Follow the instructions given below to ensure the correct and safe use of the PL.
• To prevent an electrical shock, be sure to connect the power cord to the PL
before connecting it to the main power supply.
• A fire or electrical shock may result if voltages are used with the PL that are
beyond the specified range. Be sure to only use the specified voltage.
• Before opening the PL's protective cover, be sure to turn the unit's power OFF.
This is because the PL's internal parts carry high voltages.
• If metal particles, water or other types of liquids contact any of the PL's internal
parts, immediately turn the unit's power OFF, unplug the power cord, and contact
your local PL distributor.
• Read and understand Chapter 4 "Installation and Wiring" thoroughly in order to
select an appropriate installation location for the PL.
• Before either plugging in or unplugging a board or interface connector, be sure to
turn the PL's power OFF.
• To prevent a possible explosion, do not install the PL in areas containing flammable gases.
• The PL is not appropriate for use with aircraft control devices, aerospace equip-
ment, central trunk data transmission (communication) devices, nuclear power
control devices, or medical life support equipment, due to these devices' inher-
ent requirements of extremely high levels of safety and reliability.
• When using the PL with transportation vehicles (trains, cars and ships), disaster
and crime prevention devices, various types of safety equipment, non-life sup-
port related medical devices, etc. redundant and/or failsafe system designs should
be used to ensure the proper degree of reliability and safety.
To Prevent Accidents
Follow the instructions given below to ensure the correct and safe use of the PL.
• Do not push on the PL's screen too strongly, with either your finger or with a hard
object. Excessive pressure can scratch, crack or damage the screen. Do not use
a pointed object, such as a mechanical pencil or screwdriver, to press any of the
touch panel's switches, since they can damage the display.
• If the screen becomes dirty or smudged, moisten a soft cloth with diluted neutral deter-
gent, wring the cloth well, and wipe the display. Do not use thinner or organic solvents.
• Avoid storing and operating the PL in direct sunlight, high temperatures and hu-
midity, and in areas where excessive dust and vibration will occur.
• Avoid using the PL in areas where sudden, extreme changes in temperature can occur.
This may cause condensation to form inside the unit, possibly leading to an accident.
• To prevent the PL from overheating, be sure its air circulation vents are clear and
clean, and keep the unit's operation area well-ventilated.
• Avoid operating or storing the PL near chemicals, or where chemicals can come
into contact with the unit.
• The Digital Electronics Corporation cannot be held responsible or provide any
compensation for damage(s) caused by the loss of data stored in the PL™s hard
disk drive (HDD). It is therefore strongly suggested that all important data and
software be backed up regularly to an external data backup device.
• After turning OFF the PL's power, wait until the internal HDD stops spinning
before turning on the power again (approx. 5 seconds).
PLB910-42/PLB911-42
Installation Guide
WARNINGS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLB910-42 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Electronics Corporation PLB910-42

  • Page 1 • Avoid operating or storing the PL near chemicals, or where chemicals can come into contact with the unit. • The Digital Electronics Corporation cannot be held responsible or provide any compensation for damage(s) caused by the loss of data stored in the PL™s hard disk drive (HDD).
  • Page 2: Ul/C-Ul (Csa) Application Notes

    UL/c-UL (CSA) Application Notes The PLB91*-4* is UL/c-UL 1950 recognized product. (UL File No. E171486). Please pay special attention to the following instructions when applying for UL/c-UL approval for ma- chinery which includes any of these PL units. The PL conforms as a component to the following standards: UL 1950, Third Edition, dated March 1,1998 (Standard for Safety of Information Technology Equipment, including Electrical Business Equipment) CSA-C22.2 No.
  • Page 3: Package Contents

    Package Contents The PL package should include the following items: ! ! ! ! ! PL Unit ! ! ! ! ! Power Cord ! ! ! ! ! Installation Brackets (1 set) (PL-B910/PL-B911) and screws (6) Be careful when This cord is designed installing the PL only for AC100/115V...
  • Page 4: Pl External Features

    PL External Features A : Front Face FDD Unit Attachment Slot B : Display Expansion Board Cover C : RS-232C Connector (COM1) D : RS-232C Connector (COM2) E : RS-232C Connector (COM3) F : Printer Connector (LPT1) G : RAS Connector H : Rear Maintenance Cover I : Power Terminal Block PL-B910...
  • Page 5 PL Dimensions • PL-B910 General Dimensions (Unit: mm [in.]- excluding projections) 359 [14.13] Top View 180 [7.09] 13 [0.51] 374 [14.72] Front View Side View • PL-B911 General Dimensions (Unit: mm [in.]- excluding projections) 359 [14.13] Top View 134 [5.28] 13 [0.51] 374 [14.72] Side View...
  • Page 6: General Specifications

    General Specifications ! Electrical PL-B910 PL-B911 Input Voltage AC 100V to AC 240V Rated Voltage AC 85V to AC 265V Frequency 50/60Hz shorter than 1 cycle Allowable Voltage Drop (however, pause occurrences must be more than 1 second apart) Power Consumption less than 150VA less than 100VA AC 1500V at 20mA for 1 minute...
  • Page 7 ! Environmental PL-B910 PL-B911 Exclusive grounding only. Grounding Less than 100 Ω , or your country’s applicable standard. Installation Method Inside a solid, flat panel Cooling Method Via heat convection tubes and electric fan Less than 7.5 kg (16.5 lb) Less than 6.5 kg (14.3 lb) Weight (with HDD and FDD installed)
  • Page 8: Interface Specifications

    Interface Specifications ! Printer Interface (LPT1) D-sub 25 pin (Female) 13 12 25 24 23 22 21 20 19 18 17 16 15 14 Screw Size: (4-40): Inch Type SPP/ECP SPP/ECP Mode Mode Electrical Mode Mode Electrical Direction Direction Signal Signal Specif.
  • Page 9: Keyboard Interface

    ! Keyboard Interface (The PL’s front and side connectors are the same) Mini - DIN 6 pin (Female) Pin No. Signal Name KEY DATA KEY CLK SHIELD ! Mouse Interface Pin No. Signal Name Mini - DIN 6 pin (Female) Mouse DATA Mouse CLK SHIELD...
  • Page 10: Rs-232C Interface (Com1/Com2/Com3)

    ! RS-232C Interface (COM1/COM2/COM3) Signal Signal Pin No. Pin No. Dsub 9 pin (Male) Name Name RT S CT S DT R Screw Size: (4-40): Inch Type The GND terminal is the signal ground. Be sure to connect the GND terminal to other unit’s SG (signal ground).
  • Page 11 ! ! ! ! ! Input Port (Dual use of DIN, Remote Set Input Port) - External Power : DC12V to 24V connection possible - Input Hold : Hold Diode - Isolation : Used (Photo isolation) (Interface Circuit) (Connection Example) DC12V to DC24V External...
  • Page 12: Installing The Pl

    Installing the PL Use the following procedures to install the PL into a solid panel. When using the optional 19 inch Mount Panel, refer to the PL-RM200 unit’s Installation guide for details. 1) Use the six (6) attachment screws included in the PL’s packing box to attach the mounting brackets to the PL main unit.
  • Page 13: Wiring The Pl

    3) Attach the PL to the Installation Panel with M4 screws. First, insert the main unit attachment screws into the Installation Panel’s holes, but do not tighten them. Then, place the PL main unit on the panel so that the bracket holes and the screw heads align. Next, slide the PL down so that the main unit is supported by these attachment screws.
  • Page 14 Use the following steps when connecting the power cord to the PL’s power terminals. 1) Confirm that the PL unit's power switch is POWER turned OFF. Then, remove the power terminal’s I :ON transparent plastic cover. o :OFF Transparent Cover Screws 2) Loosen and remove the middle three(3) screws from the terminal...
  • Page 15: Power Supply Cautions

    Power Supply Cautions When connecting the PL unit’s AC power terminals, please be aware of the following: • If voltage fluctuations are expected to vary Twisted-pair cable Constant beyond the specified range, connect a constant voltage transformer voltage transformer. • Use a low-noise power supply both between Twisted-pair cable Insulating...
  • Page 16: Cautions When Connecting I/O Signal Lines

    Note Be aware that the Digital Electronics Corporation shall not be held liable for any real or estimated damages or losses, or third party claims resulting from the use of this product. © 2000 Digital Electronics Corporation. All rights reserved.

This manual is also suitable for:

Plb911-42
