- Page 1 AV MONITOR 1002DX CONDITION MONITORING SYSTEM WITH RELAY OUTPUTS USER MANUAL amc VIBRO Sp. z o.o. Pilotow 2e, 31-462 Krakow, Poland T: +48 (12) 362 97 60 S: + 48 (12) 362 97 63 info@amcvibro.com KRS No.: 0000618618 REGON No.: 364497010 VAT No.: 6772403385...
-
Page 2: Table Of Contents
Turning display off on sensor failure ‘Er’ ....................... 10 Selecting the measured vibration signal estimate 'AU‘ ................11 7.10 Relay output state configuration 'uA‘, ‘uU’ ....................11 7.11 Measurement duration ‘C’ ..........................12 Measurement parameter configuration ........................12 Menu ...................................... 14 Technical parameters ..............................15 AV MONITOR 1002DX... -
Page 3: Introduction
AC voltage output allows to control the vibration level using a portable vibration analyzer. In addition, the relay outputs can be used as safety features. If alarm level is exceeded, AVM 1002DX module can turn off the unit before critical damage occurs. AV MONITOR 1002DX... -
Page 4: Front Panel Description
rapid pulsing of diode means entering the device setup menu Keyboard: » UP – up DN - down SET - set Measured value: » double-digit LED display AV MONITOR 1002DX... -
Page 5: Module Dimensions
3. Module dimensions 4. Mounting AVM 1002DX modules are designed for mounting on 35 mm DIN rain in an upright position. Figure 4-1 // Example of 3 AVM 1002DX modules mounted on DIN rail AV MONITOR 1002DX... -
Page 6: Electrical Connectors
OK LED is pulsing with a frequency of approximately 1 Hz. Once the testing procedure is over, the device is ready to operate. If an error of a sensor circuit is detected, then corresponding LED will lit. AV MONITOR 1002DX... -
Page 7: Configuration Of Avm 1002Dx
4. Use the UP/DN buttons to select the desired alarm threshold value in the range from 0.0 to 99. Alarm threshold value cannot be lower than the warning threshold value. 5. To confirm the change, press the SET button. AV MONITOR 1002DX... -
Page 8: Setting Up Of The Warning Threshold 'U
2. By pressing UP/DN set the letter ‘L’ on the display. 3. Confirm by pressing the SET button. 4. Use the UP/DN buttons to select the ON option. 5. To confirm the change, press the SET button. AV MONITOR 1002DX... -
Page 9: Signaling Of The Sensor Failure 'Ca', 'Cu
2. By pressing UP/DN set the ‘CA’/’CU’ on the display. 3. Confirm by pressing the SET button. 4. Use the UP/DN buttons to select the ‘oF’ option. 5. To confirm the change, press the SET button. AV MONITOR 1002DX... -
Page 10: Setting Up The Correction Of Values Indicated By The Module 'Sc
2. By pressing UP/DN set the ‘Er’ on the display. 3. Confirm by pressing the SET button. 4. Use the UP/DN buttons to select the ‘oF’ option. 5. To confirm the change, press the SET button. AV MONITOR 1002DX... -
Page 11: Selecting The Measured Vibration Signal Estimate 'Au
OFF module error or alarm (if enabled) alarm active open open closed closed open closed open open open open Figure 7-1 The effects of the possible settings AV MONITOR 1002DX... -
Page 12: Measurement Duration 'C
S5 – DX: LPF = 1 kHz S5 – ON, internal power supply +24 V for 4..20 mA S6 – LPF = 10 kHz S6 – ON, external power supply for 4..20 mA S7 – acceleration S8 – velocity AV MONITOR 1002DX... - Page 13 The following configuration of the switches must be set: WARNING! The set-up of the switches configuration should be done on a switched off device. If the set-up was done on an operating module, it needs to be restarted in order to activate the new configuration. AV MONITOR 1002DX...
-
Page 14: Menu
9. Menu Graphical representation of menu structure is presented on the following figure. AV MONITOR 1002DX... -
Page 15: Technical Parameters
0 – 99 relay outputs 24 V/100 mA, NO -20..+60 operating temperature operating relative humidity <95% RH protection class IP20 dimensions 23 x 100 x 120 (W x H x L) mounting 35 mm DIN rail AV MONITOR 1002DX... - Page 16 10. Recycle 10.1. Hazardous Materials AVM 2000 devices do not use any hazardous materials outlined by RoHS. These regulations confirm that lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ether, or other battery related materials are limited to no more than trace amounts. 10.2.
