Salto KPB19 Series Installation Manual

KPB19xx..
Installation Secuence
1
A
1 i6xx...
CUT THE SPINDLE
01405
SEE INSTRUCTIONS
SP01126-20 (x20) BOLT EXTENSION
ONLY FOR P > 2 - 5/8" (67mm)
FOR ELECTRONIC ESCUTCHEON
Length
(5) M5 x Length DIN 7985
(1) M5 x Length DIN 7991
(1) Ø 3,9x19 DIN 7504
(?) BOLT EXTENSION
Length
P
Inch (mm)
Door Inch / Puerta (mm)
1-9/16" (40mm)
1-3/8"<2" (35<51mm)
2-3/16" (55mm)
2-1/16"<2-5/8" (52<67mm)
1-9/16" (40mm)
2-5/8"<3-1/4" (67<82mm)
2-3/16" (55mm)
3-1/4"<3-7/8" (83<98mm)
1-9/16" (40mm)
3-7/8"<4-7/16"(99<113mm)
2-3/16" (55mm)
4-1/2"<4-3/4" (114<120mm)
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
DORMA 9300
Adapter Kit For
.......
2 3 11
2 201445.06 Exterior Plate 11 To Fix, Counter Clockwise
2a
C
L
BOLT
EXTENSION
SUPLEMENTO
_
1
5
210129
1
2
2
* SEE DORMA 9300 PANIC BAR
Eng

INSTALLATION INSTRUCTIONS

®
Panic Bar
Single Point
3 01464-01 Battery Holder
8 01015 Selfdrilling Screw DIN 7504 PH
4 SP00095-4020
SP00095-5520
MAX. TORQUE:
1,4 N.m/13 lb.in
6 01436-40/55 M5 DIN 7991 HEX
*
Interior Plate 7
®
E * MONTAJE BARRA ANTIPANICO DORMA 9300
SEGUN INSTRUCCIONES DEL FABRICANTE
ESCUTCHEONS
COMPATIBLE
Eng
E MODELOS COMPATIBLES
M5 DIN 7985 PZ
(x20)
(x20)
9 (x30) LR06
SP01077-10
Ai650m00ffH8
Ai660m00ffH8
10 01408-01-ff Battery Cover
2 5/8" (67mm)
OUTSIDE
Eng Only Wireles s Models:
-Exit detection depending of the panic bar model.
-Panic bars with no exit detection, will cause an intrusion alarm
each time the door is opened from inside.
E
Sólo Mo delos Wireles s:
-La detección de salida depende del modelo de barra antipanico.
-Barras antipanico sin detector de salida, pueden causar una
®
alarma de intrusion cuando la puerta sea abierta desde el interior.
EXTERNAL
ELECTRONIC
MODELS
2 5/8" (67mm)
INSIDE
AT THIS POINT DO NOT
CLOSE THE DOOR
TEST THE LOCK FIRST
follow user manual
P-210130 - 1/2 -ED.08/06/2010
