PL7900-T42/PL7901-T42
• To prevent an electric shock, be sure to connect the power cord to the PL before connecting it to
the main power supply.
• A fire or electrical shock may occur if voltages used with the PL are beyond the specified range.
Be sure to use only the specified voltage.
• Before opening the PL's protective cover, be sure to turn the unit's power OFF. This is because
the PL's internal parts carry high voltages.
• To avoid fires or electrical hazards, do not modify the PL in any way.
• Do not create touch panel switches that are used to either control or to ensure the safety of
equipment and personnel. Mechanical switches, such as an emergency stop switch, a deadman
(two-handed) start switch, etc., must be installed and operated via a separate control system.
• Do not create touch panel switches which could possibly endanger the safety of humans or
equipment. This is due to the possibility of a malfunction in the GP or its cable(s) causing the
output of a signal that could result in a major accident. All of a system's major, safety-related
switches should be designed to be operated separately from the GP.
• After the PL's backlight burns out, unlike the PL's "Standby Mode", the touch panel is still active.
If the operator fails to notice that the backlight is burned out and touches the panel, a potentially
dangerous machine miss-operation can occur.
If your PL's backlight suddenly turns OFF, use the following steps to determine if the backlight is
actually burned out.
1) If your PL is not set to "Standby Mode" and the screen has gone blank, your backlight is burned out.
2) Or, if your PL is set to Standby Mode, but touching the screen does not cause the display to
reappear, your backlight is burned out.
• If metal particles, water or other types of liquids contact any of the PL's internal parts, immedi-
ately turn the unit's power OFF, unplug the power cord, and contact either your PL distributor or
the Digital Electronics Corporation.
• Before either plugging in or unplugging a board or interface connector, be sure to turn the PL's power OFF.
• To prevent a possible explosion, do not install the PL in areas containing flammable gases.
• The PL is not appropriate for use with aircraft control devices, aerospace equipment, central
trunk data transmission (communication) devices, nuclear power control devices, or medical life
support equipment, due to these devices' inherent requirements of extremely high levels of
safety and reliability.
• When using the PL with transportation vehicles (trains, cars and ships), disaster and crime
prevention devices, various types of safety equipment, non-life support related medical devices,
etc. redundant and/or fail-safe system designs should be used to ensure the proper degree of
reliability and safety.
To Prevent Accidents
• Do not push on the PL's screen too strongly, with either your finger or with a hard object. Exces-
sive pressure can scratch, crack or damage the screen. Do not use a pointed object, such as a
mechanical pencil or screwdriver, to press any of the touch panel's switches, since they can
damage the display.
• If the screen becomes dirty or smudged, moisten a soft cloth with diluted neutral detergent,
wring the cloth well, and wipe the display. Do not use thinner or organic solvents.
• Avoid storing and operating the PL in direct sunlight, high temperatures and humidity, and in
areas where excessive dust and vibration will occur.
• Avoid using the PL in areas where sudden, extreme changes in temperature can occur. This
may cause condensation to form inside the unit, possibly leading to an accident.
• To prevent the PL from overheating, be sure its air circulation vents are clear and clean, and
keep the unit's operation area well-ventilated.
• Avoid operating or storing the PL near chemicals, or where chemicals can come into contact with the unit.
• The Digital Electronics Corporation cannot be held responsible or provide any compensation for
damage(s) caused by the loss of data stored in the PL™s hard disk drive (HDD). It is therefore
strongly suggested that all important data and software be backed up regularly to an external
data backup device.
• After turning OFF the PL's power, wait until the internal HDD stops spinning before turning on the
power again (approx. 5 seconds).
Installation Guide
WARNINGS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL7900-T42 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Electronics Corporation PL7900-T42

  • Page 1 • Avoid operating or storing the PL near chemicals, or where chemicals can come into contact with the unit. • The Digital Electronics Corporation cannot be held responsible or provide any compensation for damage(s) caused by the loss of data stored in the PL™s hard disk drive (HDD). It is therefore strongly suggested that all important data and software be backed up regularly to an external data backup device.
  • Page 2: Ul/C-Ul (Csa) Application Notes

    UL/c-UL (CSA) Application Notes The PL790*-T4* is UL/c-UL 1950 recognized product. (UL File No. E171486). Please pay special attention to the following instructions when applying for UL/c-UL approval for ma- chinery which includes any of these PL units. The PL conforms as a component to the following standards: UL 1950, Third Edition, dated March 1,1998 (Standard for Safety of Information Technology Equipment, including Electrical Business Equipment) CSA-C22.2 No.
  • Page 3: Package Contents

    Package Contents The PL package should include the following items: ! ! ! ! ! PL Unit ! ! ! ! ! Power Cord ! ! ! ! ! Installation Brackets (12) (PL-7900T/PL-7901T) Be careful when This cord is designed installing the PL only for AC100/115V not to damage...
  • Page 4: Pl External Features

    PL External Features A : Display Area B : Touch Panel C : Power Lamp LED D : Front Maintenance Cover <Inside the E : IrDA front main- F : Keyboard Connector tenance cover> G : Hardware Reset Switch H : FDD Slot (only for PL-7900T) I : Brightness Adjustment Slide J : RS-232C Connector (COM1) K : RS-232C Connector (COM2)
  • Page 5 PL Dimensions • PL-7900T General Dimensions (Unit: mm [in.] - excluding projections) 359 [14.13] Top View 180 [7.09] 374 [14.72] 13 [0.51] Front View Side View • PL-7901T General Dimensions (Unit: mm [in.] - excluding projections) 359 [14.13] Top View 134 [5.28] 374 [14.72] 13 [0.51]...
  • Page 6: General Specifications

    General Specifications ! Electrical PL-7900T PL-7901T Input Voltage AC 100V to AC 240V Rated Voltage AC 85V to AC 265V Frequency 50/60Hz shorter than 1 cycle Allowable Voltage Drop (however, pause occurrences must be more than 1 second apart) Power Consumption less than 150VA less than 100VA AC 1500V at 20mA for 1 minute...
  • Page 7 ! Environmental PL-7900T PL-7901T Exclusive grounding only: Grounding Less than 100 Ω , or your country’s applicable standard. Equivalent to IP65f (JEM1030) Rating Cooling Method Via heat convection tubes and electric fan Less than 10.5 kg (23.1 lb) Less than 9.5 kg (20.9 lb) Weight (with HDD and FDD installed) (with HDD and FDD installed)
  • Page 8: Interface Specifications

    Interface Specifications ! Printer Interface (LPT1) D-sub 25 pin (Female) 11 12 13 14 15 16 17 18 19 21 22 23 24 25 Screw Size: (4-40): Inch Type : Open Drain : 3 state I/O TTLIN : TTL Input SPP/ECP SPP/ECP Mode...
  • Page 9 ! Mouse Interface Pin No. Signal Name Mini - DIN 6 pin (Female) Mouse DATA Mouse CLK SHIELD ! RS-232C Interface (COM1/COM2/COM3) Signal Signal Dsub 9 pin (Male) Pin No. Pin No. Name Name Screw Size: (4-40): Inch Type The GND terminal is the signal ground. Be sure to connect the GND terminal to other unit’s SG (signal ground).
  • Page 10 ! ! ! ! ! Input Port (Dual use of DIN, Remote Set Input Port) - External Power : DC12V to 24V connection possible - Input Hold : Hold Diode - Isolation : Used (Photo isolation) (Interface Circuit) (Connection Example) DC12V to DC24V External...
  • Page 11 Installing the PL Follow the steps given below when installing the PL. Attaching the Moisture Resistant Gasket Even if the your PL’s Moisture Resistant Gasket is not needed to prevent water from entering the unit, the gasket also acts as a vibration absorber and should always be attached.
  • Page 12 ! Installation 1) Insert the PL into the panel cut. 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0...
  • Page 13: Wiring The Pl

    Wiring the PL ! ! ! ! ! Connecting the power cord (Side View of PL) Power Input Terminals Connecting these two termi- nals provides 100V to 240V AC power. L= live and N= Neutral Power Terminals (screw size: M3) Power Switch This terminal is connected to the PL’s frame (chassis).
  • Page 14 2) Loosen and remove the middle three(3) screws from the terminal Black strip. Align the crimp terminals with each screw hole, and tighten the screws. White Green/ • Crimp Terminal Types : Yellow V1.25-3, by J.S.T. or equivalent (JIS standard part number : RAV1.25-3) •...
  • Page 15: Power Supply Cautions

    Power Supply Cautions When connecting the PL unit’s AC power terminals, please be aware of the following: • If voltage fluctuations are expected to vary Twisted-pair cable Constant beyond the specified range, connect a constant voltage transformer voltage transformer. • Use a low-noise power supply both between Twisted-pair cable Insulating...
  • Page 16: Cautions When Connecting I/O Signal Lines

    Note Be aware that the Digital Electronics Corporation shall not be held liable for any real or estimated damages or losses, or third party claims resulting from the use of this product. © 2000 Digital Electronics Corporation. All rights reserved.
