- Page 1 Installation Guide Freestanding Bath P50054 1169069-2-B...
-
Page 2: Tools And Materials
Sealant Thank You For Choosing Kallista Thank you for choosing Kallista. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don’t hesitate to contact us from within the USA or Canada at 1-888-4-KALLISTA (1-888-452-5547). -
Page 3: Prepare The Site
NOTE: Refer to the roughing-in illustration when preparing the site. Make sure the flooring offers adequate support for this bath. Install the finished flooring material. Make sure the finished floor is flat and level. Kallista 1169069-2-B... - Page 4 Mark and cut a 6-1/2″ (165 mm) wide by 10-1/2″ (267 mm) long hole through the floor centered around the drain center location mark. Position the faucet supply lines. Cap the supplies and check for leaks. 1169069-2-B Kallista...
- Page 5 With help, carefully tip the bath onto its side on a clean, protective surface. Install a 3/8″ positioning bolt and nut into each of the four holes in the metal bath frame corners. Securely wrench tighten the nuts. Kallista 1169069-2-B...
- Page 6 With help, position the bath on the floor in the desired location. Use a pencil to mark the four positioning bolt locations on the finished floor. Move the bath to the side. Drill 1/2″ holes at least 2″ (51 mm) deep at the four marked bolt locations. 1169069-2-B Kallista...
- Page 7 Remove the rubber seal, and apply 100% silicone sealant to both sides of the rubber seal. Reinstall the rubber seal to the top of the drain body with the ribbed surface facing up. Kallista 1169069-2-B...
-
Page 8: Complete The Installation
Complete the drain installation according to the flip drain installation instructions. Apply a continuous bead of 100% silicone sealant completely around the bath where it meets the floor. Install the bath faucet according to the faucet manufacturer’s instructions. 1169069-2-B Kallista... - Page 9 1169069-2-...
- Page 10 1169069-2-...
- Page 11 1169069-2-...
- Page 12 USA/Canada: 1-888-4-KALLISTA Fax: 1-888-272-3094 kallista.com ©2011 KALLISTA 1169069-2-B...
