick Links

Specifications

Power Source:
220-240V AC, 50Hz
Power Consumption:
239W
Aerial Impedance:
75Ω unbalanced, Coaxial Type
Standby Power Consumption:
1.1W
Receiving System:
PAL-I, G, H, K, PAL-525/60
SECAM L, G, K
M.NTSC
NTSC (AV only)
Receiving Channels:
UHF E21-E69
CATV (S01-S05)
CATV S1-S10 (M1-M10)
CATV S11-S20 (U1-U10)
CATV S21-S41 (HYPERBAND)
Intermediate Frequency:
Video
38.9MHz, 34MHz
Sound
32.9Mhz, 33.4MHz, 33.16MHz
32.4MHz, 40.4MHz, 33.05MHz
32.66MHz
Colour
34.47MHz (PAL)
34.5MHz, 34.65MHz (SECAM)
Video/Audio Terminals:
AV1 IN
Video (21 pin)
Audio (21 pin)
RGB (21 pin)
AV1 OUT
Video (21 pin)
Audio (21 pin)
AV2 IN
Video (21 pin)
Audio (21 pin)
S-Video IN
(21 pin)
1V p-p 75Ω
500mV rms 10kΩ
1V p-p 75Ω
500mV rms 1kΩ
1V p-p 75Ω
500mV rms 10kΩ
Y: 1V p-p 75Ω
C: 0.3V p-p 75Ω
Video Projection System
TX-47PT1
EURO5-VP Chassis
AV2 OUT
Video (21 pin)
Audio (21 pin)
Selectable Output (21 pin)
AV3 IN
S-Video IN
(4-pin)
Audio (RCAx2)
Video (RCAx1)
AV4 IN
Video (21 pin)
Audio (21 pin)
S-Video IN
(21 pin)
AV4 OUT
Video (21 pin)
Audio (21 pin)
Dolby Surround-Out
Rear
High Voltage:
Projection Tube:
Audio Output:
(Music Power)
2 x 20W
26W
2 x 16W
Impedance 8Ω
Headphones:
Accessories Supplied:
Dimensions:
Height:
Width:
Depth:
Net Weight:
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
1999 Matsushita Electric Industrial Co.,Ltd.
All right reserved. Unauthorized copying and
distribution is a violation of law.
ORDER NO.ITD9903002C2
1V p-p 75Ω
500mV rms 1kΩ
Y: 1V p-p 75Ω
C: 0.3V p-p 75Ω
500mV rms 10kΩ
1V p-p 75Ω
1V p-p 75Ω
500mV rms 10kΩ
Y: 1V p-p 75Ω
C: 0.3V p-p 75Ω
1V p-p 75Ω
500mV rms 1kΩ
6 x Dolby Surround Out RCA
32kV ± 0.5kV
TVVAB10EDZ (B-ASSY)
TVVAG10EDZ (G-ASSY)
TVVAR10EDZ (R-ASSY)
90° Deflection
Front Left/Right
Super 3D Bass
Surround
Impedance 8Ω
Remote Control
2 x R6 (UM3) Batteries
1211mm
1093mm
560mm
61kg
