Mounting Instructions (to wire shelf)
NOTE! UltraDurable Commercial-Grade Pull-Out Sliding Steel Wire Cabinet Organizer
Drawer is compatible with all 18 inch deep UltraDurable Commercial-Grade shelving.
Specifications
Dimensions: 14" W x 17.75" D x 6.375" H
Weight capacity: 50 lbs.
Weight: 7 lbs.
Customer Service Information
Telephone: (800) 323-5565
Fax: (310) 533-3899
Hours: 8:30 AM – 4:30 PM (PST)
Email:
Support@SevilleClassics.com
Homepage:
www.SevilleClassics.com
022019
STEP 1.
Position DRAWER (A) on
UltraDurable wire shelf.
STEP 2.
Align BRACKET (C) with
mounting holes on DRAWER
(A) and attach with MACHINE
SCREWS (D).
STEP 3.
Attach all 4 BRACKETS (C).
Commercial-Grade Pull-Out Sliding
Steel Wire Cabinet Organizer Drawer
Model: WEB520
Thank you for choosing Seville Classics! We hope that you enjoy your new steel
pull-out drawer. Please read through this user guide for parts list, assembly
instructions, frequently asked questions and further contact information.
022019
Advertisement
Related Manuals for Seville Classics ULTRADURABLE WEB520
Summary of Contents for Seville Classics ULTRADURABLE WEB520
-
Page 1: Specifications
Fax: (310) 533-3899 Model: WEB520 Hours: 8:30 AM – 4:30 PM (PST) Thank you for choosing Seville Classics! We hope that you enjoy your new steel Email: Support@SevilleClassics.com pull-out drawer. Please read through this user guide for parts list, assembly Homepage: www.SevilleClassics.com... - Page 2 Parts List Mounting Instructions (to cabinet) STEP 1. Place the MOUNTING TEMPLATE (B) onto your A. Drawer (1) shelf or cabinet. IMPORTANT: Make sure there is room to close the door without it touching the template. B. Mounting Template (1) Lightly secure with tape, and drill 10 pilot holes through the template into the shelf.
