- Page 1 4-in-1 Bionic Mop (F801) User Manual www.hizero.com Bring World into Bionic Cleaning Era...
- Page 2 Quick Start Guide Assembling Take out the trash container Open the cleaning head cover to take out the trash container. Insert the cleaning roller Place the lower body on its side, insert the cleaning roller onto the drive motor, then push and fix it into the cleaning head till the lateral button in place.
- Page 3 Assemble the charging base Assemble the charging base, insert the foot pads into the holes on the bottom of the charging base. Connect the power adapter, the excess power line can be stored in the cable slot. 4 Hours Ready for use Keep charging until the blue light on the indicators panel becomes ON(about 4h), then enjoy cleaning.
- Page 4 Appliance View Handle Battery Indicator Mode 2 (Strong) Display Panel Mode 1 (Normal) Cleaning Roller Status Indicator Tank Empty Indicator (clean water tank) Brush Roller Status Indicator Tank Full Indicator (dirty water tank) Mode Button Power Button Product Label Upper Body Body Quick-Mount Screw Body Hand Lifting Position...
- Page 5 Battery Indicator Mode 2 (Strong) Mode 1 (Normal) Cleaning Roller Status Indicator Tank Empty Indicator(clean water tank) Brush Roller Status Indicator Tank Full Indicator(dirty water tank) Mode Button Power Button Charging Flashing in red: Appliance is charging Lighting up in blue: Appliance is fully charged In Service Lighting up in red: Low battery.
-
Page 6: Table Of Contents
1 Introduction Thank you for choosing HIZERO 4-in-1 Bionic Mop! 1 Introduction HIZERO 4-in-1 Bionic Mop is an intelligent floor cleaning machine based on innovative bionic technology, which perfectly 1.1 Safety Instructions integrates the functions of sweeping, mopping, drying and self- 1.2 Technical and Security Specifications... -
Page 7: Technical And Security Specifications
• Use only clean water or HIZERO recommended cleaner in the 1.5 Floor Maintenance clean water tank of the appliance. Follow the cleaning and maintaining instructions of the user • Neither put acetic acid (vinegar) or unauthorized detergent in manual, and simultaneously refer to the maintenance description the water tanks nor use the appliance to clean them. -
Page 8: Preparation
4 Insert the cleaning roller onto the motor (note: the maximum 8 Insert and tighten the quick-mount screw with a coin or open angle of the drive motor is 45°), push and fix it into the screwdriver to make the upper and lower body fit together cleaning head till the lateral button in place. -
Page 9: Taking Away Large Objects On The Floor
Unlock 40℃ Note: If detergent is needed, only environmental friendly detergent authorized by HIZERO is allowed. First, add the detergent or tablet according to the indication on the bottle package, then fill the clean water tank with water. Note: During locking and unlocking the body, the click sound is... -
Page 10: Start Cleaning
2 The indicator starts flashing 4.2 Start Cleaning and the appliance stops operating when the dirty water tank is full. 1 Make sure that the trash to be absorbed is always in front of Empty the dirty water tank (please the cleaning head, or it may not be cleaned effectively. -
Page 11: Self-Protection System
2 To avoid any damage, never immerse the body in water or any other liquid, nor rinse it under the tap. 1 Before cleaning, fill up the clean water tank, add HIZERO cleaning solution if needed, and empty the dirty water tank. -
Page 12: Cleaning The Trash Container
3 As per the following figures, lift the appliance up from the 2 Clean the cover with a soft damp cloth. floor or put it on the charging base, and then keep it operating under Mode 2 until the clean water tank is empty. 4 Step 1 to 3 could be repeated for two to three times to achieve better cleaning effect. -
Page 13: Cleaning/Replacing The Filtering Sponge
7.1 Replacing the Brush Roller If you want to continue to benefit from the best cleaning results, make sure you always use the original HIZERO brush roller, and we recommend you to replace it every six months. 6 Finish the rest installation steps. -
Page 14: Replacing The Cleaning Roller
9 Caring for the Environment If you want to continue to benefit from the best cleaning results, make sure you always use original HIZERO cleaning roller, and Do not throw away the appliance as the normal household waste replace it every four months. -
Page 15: Troubleshooting
This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, please contact the Consumer Care Centre in your country or visit our FAQ page on www.hizero.com. - Page 16 M8900000103...
- Page 17 * 注：此页面无需印刷 用户手册 F801 148mm×210mm M8900000103 2018.11.22 马小容 封面 128g 铜板纸，四色印刷 内页 80g 轻型纸，专色印刷 骑马钉 装订，正反面印刷...
