Page 1
4-in-1 Bionic Mop (F801) User Manual www.hizero.com Bringing the World into Bionic Cleaning...
Page 2
Quick Start Guide Assembling Take out the trash container Open the cleaning head cover to take out the trash container. 45° Insert the cleaning roller Place the lower body on its side, find the drive motor and gently pull it out to a right angle (not to exceed 45°), insert the cleaning roller onto the drive motor, then push into the cleaning head till the lateral button in place.
Page 3
Assemble the charging base Connect the two components of the charging base. Connect the power adapter, and the excess power line can be stored in the cable slot. 4 Hours Ready for use Check whether it is necessary to charge the product first (blue battery indicator means a full battery) before use.
Page 4
Product View Handle Power Button Display Panel Mode Button Indicator for full dirty water tank Indicator for empty Brush Roller Status Indicator clean water tank Cleaning Roller Status Indicator Mode 1 (Normal) Mode 2 (Extra water) Battery Indicator Product Label Upper Body Body Quick-Mount Screw Body...
Page 5
(Regular) (Extra water) Charging Flashing Red: The product is charging. Flashing Blue: Something is wrong and contact the Customer Service Centre for a solution. Solid Blue: The product is charged fully. In Use Flashing red: Too low battery to continue working. Solid red: Low battery and the product will automatically power off within 3 minutes.
Table of Contents 1 Introduction Thank you for choosing HIZERO 4-in-1 Bionic Mop! 1 Introduction HIZERO 4-in-1 Bionic Mop is an intelligent floor cleaning machine based on innovative bionic technologies, which 1.1 Safety Instructions perfectly integrates the functions of sweeping, mopping, drying 1.2 Technical and Security Specifications...
1.5 Floor Maintenance • Use only clean water or clean water with HIZERO cleaning solution in theclean water tank of the product. Follow the cleaning and maintaining instructions of the user • Do not put acetic acid (vinegar) or unauthorized detergent in manual, and simultaneously refer to the maintenance description the water tanks nor use the product to clean them.
4 Insert the cleaning roller onto the drive motor (note: the 8 Insert the quick-mount screw into the bolt hole on the maximum open angle of the drive motor is 45°), gently push and handle of the appliance and tighten it. fix it into the cleaning head till the lateral button is in place.
(should not be higher than 40°C/104°F). If needed, HIZERO cleaning solution may be added (refer to Section 1.5 Floor Maintenance). Note: If detergent is needed, only HIZERO cleaning solution is allowed. And adding the cleaning solvent/tablet must follow the related use instruction before filling in clean water.
2 The indicator will flash and the 4.2 Start Cleaning product will stop working when the dirty water tank is full. Empty the 1 Make sure that the hard waste to be collected is always in dirty water tank (refer to Section front of the cleaning head, or it may not be cleaned effectively.
Method 1: Make the cleaning roller do self-cleaning. 5.1 Maintenance 1 Fill up the clean water tank ( add some HIZERO original 1 Regularly clean the shell of the product with a soft damp cleaning solution) and install it back, empty the dirty water tank cloth.
Mode 2. 4 To achieve a better cleaning effect, multiple self-cleaning is recommended.with HIZERO detergent. 3 Reinstall the brush roller onto the cover, then fix the cover back to the cleaning head.
7.1 Replace the Brush Roller If you want to continue to benefit from the best cleaning results, make sure you always use the original HIZERO brush roller, and we recommend you to replace it every six months. 1 Switch off the product and lock it in an upright position.
7.2 Replace the Cleaning Roller If you want to continue to benefit from the best cleaning results, make sure you always use original HIZERO cleaning roller, and replace it every four months. 1 Switch off the product and take out the trash container, then empty or take out the water tanks.
This chapter summarizes the most common problems you could encounter with the product. If you are unable to solve the problem with the information below, please contact the Customer Service Centre in your country/region or visit our FAQ page on www.hizero.com.
