VIA Technologies AMOS-5000 User Manual

Fan-less, compact embedded chassis kit for the eitx-3000
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
user manual
AMOS-5000
Fan-less, compact embedded
chassis kit for the EITX-3000
Revision 1.00
100-11032009-1551

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMOS-5000 and is the answer not in the manual?

Questions and answers

Related Manuals for VIA Technologies AMOS-5000

Summary of Contents for VIA Technologies AMOS-5000

  • Page 1 AMOS-5000 Fan-less, compact embedded chassis kit for the EITX-3000 Revision 1.00 100-11032009-1551...
  • Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
  • Page 3 Safety Precautions Do’s Always read the safety instructions carefully. Keep this User's Manual for future reference. All cautions and warnings on the equipment should be noted. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up.
  • Page 4 Box Contents and Ordering Information Model Number Description AMOS-5000-1MZZA1 Standard kit 1 x front I/O panel 1 x rear I/O panel 1 x top cover 1 x CF cover 1 x package of cable ties 1 x audio cable 1 x GPIO cable...

  • Page 5: Table Of Contents

    ABLE OF ONTENTS 1 Overview ......................... 1 Specifications ......................4 Operating Environment................... 5 2 Installing the I/O cables .................. 6 Front I/O plate cables ..................7 Installing the GPIO cable................7 Installing the WLAN antenna ..............9 Rear I/O plate cables..................10 Installing the TRS audio cable ..............10 Installing the USB I/O cable ..............11 Installing the LPT cable ................12...

  • Page 6: Overview

    Overview...
  • Page 7 The AMOS-5000 is a fanless and compact chassis kit that complements the EITX-3000. The AMOS-5000 comes in two configurations: standard and expanded storage. The standard AMOS-5000 configuration consists of front and rear I/O plates and a top cover. The expanded storage configuration consists of front and rear I/O plates and a compartmentalized storage section that can support up to two 2.5”...
  • Page 8 The front I/O plate features cutouts for two USB ports, four COM ports, one GPIO port, one DC-in port, two LED indicators, and one WLAN antenna. The rear I/O plate features cutouts for three TRS jacks, one VGA port, two USB ports, two LVDS ports, one CF slot, two LAN ports, and one LPT port.

  • Page 9: Specifications

    PECIFICATIONS Standard kit Expanded storage kit Material Heavy duty steel Heavy duty steel Disk drive capacity 1 x GPIO 1 x GPIO Front I/O support 1 x DC-in 1 x DC-in 2 x USB 2 x USB 4 x COM 4 x COM 1 x antenna 1 x antenna...

  • Page 10: Operating Environment

    PERATING NVIRONMENT EITX-3000 with EITX-3000 without AMOS-5000 AMOS-5000 Operating temperature With HDD With HDD With CF With CF With HDD With HDD With CF With CF 0°C ~ 45°C -10°C ~ 65°C With CF With CF With CF With CF -20°C ~ 55°C...

  • Page 11: Installing The I/O Cables

    Installing the I/O cables...

  • Page 12: Front I/O Plate Cables

    RONT PLATE CABLES Installing the GPIO cable Step 1 Step 1 Step 1 Step 1 Break off the GPIO cutout filler. Step 2 Step 2 Step 2 Step 2 Use a metal file to smooth out any rough edges. Step 3 Step 3 Step 3 Step 3...
  • Page 13 Step 4 Step 4 Step 4 Step 4 Fasten the standoff screws to secure the connector to the front I/O plate.

  • Page 14: Installing The Wlan Antenna

    Installing the WLAN antenna Step 1 Step 1 Step 1 Step 1 Insert the WLAN antenna port into the antenna cutout. Step Step Step Step 2 2 2 2 Fasten the WLAN antenna port in place with the nut.

  • Page 15: Rear I/O Plate Cables

    PLATE CABLES Installing the TRS audio cable Step 1 Insert the 3-jack TRS connector into the TRS cutout. Step Step Step Step 2 2 2 2 Fasten the standoff screws to secure the connector to the rear I/O plate.

  • Page 16: Installing The Usb I/O Cable

    Installing the USB I/O cable Step 1 Step 1 Step 1 Step 1 Insert the USB connectors into the USB cutouts. Step Step Step Step 2 2 2 2 Fasten the standoff screws to secure the connectors to the rear I/O plate.

  • Page 17: Installing The Lpt Cable

    Installing the LPT cable Step 1 Step 1 Step 1 Step 1 Break off the LPT cutout filler. Step 2 Step 2 Step 2 Step 2 Use a metal file to smooth out any rough edges. Step 3 Step 3 Step 3 Step 3 Insert the 25-pin D-sub LPT connector into the LPT cutout.
  • Page 18 St St St Step 4 ep 4 ep 4 ep 4 Fasten the standoff screws to secure the connector to the rear I/O plate.

  • Page 19: Installing The Standard Kit

    Installing the standard kit...

  • Page 20: Installing The Front I/Oplate

    NSTALLING THE FRONT PLATE Step 1 Step 1 Step 1 Step 1 Remove all standoff screws from the front I/O connectors of the EITX-3000.
  • Page 21 Step Step Step Step 2 2 2 2 Align the front I/O plate with EITX-3000. Step Step Step Step 3 3 3 3 Secure the front I/O plate to the heatsink of the EITX-3000. And reinstall all standoff screws to the front I/O connectors.

  • Page 22: Installing The Rear I/Oplate

    NSTALLING THE REAR PLATE Step 1 Step 1 Step 1 Step 1 Remove all standoff screws from the rear I/O connectors of the EITX-3000. Step Step Step Step 2 2 2 2 Align the rear I/O plate with EITX-3000.
  • Page 23 Step Step 3 3 3 3 Step Step Secure the rear I/O plate to the heatsink of the EITX-3000. And reinstall all standoff screws to the rear I/O connectors. Step Step 4 4 4 4 Step Step Install the CF cover on the rear I/O plate.

  • Page 24: Installing The Top Cover

    NSTALLING THE TOP COVER Before installing the top cover, the hard drive and WLAN module (optional) should be installed. Installing the hard drive Step 1 Step 1 Step 1 Step 1 Mount the hard disk brackets on the 2.5 inch hard disk drive. And insert the rubber shock absorbers to the HDD mounting brackets.

  • Page 25: Installing The Wlan Module

    Installing the WLAN module Step 1 Step 1 Step 1 Step 1 Align the WLAN module over the WLAN mounting holes on the inner side of the top cover. Step Step Step Step 2 2 2 2 Secure the WLAN module to the top cover with two mounting screws.

  • Page 26: Installing The Top Cover

    Installing the top cover Step 1 Step 1 Step 1 Step 1 Align the top cover over the mounting holes on the heatsink.
  • Page 27 Step Step Step Step 2 2 2 2 Secure the top cover with eight mounting screws.

  • Page 28: Installing The Expanded Storage Kit

    Installing the expanded storage kit...

  • Page 29: Installing The Front I/Oplate

    NSTALLING THE FRONT PLATE Step 1 Step 1 Step 1 Step 1 Remove all standoff screws from the front I/O connectors of the EITX-3000. Step Step 2 2 2 2 Step Step Align the front I/O plate with EITX-3000.
  • Page 30 Step Step 3 3 3 3 Step Step Secure the front I/O plate to the heatsink of the EITX-3000. And reinstall all standoff screws to the front I/O connectors...

  • Page 31: Installing The Rear I/Oplate

    NSTALLING THE REAR PLATE Step 1 Step 1 Step 1 Step 1 Remove all standoff screws from the rear I/O connectors of the EITX-3000. Step Step Step Step 2 2 2 2 Align the rear I/O plate with EITX-3000.
  • Page 32 Step Step 3 3 3 3 Step Step Secure the rear I/O plate to the heatsink of the EITX-3000. And reinstall all standoff screws to the rear I/O connectors. Step Step 4 4 4 4 Step Step Install the CF cover on the rear I/O plate.

  • Page 33: Installing The Expanded Storage Kit

    NSTALLING THE EXPANDED STORAGE The expanded storage chassis consists of two pieces. The bottom portion of the storage chassis must be mounted first before mounting the top portion. Before mounting the bottom portion of the storage chassis, the WLAN module (optional) should be installed.

  • Page 34: Installing The Bottom Half Of The Storage Kit

    Installing the bottom half of the storage kit Step 1 Step 1 Step 1 Step 1 Align the bottom half of the storage chassis over the mounting holes on the heatsink.
  • Page 35 Step Step Step Step 2 2 2 2 Secure the bottom half of the storage chassis to the heatsink with eight mounting screws.

  • Page 36: Installing The Hard Drives

    Installing the hard drives Step 1 Step 1 Step 1 Step 1 Mount the hard disk brackets on the 2.5 inch hard disk drives. And install the rubber shock absorbers to the HDD mounting brackets.
  • Page 37 Step Step Step Step 2 2 2 2 Align the shock absorbers over the hard drive mounting holes on the inside of the storage chassis and mount the hard drives. And secure the hard drives to the storage chassis with the four hard drive mounting screws per hard drive.

  • Page 38: Installing The Top Half Of The Storage Kit

    Installing the top half of the storage kit Step 1 Step 1 Step 1 Step 1 Align the top half of the storage chassis with the bottom half of the storage chassis.
  • Page 39 Step Step Step Step 2 2 2 2 Secure the top half of the storage chassis to the bottom half with four mounting screws.
