Multi-user Seesaw
Installation Instructions
Multi-user Seesaw
Springtime
Cary
Farmy
Baronessa
SPMBACK/8044148
© Playpower Inc
E-post:hags@hags.com
www.hags.com
Issue F 15/01/2016
SPMNS
SPMND
8045084
8045083
8045081
8045080
8056655
8056196
SPMNG
8045082
8045079
8056193
1/31
Advertisement
Related Manuals for HAGS Springtime
Summary of Contents for HAGS Springtime
- Page 1 Installation Instructions Multi-user Seesaw Springtime SPMNS SPMND SPMNG Cary 8045084 8045083 8045082 Farmy 8045081 8045080 8045079 8056655 8056196 8056193 Baronessa SPMBACK/8044148 © Playpower Inc E-post:hags@hags.com www.hags.com 1/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 2 ITEM PART 86401001 86009002 1.75 86009001 86030003 86110001A 86110005A 8047842 38.73 8047776 9.56 8047799 0.32 56029999 12.5 86030007 0.005 12 x 36 x 5 10301005 0.048 2/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 3 ITEM PART 86050006 10291400 0.005 15 x 35 x 5 10121035 0.032 M10 x 35 10121030 0.028 M10 x 30 10131065 0.042 M10 x 65 8008850 0.004 M10 - 11 X 24 X 2 8008796 0.01 8008386 0.058 M10 x 75 324806 0.01 8025747...
- Page 4 LxWxH (m) X 2=T SPMNS= 176 2.88 x 0.88 x 0.70 m³ m² EN1176 8045081= 172 2.88 x 0.83 x 0.86 H=0.7m T = 5hr 8045084= 172 2.82 x 0.83 x 0.81 0.45 5 x 3 8056655= 200 3.08 x 0.85 x 0.89 1400 2750 TYPE 1...
- Page 5 LxWxH (m) X 2=T SPMNS= 176 2.88 x 0.88 x 0.80 m³ m² EN1176 8045081= 172 2.88 x 0.83 x 0.96 H=0.8m T = 5hr 8045084= 172 2.82 x 0.83 x 0.91 0.45 5 x 3 8056655= 200 3.08 x 0.85 x 0.99 1400 2750 TYPE 3...
- Page 6 LxWxH (m) X 2=T SPMND= 166 2.88 x 0.88 x 0.80 m² EN1176 8045080= 162 2.88 x 0.83 x 0.96 H=0.8m T = 5hr 5 x 3 8045083= 162 2.82 x 0.83 x 0.91 8056196= 190 3.08 x 0.85 x 0.99 L1 = L2 W1=W2 INCL...
- Page 7 LxWxH (m) X 2=T SPMNG= 227 2.88 x 0.88 x 0.80 m² EN1176 8045079= 223 2.88 x 0.83 x 0.96 H=0.7m T = 5hr 5 x 3 8045082= 223 2.82 x 0.83 x 0.91 8056193= 251 3.08 x 0.85 x 0.99 L1 = L2 W1=W2 TYPE 1...
- Page 8 Step 1 20 - 25 Nm! Step 2 20 - 25 Nm! 8/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 9 Step 3 20 - 25 Nm! Step 4 S2 (50mm) 4 & 5 ≥C20-25 7 x 24h Step 5 9/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 10 Step 1-A Step 1-B Step 5 10/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 11 Step 1-B Step 2-B 11/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 12 Step 3-B Step 4-B Step 5 12/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 13 Step 5 20 - 25 Nm! LOCTITE 20 - 25 Nm! LOCTITE 16 11 Step 6 Step 7 20 - 25 Nm! 13/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 14 Appendix A: 86401003 ITEM PART QTY. 86402004 86402005 86402006 86402007 2.02 86402008 86402009 86402010 86402011 2.75 10121035 M10 X 35 0.032 10121050 M10 X 50 0.035 10131065 M10 X 65 0.039 10291000 M10 - 11 X 21 X 1 0.002 10391200 M12 - 14 X 21 X 2 0.001...
- Page 15 Appendix A: 86401003 15/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 16 Appendix A: 86401003 16/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 17 Appendix A: 86401003 A14 A13 17/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 18 Appendix A: 86401003 18/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 19 Appendix B: 8050885 ITEM PART QTY. 8045061 4.46 8045066 4.66 10121030 0.028 M10 x 30 10291000 0.002 M10 - 11 x 21 x 1 19024501 0.001 19/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 20 Appendix C: 8050884 ITEM PART QTY. 8045046 4.47 8045050 4.58 8045055 4.60 8045053 4.14 10121030 0.028 M10 x 30 10291000 0.002 M10 - 11 x 21 x 1 19024501 0.001 20/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 21 Appendix D: 8056656 ITEM PART QTY. 8056310 9.20 8056311 9.20 8056307 13.48 8056309 13.48 10121030 0.028 M10 x 30 10121040 0.032 M10 X 40 10291000 0.002 M10 - 11 x 21 x 1 21/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 22 Appendix D: 8056656 22/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 23 Appendix D: 8056656 23/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 24 Appendix E: SPMBACK/8044148 ITEM PART QTY. 86403002 2.56 86402003 3.15 10121020 M10 x 20 0.028 10121035 M10 x 35 0.032 10291000 M10 - 11 x 21 x 1 0.002 24/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 25 Appendix F: 86401001 ITEM PART QTY. 86403001 86402001 12.5 86402002 15033025 0.047 10121035 M10 X 35 0.032 10291000 M10 - 11 x 21 x 1 0.002 25/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 26 Appendix G: 56029999 ITEM PART QTY. 86009003 0.08 86009006A 0.01 0.003 86009006B 0.01 0.003 0.12 86009006C 0.01 0.003 86009007 0.001 86009005 26/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 27 Appendix F: 56029999 Step 1 34-38Nm Step 2 Step 3 G2 G3 G4 G2 G3 G4 34-38Nm 34-38Nm 27/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 28 Appendix H: 86110001A ITEM PART QTY. 86110001 15033025 0.047 28/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 29 Appendix I: 86110005A ITEM PART QTY. 86110005 15033025 0.047 29/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 30 Appendix J EN1176 TYPE 1 & 2 - H=0.7m TYPE 3 & 4 - H=0.8m L1 = L2 W1=W2 2880 3880 Zone A 0.5m Zone A 0.5m Zone A 30/31 Multi-user Seesaw Issue F 15/01/2016...
- Page 31 Appendix K 3900 2900 1728 TYPE 1, 2 3500 TYPE 3 Synthetic TYPE 5 Grassmat 31/31 Multi-user Seesaw Issue F 15/01/2016...
